- Page 1 FUSION-AUDIT-ZVK INSTALLATION GUIDE FUSION-AUDIT-ZVK FUSION-AUDIT-ZVK Installation Guide Issue 01...
-
Page 2: Table Of Contents
Contents INTRODUCTION ......................................... 3 FUSION-AUDIT-ZVK OVERVIEW ....................................4 INSTALLATION........................................... 5 CONFIGURATION MODE......................................7 REGISTRY CONFIGURATION ....................................9 ZSC-1000PLUS CONFIGURATION..................................10 USER CONFIGURATION......................................11 ZVK CONFIGURATION ......................................12 LOGGED COMMANDS......................................13 REQUIRED SOFTWARE ......................................14 SERVICING AND SUPPORT ....................................15 WARRANTY ..........................................16 MINIMUM SYSTEM REQUIREMENTS .................................. -
Page 4: Introduction
© 2005-6 ALL RIGHTS RESERVED. Meyertech, the Meyertech logo, Security with Vision, FUSION, the FUSION logo, ZoneVu, the ZoneVu logo are either registered trademarks or trademarks of Meyertech limited incorporated in the United Kingdom and/or other countries. MEYERTECH LIMITED... -
Page 5: Fusion-Audit-Zvk Overview
Access is required to a dedicated serial port, through which the application communicates with the Meyertech Site Controller. See installation diagram overleaf. Operating Mode FUSION-AUDIT-ZVK is an application that operates in the background on your PC or Workstation. Once the application is configured and running no user input is required. IMPORTANT ! -
Page 6: Installation
FUSION-AUDIT-ZVK Installation Guide Issue 01 Page 5 of 21 Installation Basic Installation - No Fusion Workstations ZVK-77 Fusion Audit ZVK and Fusion Audit RS232 ZoneVu ZSC-1000 FUSION-WS ZVK-77 Advanced Installation - Fusion Workstations ZVK-77 Fusion Audit ZVK RS232 FUSION FUSION-WS... - Page 7 The commands are stored in a file that is understood by FusionAudit. FusionAudit, running independently will import and truncate this log to produce the audit log. Current Status This dialog will report the current status of the connection between FUSION-AUDIT-ZVK and the Meyertech ZoneVu CCTV system. User Options Before any user options can be selected, the operator must Log On.
-
Page 8: Configuration Mode
Only those operators of the correct login priority will be allowed to access the configuration. Workstation This number identifies the FUSION-AUDIT-ZVK application as a virtual workstation. It should therefore be different to any other Fusion Workstations on the CCTV system. See the Registry Configuration section for further details. - Page 9 Page 8 of 21 MAC Address Barring This section allows the user to specify which MAC addresses should not be audited by FUSION-AUDIT-ZVK. This is done via the MAC Address Barring dialog. This screen lists the available MAC addresses on the system. For each of the available MAC addresses there is a tick box which the user can use to specify whether the selected MAC address is audited.
-
Page 10: Registry Configuration
Page 9 of 21 Registry Configuration The two registry entries that need to be configured for FUSION-AUDIT-ZVK can be modified by using the registry editor. The registry editor can be launched by selecting the Start Menu in Windows and then clicking “Run…”... -
Page 11: Zsc-1000Plus Configuration
Page 10 of 21 ZSC-1000plus Configuration The PC2 port of the ZSC-1000plus site controller must be enabled for use with FUSION-AUDIT-ZVK. This is done using Meyertech’s Mpower software to select the “Audit Mode” option on the PC2 port. The default baud rate of 9600 baud should also be selected. -
Page 12: User Configuration
Page 11 of 21 User Configuration In order for FUSION-AUDIT-ZVK to effectively audit a CCTV system it is very important to ensure that the user lists are synchronised correctly between the keyboard and FusionAudit. To synchronise the users from the Fusion user list to FusionAudit is a two step process. Firstly the user list has to be exported using FusionEdit. -
Page 13: Zvk Configuration
Page 12 of 21 ZVK Configuration While FUSION-AUDIT-ZVK will audit any Meyertech ZVK keyboard it is important to note that only the ZVK-77D supports User Synchronisation. This means that while the ZVK-77D will log commands associated with a particular user, other keyboards will log commands associated with the actual keyboard itself (keyboards 1-12 are supported). -
Page 14: Logged Commands
Page 13 of 21 Logged Commands FUSION-AUDIT-ZVK generates FusionAudit compatible log files. If all applications are correctly configured and synchronised then a full audit of the operator commands on the ZVK keyboards, when running in either PCI or Classic mode, will be produced. -
Page 15: Required Software
The following software versions are required from Meyertech for FUSION-AUDIT-ZVK. FusionAudit 1.6.1.0 and Later This will be used to synchronise the user lists and will be used to view the data that is gathered by FUSION-AUDIT-ZVK. FUSION-AUDIT-ZVK 1.0.0.0 and Later This will be used to audit the CCTV network. -
Page 16: Servicing And Support
Meyertech offer comprehensive levels of support during the product’s warranty period. Our support team will be happy to help with any problem you may experience relating to the installation or operation of FUSION-AUDIT-ZVK. 1. Telephone support (+44(0)161 628 8406 ), which is available during normal office hours 9AM – 5PM Monday to Friday excluding Bank holidays. -
Page 17: Warranty
FUSION-AUDIT-ZVK Installation Guide Issue 01 Page 16 of 21 Meyertech Limited is a member of the CCTV User Group. Warranty Please refer to Meyertech Limited ‘Terms & Conditions of Sale of Goods & Services’ for interpretation. 1. If the Buyer establishes to the Seller's reasonable satisfaction that there is a defect in the materials or... - Page 18 FUSION-AUDIT-ZVK Installation Guide Issue 01 Page 17 of 21 Buyer of all obligation to pay the sum by the issue of a credit note in favour of the Buyer in the amount of such price. 6. In respect of all Goods supplied to the Seller by a Third Party Supplier the Seller will on request pass on to the...
-
Page 19: Minimum System Requirements
Page 18 of 21 Minimum System Requirements The minimum recommended PC hardware to run FUSION-AUDIT-ZVK is dictated by the Operating System you are running. i.e. that recommended by Microsoft for running a particular Operating System. FUSION-AUDIT-ZVK also requires: 1. One free Serial RS232 port 2. - Page 20 ETC Fault Logging and Reporting In order for faults to be fixed in future releases of Windows and FUSION-AUDIT-ZVK it is important that all faults are logged and reported to Meyertech. When you experience a fault please note down as much information as you can about the status of the system when the fault occurred IE: •...
- Page 21 Page 20 of 21 Recovery from a Major Fault Recovery from a more serious fault may mean you cannot exit FUSION-AUDIT-ZVK. In this case follow the procedure below: 1. Locate the PC keyboard and press Ctrl, Alt, Delete simultaneously. 2. A pop-up window will appear giving you the option to end applications, which are currently running.
