- Page 1 MODEL ML393D MULTIPLE USE WOODWORKING MACHINE SERVICE MANUAL...
- Page 2 CAUTION 1 The use of any machine tool with electric drive can involve risks of damage to persons or things. It is therefore necessary to read this manual carefully before starting the machine. 2 To adjust and maintain after stopping the machine and take the plug off the socket.
- Page 3 1 Usage This machine is convenient and reliable due to its mulupl.e functions such as surface planer, press . planer, wood sawing. circular hole. Drilling. Square m ortises chis e ling as \Veil as c i rcular saw grinding and so on. Because the spindle of sawing and planer is separated, the operation is convenient and safety.
- Page 4 ch he 1s working. Before starting 1he machine. carefully read this manual. • The use of any machine tool with electric drr,·e can involve nsks of damage to persons or things It is therefore necessar to always p,n the i..:tmost anentmn. •...
- Page 9 • Grooving Preparation: Stop the machme. move the clutch bar t.o sawmg pos1t1on. Repeat sawmg process by changing position of the single blade sawing depth determined by lifung u p the bench of circular saw. Leading and locaung can be achieved by mak i ng use of the lead bar.
- Page 10 convenience of removing the chip. the drill must be withdrawn frequently . • Tool Sharpening Lower mortise-chiseling bench, dismount supporting stand of the square chisel, fix the special use grinding wheel shaft to the drill chuck tightly, and fit the grinding wheel to the shaft. Move the bench horizontal towards the grinding wheel.
- Page 11 ------- -- -- -------- --- - - --· - ·- ··--· -· .. ·· - - - - - - 7 Maintenance & Attendance Clear the wood flour and accumulauons on the machine 1mmedtately after operating for service life of the machine and processing qual i ty. Check and maintain the machine parts and electric elements periodically.
