- Page 1 Viper 220 MAX Installation guide Recreational Vehicle Security System Part # 322VTT Rev.2006 B © 2005 Directed Electronics, Inc. (Canada), CA N321V 04-2005...
-
Page 2: Table Of Contents
Basic Wiring Guide ..........20 © 2005 Directed Electronics, Inc. (Canada) -
Page 3: What Is Included
H1/7 ______ BLACK (-) CHASSIS GROUND INPUT H1/8 ______ H1/9 YELLOW (+) IGNITION INPUT, ZONE 5 ______ H1/10 BROWN (+) SIREN/HORN OUTPUT ______ H1/11 (+) 12V CONSTANT POWER INPUT ______ H1/12 RED/WHITE NOT USED © 2005 Directed Electronics, Inc. (Canada) -
Page 4: Primary Harness (H1), 12-Pins Connector Wiring Description
This wire supplies a (-) 500 mA ground as long as the system is armed. This output ceases as soon as the system is dis- armed. The orange wire is pre-wired to control the Directed Electronics 8618 Starter Kill relay included. - Page 5 “ON” position also while cranking and will show 0 volts when in the “OFF” position. If no 12 volts shows while cranking, please select another ignition source. H1/10 BROWN (+) Siren output Connect the brown wire of the security system to the (+) activation wire of the backup siren. © 2005 Directed Electronics, Inc. (Canada)
-
Page 6: Some Important Notes
If the recreational vehicle is used peri- odically, we recommend that you acquire a low current battery charger / maintainer to preserve the vehicle’s battery life span. © 2005 Directed Electronics, Inc. (Canada) -
Page 7: Plug-In Accessories Connector
The receiver/antenna connects to the 4-pin White connector on the side of the security system. If the receiver/antenna is not properly connected to the security system no signal will be received. The security system will not operate if the receiver/antenna is disconnected. © 2005 Directed Electronics, Inc. (Canada) -
Page 8: Wiring An Digital Tilt Sensor
Blue (-) To INSTANT trigger input, zone 4 Tilt Sensor NOTE! The digital Tilt sensor must be installed horizontally with DEI 507M writing facing up. Avoid installing the sensor on an angled or vertical position. © 2005 Directed Electronics, Inc. (Canada) -
Page 9: Transmitter Configuration
For additonnal protection, a 508D perimeter microwave sensor can be added to the security system. When installed with one of Directed Electronics security system could be interfaced with the shock sensor harness. The 508D has a dual stage trigger output, that will either Warn or trigger the security system, both wires the blue and the green are Multiplex. -
Page 10: 470T 2-Button Transmitter
Transmit. While holding the switch push in, press on the arm/disarm button of the first transmitter ( you will hear one long chirp). Press on the arm/disarm button of the second transmitter ( you will hear one long chirp again). © 2005 Directed Electronics, Inc. (Canada) - Page 11 (a long chirp will be heard). Press on the button of the second transmitter (a long chirp will be heard). Choose. Press two times on the Valet®/program push switch and hold it on the second time. The siren will chirp two times. © 2005 Directed Electronics, Inc. (Canada)
-
Page 12: System Features Learn Routine
998T Bitwriter®. To access system features learn routine: Green H 1/5 wire will need to be connected to ground for the learn routine to work. © 2005 Directed Electronics, Inc. (Canada) -
Page 13: System Features Descriptions
■ Turn the vehicle key to the “ON” position. ■ More than 15 seconds elapses between steps. ■ Valet®/Program switch is pressed too many times. System features descriptions MENU # 1 - BASIC FEATURES © 2005 Directed Electronics, Inc. (Canada) -
Page 14: Menu #1
Channel 3 - Latch/Latch reset with ignition/ 30 seconds timed MENU # 1 1-2 CONFIRMATION CHIRPS ON/OFF This feature controls the chirps that confirm the arming and disarming of the system. 1-5 PANIC MODE ON IGNITION ON/OFF © 2005 Directed Electronics, Inc. (Canada) -
Page 15: Menu #2
If NPC is turned OFF, the system will respond to repeated triggers on the sensor inputs and will do so indefinitely 2-5 DISARM PULSES 1 TO 5 © 2005 Directed Electronics, Inc. (Canada) -
Page 16: Once A Feature Is Programmed
To select another menu: 1. Press and HOLD the Valet/Program switch. 2. After three seconds, the unit will advance to the next menu and the siren will chirp, indicating which menu has been accessed. © 2004 Directed Electronics, Inc. (Canada) - Page 17 ■ Turn the ignition “ON” ■ No activity for longer than 15 seconds. ■ Pressed the Valet®/Program switch too many times. A long chirp will confirm that you have exited the learn routine mode. © 2004 Directed Electronics, Inc. (Canada)
- Page 18 © 2005 Directed Electronics, Inc. Vista, CA...
