- Page 1 RAP200MT RAP200MT USER’S AND INSTALER’S MANUAL v2.0 REV. 05/2021...
-
Page 2: Table Of Contents
01. SAFETY INSTRUCTIONS This product is certified in accordance with European Community (EC) safety standards. 02. THE PRODUCT RAP200MT This product complies with Directive 2011/65/EU of the TECHNICAL CHARACTERISTICS European Parliament and of the Council, of 8 June 2011, on... -
Page 3: Safety Instructions
01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. very important. Read all instructions carefully before beginning the WARNINGS FOR TECHNICIANS installation/usage procedures and keep this manual in a safe place that it can be consulted whenever necessary. - Page 4 01. SAFETY INSTRUCTIONS RESPONSABILITY September 2009. • Attach the permanent label for the manual release as close as possible • Supplier disclaims any liability if: to the release mechanism. • Product failure or deformation result from improper installation • Disconnect means, such as a switch or circuit breaker on the electrical use or maintenance! panel, must be provided on the product’s fixed power supply leads in •...
-
Page 5: The Product
RAP200MT DESCRIPTION Rotation screw The RAP200MT is an ideal microwave radar for large doors and places with high ceilings, and can be installed up to 7m height. It has detection technology capable of differentiating people Green LED and vehicles, reducing unwanted openings, thus saving energy loss. -
Page 6: Installation
03. INSTALLATION INSTALLATION AND CONNECTIONS Define the location where you want to install the product and position it (level). Loosen the rotation screw and separate the fixing bracket from the sensor body (it is not necessary to remove the rotation screw completely). Make the markings and drill the wall. -
Page 7: Configuration
04. CONFIGURATION 04. CONFIGURATION SENSOR CONFIGURATION PROGRAMMABLE PARAMETERS 01 • Press the [Function] button for 2 sec. (or more) to enter the programming mode. FACTORY FUNCTION (RED LED) VALUE (GREEN LED) DESCRIPTION 02 • The current function (red LED) and value (green LED) will be indicated by the number of times that VALUE the red and green LEDs flash slowly (see table Programmable Parameters) (1) Vehicle (front) -
Page 8: Sensitivity 7A
04. CONFIGURATION 04. CONFIGURATION SENSITIVITY VEHICLE PRESENCE RELAY Recommended values to increase or decrease the size of the detection area. The vehicle presence relay has the function of communicating the approach of a vehicle to the control board, activating the opening of the door. SENSOR BODY ANGLE 01 •... -
Page 9: Detection Area Adjustment
The RAP200MT sensor has the ability to distinguish between people and vehicle detection depending on 01 • Connect the Vehicle Presence Relay and the Human Presence Relay to the door control board. the connection and configuration of the vehicle and human presence relays. -
Page 10: Troubleshooting
05. TROUBLESHOOTING INSTRUCTIONS FOR FINAL CONSUMERS / SPECIALIZED TECHNICIANS Anomaly Cause / Resolution • There is no current supplying the device; LEDs do not emit a signal • The device is defective (send to technical services). • Tilt the sensor body out of the door; •...
