  • Page 1 PB-150 Comb Binding Machine 95494 1 12/18...
  • Page 2 ENGLISH Punching&Binding Level Holding fixture for binding elements Margin Adjusting Scale Measuring Scale Punching Shaft Paper Guide With Attachment Screw CAPABILITIES Technical Data Width 300mm Punching Thickness : 15sheets Punch PVC Cover 2sheets Punch PP Cover 1sheet Machine Dimension : 44.5x21x28.8cm Weight 5kgs...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS-KEEP FOR FUTURE USE Please read before use and keep for future When punching; - always ensure the machine is on a stable surface - test punch scrap sheets and set the machine before punching final documents - remove staples and other metal articles prior to punching - never exceed the machines quoted performance Keep the machine away from heat and water sources.
  • Page 4 PUNCH 1.Adjusting paper guide to the corresponding paper size. Release attachment screw, adjust paper guide and fasten attachment screw. 2.Determine the diameter. Put the block under the measuring scale. Push slider downwards. Read the diameter of the binding element . 3.Adjusting the margin turn right knob to the corresponding size 4.Insert paper into punching slot,...
  • Page 5 PUNCH 5.Ensure the paper is less than 15 pieces BIND 1.Caution! Lay the plastic binding element with its spine behind the vertical retaining fingers and its rings facing down through the gaps in the fi ngers. 2. Open the binding comb by pushing the binding lever backward.
  • Page 6 BIND 4. Lay down paper to the front. Close plastic comb by returning the binding lever to stop. REMOVE BOUND BOOK 1.With the binding lever in the rear position, slide the bound book over the comb by pushing the binding lever backwards. 2.Remove the desired pages, punch and insert the new ones.

  • Page 7: Troubleshooting

    REMOVAL OF WASTE CLIPPINGS The waste tray is located under the machine and is accessed from the front side. For best results empty the tray regularly. TROUBLESHOOTING Problem Cause Solution Adjust edge guide until hole pattern Edge guide not Punched holes are not central is correct Check waste tray is empty.
  • Page 8 International GmbH Bergheimer Straße 6 - 12 88677 Markdorf / Germany Tel.: ++49 (0)7544 / 60-0 Fax.: ++49 (0)7544 / 60-248 E-mail: sales.de@intimus.com www.intimus.com 95494 1 12/18...
