BR Remote Micro Joystick Instructions

Quite simply - the simplest joystick ever!
All functions are controlled with the joystick which has 3 modes;
1. Pan & Tilt
2. Zoom & Focus
3. Menu Scroll & select
The modes are changed with the touch-down switch on the joystick. You can either
down the switch.
A tap is less than 0.5 second
A hold down is more than 0.5 second
The joystick powers up in
mode, just tap the joystick switch.
To enter Menu Scroll
To exit Menu Scroll mode,

Connections;

DC jack : 12 – 35v
XLR4: on a flying lead. This has both power & data for a remote head.
Note: The supplied power supply is 12w. This is enough for some cameras but not for others. Check the
power consumption of the camera you are using. Include the lens motors if fitted. If needed, use a 2
power supply near to the camera with a break-out cable.
There is a connector on the PCB inside which can be used to connect a Remote Camera Panel or other
equipment into the system. When data is being received the LED will flash.
Note: Not all functions apply to all camera models. Check camera specification for applicable functions.
Instructions
Pan & Tilt mode. To toggle between
mode, hold down the joystick switch. Then use the joystick to navigate the menu.
hold down the joystick switch.
Joystick
tap
Pan & Tilt mode and
Micro
the switch or hold
Zoom & Focus
nd
