  • Page 1 PACK 11...
  • Page 2 PAGE PHASE The winch The internal planking 02 Lateral support 04 Lateral support 05 The winch column 02 The strips for the upper deck 01 Positioning the cables support 01 Positioning the cables support 02 Cables supports 03 Design and production by Incipit srl Assembly guide edited by Milanoedit srl - www.milanoedit.com Published in Italy by De Agostini Publishing Italia S.p.A., 28100 Novara, Via G.
  • Page 3 PAGE PHASE The strips for the upper deck 02 Positioning the winch The bulwarks 01 The bulwarks 02 The bulwarks 03 The bulwarks 04 The bulwarks 05 The bulwarks 06 The bulwarks 07 Design and production by Incipit srl Assembly guide edited by Milanoedit srl - www.milanoedit.com Published in Italy by De Agostini Publishing Italia S.p.A., 28100 Novara, Via G.
  • Page 4 PAGE PHASE The bulwarks 08 The bulwarks 09 The bulwarks 10 The bulwarks 11 The bulwarks 12 The bulwarks 13 The stern 01 The stern 02 The bow’s details Design and production by Incipit srl Assembly guide edited by Milanoedit srl - www.milanoedit.com Published in Italy by De Agostini Publishing Italia S.p.A., 28100 Novara, Via G.
  • Page 5 PAGE PHASE The base The bulwarks 14 The bulwarks 15 The culverins supports The stern’s details 01 The stern’s details 02 The stern’s details 03 The stern’s details 04 Design and production by Incipit srl Assembly guide edited by Milanoedit srl - www.milanoedit.com Published in Italy by De Agostini Publishing Italia S.p.A., 28100 Novara, Via G.
  • Page 6 PACK 11 ASSEMBLY INSTRUCTIONS PACK 11 List od Components wooden tablet 11-01 wooden tablet 11-07 wooden tablet 11-02 wooden tablet 11-08 wooden tablet 11-03 wooden tablet 11-09 wooden tablet 11-04 wooden tablet 11-10 wooden tablet 11-05 wooden tablet 11-11 wooden tablet 11-06 wooden tablet 11-12 N.B.: at the end of this session, keep the leftover pieces from...
  • Page 7 PACK 11 PHASE 100 THE wINCH To make the winch, carefully follow the assembly sequences shown on these pages. Always apply a drop of glue to join each piece to the preceding piece.
  • Page 8 PACK 11...
  • Page 9 PACK 11...
  • Page 10 PACK 11...
  • Page 11 PACK 11...
  • Page 12 PACK 11...
  • Page 13 PACK 11...
  • Page 14 PACK 11...
  • Page 15 PACK 11...
  • Page 16 PACK 11...
  • Page 17 PACK 11...
  • Page 18 PACK 11...
  • Page 19 PACK 11...
  • Page 20 PACK 11...
  • Page 21 PACK 11...
  • Page 22 PACK 11...
  • Page 23 PACK 11...
  • Page 24 PACK 11...
  • Page 25 PACK 11...
  • Page 26 PACK 11...
  • Page 27 PACK 11...
  • Page 28 PACK 11...
  • Page 29 PACK 11...
  • Page 30 PACK 11...
  • Page 31 PACK 11...
  • Page 32 PACK 11...
  • Page 33 PACK 11...
  • Page 34 PACK 11...
  • Page 35 PACK 11...
  • Page 36 PACK 11...
  • Page 37 PACK 11...
  • Page 38 PACK 11...
  • Page 39 PACK 11...
  • Page 40 PACK 11...
  • Page 41 PACK 11...
  • Page 42 PACK 11...
  • Page 43 PACK 11...
  • Page 44 PACK 11...
  • Page 45 PACK 11...
  • Page 46 PACK 11 Now file off the edges of the pieces highlighted in red, until you have obtained a continuous surface. Then continue with the assembly of the winch, carefully studying the drawings on the following pages.
  • Page 47 PACK 11...
  • Page 48 PACK 11...
  • Page 49 PACK 11...
  • Page 50 PACK 11...
  • Page 51 PACK 11 Paint pieces A4B and A4T black and then join them to the rest of the winch.
  • Page 52 PACK 11...
  • Page 53 PACK 11 PHASE 101 THE INTERNAL PLANkINg 02 Take a 1.5 x 6 x 250 mm strip that you received in pack 07. Cut a 90 mm long segment of this strip and glue it at the position shown.
  • Page 54 PACK 11 Cut another 90 mm long segment from the same strip, and glue it at the position shown.
  • Page 55 PACK 11 Take another 1.5 x 6 x 250 mm strip. Cut a 90 mm long segment of this strip and glue it at the position shown.
  • Page 56 PACK 11 Cut another 90 mm long segment from the same strip, and glue it at the position shown. Then finish the edges of the planking until you obtain a smooth, continuous surface.
  • Page 57 PACK 11 PHASE 102 LATERAL SUPPORT 04 To make this new lateral support, carefully follow the assembly sequences shown on these pages. Always apply a drop of glue to join the pieces together.
  • Page 58 PACK 11...
  • Page 59 PACK 11...
  • Page 60 PACK 11...
  • Page 61 PACK 11...
  • Page 62 PACK 11 Take the lateral support you just made, and paint it black.
  • Page 63 PACK 11 Join the lateral support to the rest of your model, applying a drop of glue to the parts highlighted in red.
  • Page 64 PACK 11 2,5MM Position the lateral support, carefully observing the measurements shown in the illustrations.
  • Page 65 PACK 11 2,5MM...
  • Page 66 PACK 11...
  • Page 67 PACK 11 PHASE 103 LATERAL SUPPORT 05 To make this new lateral support, carefully follow the assembly sequences shown on these pages. Always apply a drop of glue to join the pieces together.
  • Page 68 PACK 11...
  • Page 69 PACK 11...
  • Page 70 PACK 11...
  • Page 71 PACK 11...
  • Page 72 PACK 11 Take the lateral support you just made, and paint it black.
  • Page 73 PACK 11 Join the lateral support to the rest of your model, applying a drop of glue to the parts highlighted in red.
  • Page 74 PACK 11 2,5MM POPPA Position the lateral support, carefully observing the measurements shown in the illustrations.
  • Page 75 PACK 11 2,5MM PRUA...
  • Page 76 PACK 11...
  • Page 77 PACK 11 PHASE 104 THE wINCH COLUMN 02 Retrieve the winch column you assembled in pack 09. Join it to the rest of the model, following the instructions given on these pages.
  • Page 78 PACK 11...
  • Page 79 PACK 11 PHASE 105 THE STRIPS fOR THE UPPER dECk 01 Recover three of the 1.5 x 6 x 250 mm strips that you received in Pack 07. Cut them according to the measurements shown and glue them at the positions shown in red.
  • Page 80 PACK 11 Remove the strip segments that are present in the areas shown in red.
  • Page 81 PACK 11 Place additional strips to form a row of planking to either side of the central row, as shown. Remove the strip segments that are present in the areas highlighted in red.
  • Page 82 PACK 11 PHASE 106 POSITIONINg THE CABLES SUPPORT 01 Retrieve the cables support 01 that you assembled in pack 09, and join it to the rest of the model as shown on the drawings on the next page.
  • Page 83 PACK 11...
  • Page 84 PACK 11 PHASE 107 POSITIONINg THE CABLES SUPPORT 02 Retrieve the cables support 02 that you assembled in pack 09, and join it to the rest of the model as shown on the drawings on the next page.
  • Page 85 PACK 11...
  • Page 86 PACK 11 PHASE 108 CABLES SUPPORTS 03 Remove all the PM1 and PM2 pieces from tablet 8-10. Work them with a small file until you obtain the result shown in the drawings. Then join them to the rest of the model as shown on the following pages.
  • Page 87 PACK 11...
  • Page 88 PACK 11...
  • Page 89 PACK 11 PHASE 109 THE STRIPS fOR THE UPPER dECk 02 Recover the rest of the 1.5 x 6 x 250 mm strips that you received in Pack 07. Continue constructing the upper deck planking following the measurements indicated on the following pages. Remove the strip segments that are present in the areas shown in red.
  • Page 90 PACK 11...
  • Page 91 PACK 11...
  • Page 92 PACK 11...
  • Page 93 PACK 11...
  • Page 94 PACK 11...
  • Page 95 PACK 11...
  • Page 96 PACK 11 All the strips have now been placed in position.
  • Page 97 PACK 11 PHASE 110 POSITIONINg THE wINCH Glue the winch to the rest of the model, at the position shown.
  • Page 98 PACK 11...
  • Page 99 PACK 11 The upper deck is now complete.
  • Page 100 PACK 11 PHASE 111 THE BULwARkS 01 Remove the STB pieces from tablet 11-08. Join them to the rest of your model as shown on the drawings.
  • Page 101 PACK 11...
  • Page 102 PACK 11...
  • Page 103 PACK 11 Now do the same with the four SVB pieces.
  • Page 104 PACK 11 PHASE 112 THE BULwARkS 02 Remove the STT pieces from tablet 11-09. Join them to the rest of your model as shown on the drawings.
  • Page 105 PACK 11...
  • Page 106 PACK 11 Now do the same with the four SVT pieces.
  • Page 107 PACK 11 PHASE 113 THE BULwARkS 03 To continue constructing the bulwarks, look carefully at the drawings on the following pages. Remove the pieces shown from their tablets, shape them as shown, and join them to the rest of the model.
  • Page 108 PACK 11...
  • Page 109 PACK 11...
  • Page 110 PACK 11...
  • Page 111 PACK 11...
  • Page 112 PACK 11...
  • Page 113 PACK 11...
  • Page 114 PACK 11...
  • Page 115 PACK 11 PHASE 114 THE BULwARkS 04 Altezza 3MM Continue constructing the bulwarks using the 1.5 x 6 x 250 mm strips that you received in pack 07. Join these to the rest of the model as shown and remove the parts highlighted in red, following the directions shown on the drawings.
  • Page 116 PACK 11...
  • Page 117 PACK 11...
  • Page 118 PACK 11...
  • Page 119 PACK 11 PHASE 115 THE BULwARkS 05 Altezza 3MM Continue constructing the bulwarks using the 1.5 x 6 x 250 mm strips that you received in pack 07. Join these to the rest of the model as shown and remove the parts highlighted in red, following the directions shown on the drawings.
  • Page 120 PACK 11...
  • Page 121 PACK 11...
  • Page 122 PACK 11...
  • Page 123 PACK 11 Make the frames of the cannon housings, using segments of 1.5 x 6 x 250 mm strips.
  • Page 124 PACK 11...
  • Page 125 PACK 11 PHASE 116 THE BULwARkS 06 Continue constructing the bulwarks, carefully following the drawings on these pages. Remove the pieces shown from their tablets and join them together as shown.
  • Page 126 PACK 11...
  • Page 127 PACK 11 Take the component you have just assembled and paint it black.
  • Page 128 PACK 11 PHASE 117 THE BULwARkS 07 Continue constructing the bulwarks, carefully following the drawings on these pages. Remove the pieces shown from their tablets and join them together as shown.
  • Page 129 PACK 11...
  • Page 130 PACK 11 Take the component you have just assembled and paint it black.
  • Page 131 PACK 11 Paint the component shown black.
  • Page 132 PACK 11 Join the components to the rest of the model at the position shown. File off any protrusions, if necessary.
  • Page 133 PACK 11 PHASE 118 THE BULwARkS 08 Continue constructing the bulwarks, carefully following the drawings on these pages. Remove the pieces shown from their tablets and join them together as shown.
  • Page 134 PACK 11...
  • Page 135 PACK 11...
  • Page 136 PACK 11 PHASE 119 THE BULwARkS 09 Continue constructing the bulwarks, carefully following the drawings on these pages. Remove the pieces shown from their tablets and join them together as shown.
  • Page 137 PACK 11...
  • Page 138 PACK 11...
  • Page 139 PACK 11 Cut two segments 22 mm long from a 1.5 x 6 x 250 mm strip and glue them at the positions shown.
  • Page 140 PACK 11 PHASE 120 THE BULwARkS 10 Take three 1.5 x 6 x 250mm strips. Join them to the rest of the model at the positions shown, applying a drop of glue at the points of contact.
  • Page 141 PACK 11 As shown, shape the tip of the strip that will be joined to the bow.
  • Page 142 PACK 11 Take three 2 x 2 x 250 mm strips that you received in pack 07. Paint them black and join them to the rest of the model at the positions shown, applying a drop of glue at the points of contact. As shown in the previous page, shape the tip of the strip that will be joined to the bow.
  • Page 143 PACK 11 PHASE 121 THE BULwARkS 11 Take three 1.5 x 6 x 250mm strips. Join them to the rest of the model at the positions shown, applying a drop of glue at the points of contact.
  • Page 144 PACK 11 Take three 2 x 2 x 250 mm strips. Paint them black and join them to the rest of the model at the positions shown, applying a drop of glue at the points of contact. As shown on page 922, shape the tip of the strip that will be joined to the bow.
  • Page 145 PACK 11 Remove the segment shown in red. To make the pieces shown above, use two segments of 1.5 x 6 x 250 mm strip, and glue them in position. File off the surfaces as shown.
  • Page 146 PACK 11 Repeat the same operations on the other side of the model.
  • Page 147 PACK 11 Temporarily remove the model from the shipyard; remove the stern support highlighted in red on the drawing. Reposition the model on the shipyard.
  • Page 148 PACK 11 PHASE 122 THE BULwARkS 12 Take three 1.5 x 6 x 250mm strips. Join them to the rest of the model at the positions shown, applying a drop of glue at the points of contact. As shown on page 922, shape the tip of the strip that will be joined to the bow.
  • Page 149 PACK 11 Ritagliate a sagoma Take three 1.5 x 6 x 250mm strips. Join them to the rest of the model at the positions shown, applying a drop of glue at the points of contact. As shown on page 922, shape the tip of the strip that will be joined to the bow.
  • Page 150 PACK 11 Ritagliate a sagoma Take three 1.5 x 6 x 250mm strips. Join them to the rest of the model at the positions shown, applying a drop of glue at the points of contact. As shown on page 922, shape the tip of the strip that will be joined to the bow. Remove the segment shown in red.
  • Page 151 PACK 11 Take three 1.5 x 6 x 250mm strips. Join them to the rest of the model at the positions shown, applying a drop of glue at the points of contact. As shown on page 922, shape the tip of the strip that will be joined to the bow.
  • Page 152 PACK 11 PHASE 123 THE BULwARkS 13 Take three 1.5 x 6 x 250mm strips. Join them to the rest of the model at the positions shown, applying a drop of glue at the points of contact. As shown on page 922, shape the tip of the strip that will be joined to the bow.
  • Page 153 PACK 11 Ritagliate a sagoma Take a 1.5 x 6 x 250 mm strip and divide it into two segments, taking the measurements directly on your model. Join these segments to the rest of the model at the positions shown, applying a drop of glue at the points of contact.
  • Page 154 PACK 11 Ritagliate a sagoma Take a 1.5 x 6 x 250 mm strip and divide it into two segments, taking the measurements directly on your model. Join these segments to the rest of the model at the positions shown, applying a drop of glue at the points of contact.
  • Page 155 PACK 11 Take a 1.5 x 6 x 250 mm strip and divide it into two segments, taking the measurements directly on your model. Join these segments to the rest of the model at the positions shown, applying a drop of glue at the points of contact.
  • Page 156 PACK 11 Take a 1.5 x 6 x 250 mm strip and divide it into two segments, taking the measurements directly on your model. Join these segments to the rest of the model at the positions shown, applying a drop of glue at the points of contact.
  • Page 157 PACK 11 VIII VIII Take a 1.5 x 6 x 250 mm strip and divide it into two segments, taking the measurements directly on your model. Join these segments to the rest of the model at the positions shown, applying a drop of glue at the points of contact.
  • Page 158 PACK 11 Take a 1.5 x 6 x 250 mm strip and divide it into two segments, taking the measurements directly on your model and referring to the drawing. Paint them black and join them to the rest of the model at the positions shown, applying a drop of glue to the contact points.
  • Page 159 PACK 11 Take a 1.5 x 6 x 250 mm strip and divide it into two segments, taking the measurements directly on your model and referring to the drawing. Paint them black and join them to the rest of the model at the positions shown, applying a drop of glue to the contact points.
  • Page 160 PACK 11 PHASE 124 THE STERN 01 Take a 1.5 x 6 x 250 mm strip and cut a segment of it, taking its measurements directly on the model. Glue it at the position shown, keeping to the same height as the levels of the bulwarks.
  • Page 161 PACK 11...
  • Page 162 PACK 11...
  • Page 163 PACK 11 For steps 7 and 8 you will need to make several short segments from a 1.5 x 6 x 250 mm strip. Join these to the rest of the model as shown.
  • Page 164 PACK 11 Riempimento...
  • Page 165 PACK 11 PHASE 125 THE STERN 02 Remove the components shown from their tablets, and join them to the rest of the model at the positions shown. Shape the stern strips as shown.
  • Page 166 PACK 11...
  • Page 167 PACK 11...
  • Page 168 PACK 11...
  • Page 169 PACK 11...
  • Page 170 PACK 11 PHASE 126 THE BOw’S dETAILS Detach the GH piece from tablet 10-09 and glue it at the position shown.
  • Page 171 PACK 11 Drill two holes at the positions indicated, of diameter approximately 3.5 mm and angled as shown in figure 3.
  • Page 172 PACK 11 PHASE 127 THE BASE Take the base for your model, which you assembled in pack 04, and paint it black. Remove the model from the shipyard and join it to the base.
  • Page 173 PACK 11 PHASE 128 THE BULwARkS 14 Take three 1.5 x 6 x 250mm strips. Join them to the rest of the model at the positions shown, applying a drop of glue at the points of contact. As shown on page 922, shape the tip of the strip that will be joined to the bow.
  • Page 174 PACK 11 VIII VIII VIII Take three 1.5 x 6 x 250mm strips. Join them to the rest of the model at the positions shown, applying a drop of glue at the points of contact. As shown on page 922, shape the tip of the strip that will be joined to the bow.
  • Page 175 PACK 11 PHASE 129 THE BULwARkS 15 3° 2° 1° Take three 1.5 x 6 x 250mm strips. Paint them black and join them to the rest of the model at the positions shown, applying a drop of glue at the points of contact. As shown on page 922, shape the tip of the strip that will be joined to the bow.
  • Page 176 PACK 11 3° 2° 1° Take three 1.5 x 6 x 250mm strips. Paint them black and join them to the rest of the model at the positions shown, applying a drop of glue at the points of contact. As shown on page 922, shape the tip of the strip that will be joined to the bow.
  • Page 177 PACK 11 PHASE 130 THE CULvERINS SUPPORTS Detach the CT pieces from tablet 11-08. Drill two blind holes in each piece, of diameter 0.5 Drill a hole in each piece, of diameter 1.2 mm and mm, at the positions shown. depth 5 mm, at the position shown.
  • Page 178 PACK 11 Take two nails, cut them to the required length, and insert them into the holes drilled on the side of one support. The nail heads must remain visible. Repeat the same operation for the other supports. Detach ten AC pieces from the photo-etching you Join an AC piece to each of the CT supports, at received in Pack 08.
  • Page 179 PACK 11 Join the CT supports to the rest of the model at the positions shown. If necessary, file off any protrusions from these pieces.
  • Page 180 PACK 11 Detach the CB pieces from tablet 11-09. Drill two blind holes in each piece, of diameter 0.5 Drill a hole in each piece, of diameter 1.2 mm and mm, at the positions shown. depth 5 mm, at the position shown. Take two nails, cut them to the required length, Join an AC piece to each of the CB supports, at and insert them into the holes drilled on the side...
  • Page 181 PACK 11 Join the CB supports to the rest of the model at the positions shown. If necessary, file off any protrusions from these pieces.
  • Page 182 PACK 11 Detach the DT pieces from tablet 11-08. Drill two blind holes in each piece, of diameter 0.5 Drill a hole in each piece, of diameter 1.2 mm and mm, at the positions shown. depth 5 mm, at the position shown.
  • Page 183 PACK 11 Take two nails, cut them to the required length, and insert them into the holes drilled on the side of one support. The nail heads must remain visible. Repeat the same operation for the other support. Join an AC piece to each of the DT supports, at Join the DT supports to the rest of the model the position shown.
  • Page 184 PACK 11...
  • Page 185 PACK 11 Detach the DB pieces from tablet 11-09. Drill two blind holes in each piece, of diameter 0.5 Drill a hole in each piece, of diameter 1.2 mm and mm, at the positions shown. depth 5 mm, at the position shown.
  • Page 186 PACK 11 Take two nails, cut them to the required length, and insert them into the holes drilled on the side of one support. The nail heads must remain visible. Repeat the same operation for the other support. Join an AC piece to each of the DB supports, at Join the DB supports to the rest of the model the position shown.
  • Page 187 PACK 11...
  • Page 188 PACK 11 PHASE 131 THE STERN’S dETAILS 01 BXL1 BXL2 BXL3 Detach the pieces shown from their tablets and join them together to begin creating the details of the stern of your model.
  • Page 189 PACK 11 BXL1 BXL2 BXL3 BXL3 BXL1 BXL2 File off the edges of the pieces at a 45° angle. BXL3 BXL3 BXL1 BXL2 BXL2 BXL1...
  • Page 190 PACK 11 Detach the CXB pieces from tablet 6-04 and glue Remove the excess part of these pieces. the templates as shown.
  • Page 191 PACK 11 File the surface of the pieces to give them a certain convexity. Then remove the template.
  • Page 192 PACK 11 Join the CXB pieces to the BXB piece as shown.
  • Page 193 PACK 11 BXL1 BXL2 BXL3 Detach the BLC pieces from the tablet 7-04 and join them to the rest of the group, as shown.
  • Page 194 PACK 11 Join the assembly to the rest of the model, at the position shown.
  • Page 195 PACK 11 PHASE 132 THE STERN’S dETAILS 02 Detach the SXB piece from tablet 11-06 and paint it black.
  • Page 196 PACK 11 Join the SXB piece to the rest of the model, at the position shown.
  • Page 197 PACK 11 PHASE 133 THE STERN’S dETAILS 03 BXR1 BXR2 BXR3 Detach the pieces shown from their tablets and join them together to continue creating the details of the stern of your model.
  • Page 198 PACK 11 BXR1 BXR2 BXR3 BXR3 BXR1 BXR2 File off the edges of the pieces at a 45° angle. BXR3 BXR3 BXR1 BXR2 BXR2 BXR1...
  • Page 199 PACK 11 Detach the CXT pieces from tablet 6-04 and glue Remove the excess part of these pieces. the templates as shown.
  • Page 200 PACK 11 File the surface of the pieces to give them a certain convexity. Then remove the template.
  • Page 201 PACK 11 Join the CXT pieces to the BXT piece as shown.
  • Page 202 PACK 11 BXR1 BXR2 BXR3 Detach the BRC pieces from the tablet 7-03 and join them to the rest of the group, as shown.
  • Page 203 PACK 11 Join the assembly to the rest of the model, at the position shown.
  • Page 204 PACK 11 PHASE 134 THE STERN’S dETAILS 04 Detach the SXT piece from tablet 11-06 and paint it black.
  • Page 205 PACK 11 Join the SXT piece to the rest of the model, at the position shown.
