- Page 1 High Wall Series Te c hni c al IOM Man u al...
- Page 2 Your projects, challenges and requirements are our focus. We have a dedicated team that can engineer tailored solutions for your commercial HVAC application. Oceania Solutions Group is an Oceania Solutions Group are proud of our extensive portfolio and experience within HVAC industry. From industrial applications through Australian owned business that to commercial air conditioning installations for tropical and high humidity environments.
- Page 3 Contents Product technical data and dimensions General information Important notes Installation and maintenance manual Condensate drain pump IR wireless remote control Wiring HW+IR control+V connection Wiring HW+A70/D+V connection Wiring HW+A70+V connection Notes High Wall Series | Technical IOM Manual...
- Page 4 Specialised products can be designed for individual projects with components such as EC motors or UVC lamps. All Euroclima terminals can be equipped with factory mounted controls. High Wall Series | Technical IOM Manual...
-
Page 5: Product Warranty
High wall (HW) HW 070-090-180 UNITA' TERMINALE IDRONICA A PARETE The Euroclima HW unit is the optimal solution for wall mounting in hotels, apartments and offices for summer cooling and winter heating. The units are equipped with elegant ABS casing, adjustable blades... -
Page 6: General Information
General Information The specialised features of the HW fan coil allow for a varienty of installation applications, from light commercial to hotels and apartments. The HW is a perfect and stylish solution for cooling and heating in any space. The ABS casing, high efficiency heat exchanger and finned coil has been specially designed and manufactured to make the unit as compact as possible. -
Page 7: Important Notes
Important notes Warning: the manufacturer and supplier are not responsible for Unit acceptance, handling and storage. the incorrect installation of hydraulic and electrical connections. • At the time of the delivery, please verify the correspondence Please carefully read this manual before installing and operating the between the order and the delivery docket. - Page 8 Basic requirements for installation position Rear panel installation Installation in the following places can cause malfunctions. If it is • Always mount the real bracket panel horizontally using an accurate unavoidable, please contact a service center. level instrument. • Installations where strong heat sources, vapors, flammable gas or •...
- Page 9 Installation and maintenance manual HW 070-090-180 WALL HYDRONIC TERMINAL UNIT Installation The unit installation work must be completed by qualified personnel according to the local rules and this installation and operation manual. Before installing, please ensure you have contacted a local authorised installer or maintenance contractor.
- Page 10 Electrical connections Cleaning and maintenance The electrical connections must be performed by a qualified Before conducting any maintenance, make sure the power to specialist, according to the national electrical standards in the unit is turned off or disconnected. force (AS3000). Before making any connection the power It is recommended only a qualified specialist can intervene.
- Page 11 Points to control Possible causes Has the unit been secured to the wall correctly? The unit may drop, shake or emit noise or vibration Have you conducted a water leakage test? It may cause insufficient cooling/heating capacity Is application of cooling/heat insulation sufficient? It may cause condensation and cause water to drip Is water drainage sufficient? It may cause condensation and water pooling...
- Page 12 Condensate drain pump Flow curve rate Flow rate Volt Frequency SWL (at 30 cm) Absorption Insulation Power 230 V±10% 50-60 Hz < 26 dB(A) 62 mA Class B – IP54 Wall cabinet concealed pump and valves High Wall Series | Technical IOM Manual...
- Page 13 Manual for IR wireless remote control This wireless remote control is a universal type and it is employed for various types of terminal units use only the functions of the buttons that are described in this manual. Functions of wireless remote control Modes of unit operation: •...
- Page 14 COD: HW.T.V.01.14 HW+IR control+V connection Terminal Description Note: Valve power supply N 230V On the line of power supply always install differential switch and/or as required by national regulations and Valve consent L 230V respect neutral/phase. ON-OFF remote (ON-close / OFF-open) Power supply cable By customer care...
- Page 15 COD: HW.A70/D.01.14 HW+A70/D+V connection Terminal Description Earth Fan Common N MAX Speed L MED speed L MIN speed L N’ Valve common N Valve consent L Condenser 1μF HW 070 / 090 1.5μF HW 180 Note: On the line of power supply always install differential switch and/or as required by national regulations and respect neutral / phase.
- Page 16 COD: HW.A70/D.01.14 HW+A70+V connection Terminal Description Earth Fan Common N MAX Speed L MED speed L MIN speed L N’ Valve common N Valve consent L Condenser 1μF HW 070 / 090 1.5μF HW 180 Note: On the line of power supply always install differential switch and/or as required by national regulations and respect neutral / phase.
- Page 17 Did you know? Euroclima have an extensive range of interactive Eurovent certified software available to support you with all of your air handling units and fan coil unit needs. Notes High Wall Series | Technical IOM Manual...
- Page 18 Recent projects Westfield James Cook Coomera University Queensland Queensland Canterbury Leagues Club New South Wales Gold Coast Private Bendigo Animal Hospital Hospital Queensland Victoria Kirwan High School Queensland For more information on our latest projects, visit www.oceania-group.com PO Box 429 Cannon Hill QLD 4170 Click to follow our socials...
