Figure 11. The horizontal directivity characteristics of the 8361A
(monitor in vertical orientation).
Figure 13. The signal path block diagram of the 8361A.
SYSTEM SPECIFICATIONS
Lower cut-off frequency, –6 dB
Upper cut-off frequency, –6 dB
Accuracy of frequency response, ± 1.5 dB
Maximum short term sine wave acoustic output on axis in half space, averaged from
100 Hz to 3 kHz at 1 m
Maximum long term RMS acoustic output in the same conditions with IEC weighted
noise (limited by driver protection circuit) at 1 m
Maximum peak acoustic output per pair in a listening room with music material at 1 m
Self generated noise level in free space at 1 m on axis (A-weighted)
Harmonic distortion at 95 dB SPL at 1 m on axis
Freq:
50...100 Hz
> 100 Hz
Drivers
Bass
Midrange
Treble
Weight
Dimensions
Height including IsoPod stand
Height without IsoPod
Width
Depth
Figure 12. The vertical directivity characteristics of the 8361A
(monitor in vertical orientation).
< 30 Hz
> 43 kHz
36 Hz – 20 kHz
≥ 118 dB SPL
109 dB SPL
128 dB SPL
≤ 5 dB
< 3 %
< 0.5 %
Dual 263 x 137 mm (10
/
x 5
3
8
130 mm (5 in) cone (coaxial)
25 mm (1 in) metal dome (coaxial)
31.9 kg (70.3 lb)
593 mm (23
/
in)
3
8
/
570 mm (22
in)
7
16
357 mm (14 in)
/
347 mm (13
in)
5
8
/
in) obround cones
3
8
7
