Page 1: Table Of Contents
OPERATING HAZARDS http://www.dropsa.com Manual drawn up in accordance with EC Directive 06/42 C2159IE - WK 25/17 Via Benedetto Croce, 1 Dropsa products can be purchased from Dropsa bracnhes and authorized distributors, Vimodrone, MILANO (IT) visit or contact us at www.dropsa.com/contact sales@dropsa.com...
Page 2: Introduction
1. INTRODUCTION This user and maintenance manual relates to the MiQueL air/oil modular minimal system. The latest version may be obtained from the Technical-Commercial Office, or by consulting our website http://www.dropsa.com. This user and maintenance manual contains important information about protecting the health and safety of the personnel who intend to use this apparatus.
Page 3: Product Identification
3. PRODUCT IDENTIFICATION There is a plate on the side of the unit that displays the product code, the power supply voltages and the basic characteristics. 4. TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS 1lt – 3lt Reservoir capacity Maximum number of modules 4bar ÷...
Page 4 COMPLETE UNIT - MiQueL PRO- i Solenoid valve kit (optional) Air inlet 24V power supply Pressure switch (optional) Pressure gauge Loading cap with filter Device to remove Ø3 tube (optional) Air inlet Slider valve 3/2 Mounting brackets Modular element outlets...
Page 5: Unpacking And Installing
Use safety gloves or glasses as specified in the safety sheet for the lubricant. Do not use aggressive lubricants with NBR gaskets. In the case of doubt, contact the Dropsa SpA technical office to receive a detailed card about the recommended oils.
Page 6: Operating Instructions
At the first start-up, it may be necessary to fill the oil pipes, wait until the lubricant exits; • Check that the lubrication is suitable (if there are doubts about correct operation, the Dropsa SpA technical office can be contacted to request the inspection procedure).
Page 7: Troubleshooting
If you were not able to solve the problem after consulting the diagnostics table, do not try to find the fault by disassembling machine parts but contact the Dropsa technical office and report the discovered anomalies, with a detailed description.
Page 8: Ordering Information
3135507 3135547 3135508 3135548 3135511 3135551 3135512 3135552 Air/Oil modular minimal system 3135513 3135553 with compensation valve 3135514 3135554 MiQueL PRO - i with solenoid valve for independent 3135515 3135555 3135516 3135556 control 3135517 3135557 3135518 3135558 3135521 3135561 3135522...
Page 9 DESCRIPTION CODE DESCRIPTION 1525430 MiQueL PRO - Modular element 0020566 Tank pressure gauge 1525440 MiQueL PRO - Modular element 5717232 Ø3 OIL outlet pipe 1525450 MiQueL BASE - Modular element 5717301 Ø6 AIR outlet pipe 1525460 MiQueL BASE - Modular element 3226664 Oil MK 150 20 lt.
Page 10: Dimensions
12. DIMENSIONS...
Page 11: Handling And Transportation
13. HANDLING AND TRANSPORTATION Before shipping, the units are carefully packed inside cardboard boxes. When transporting and storing the equipment, pay attention to the direction indicated on the boxes themselves. Upon receipt, check that the package has not been damaged and store the equipment in a dry location. Lift the equipment according to the direction shown on the cardboard package.
Page 12: Operating Hazards
• Use of unsuitable lubricant: The specifications of the lubricant are indicated both on the unit as well as in this User and maintenance manual (in the case of doubt, contact the Dropsa S.p.A technical office.). FLUIDS THAT ARE NOT PERMITTED...
