VIBCO DC Manual

12 & 24 volt battery operated
Hide thumbs
Table of Contents

Advertisement

Quick Links

Model DC
Specifications • Mounting Instructions • Operating Instructions
Parts List • Dimensions • Maintenance •Technical Data
HQ & Factory:
Canada:
75 Stilson Road
2215 Dunwin Drive
Wyoming, RI 02898
Mississauga, ONT L5L 1X1
E-mail: vibrators@vibco.com
E-mail: vibrators@vibco.com
Phone: 800 633-0032
Phone: 800 465-9709
(401) 539-2392
Fax:
(401) 539-2584
Fax:
12 & 24 Volt
Battery Operated
(905) 828-4191
(905) 828-5015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC and is the answer not in the manual?

Questions and answers

Related Manuals for VIBCO DC

Summary of Contents for VIBCO DC

  • Page 1 Model DC 12 & 24 Volt Battery Operated Specifications • Mounting Instructions • Operating Instructions Parts List • Dimensions • Maintenance •Technical Data HQ & Factory: Canada: 75 Stilson Road 2215 Dunwin Drive Wyoming, RI 02898 Mississauga, ONT L5L 1X1 E-mail: vibrators@vibco.com...

  • Page 2: Table Of Contents

    Thank you for choosing VIBCO, Inc. for your vibration needs. You are now the owner of the finest 12 volt DC battery operated vibrator available today backed by complete manufacturer confidence in its quality and dependability.

  • Page 3: Warning Labels And Serial Number Tags

    Avant de travailler sur l`appareil, débrancher la source d`alimentation Please have the information on this tag ready when ordering parts or contacting the technical service department at VIBCO. Location: On top of conduit box. DC-3500: Sticker on round motor. PHONE: 1-800-633-0032 FAX: 1-401-539-2584 WWW.VIBCO.COM...

  • Page 4: Dc-3500 Mounting Instructions

    260 ft-lbs. Remove end cover on vibrator and spin shaft with finger, it should spin freely - if not, re-shim vibrator (does not apply to DC-60, DC-500, or DC-3500). Retighten the bolts after the first 10-15 minutes of running, then check them periodically for tightness. When mounting the DC-3500 secure vibrator with one bolt (use Loctite 242 or equal), and lock washer.
  • Page 5 DC-3500/5000 MOUNTING INSTRUCTIONS Saftey Cable Push-Button On panel Battery Positive Terminal Power Solenoid Cable Figure 1 Switch Flat Bed Dump Trucks and Tandem Trailers The vibrator should be located underneath the body, preferably 1/4 the body length from the front, or as close to this as possible, and centered between sills or main beams (see Figures 1 &...
  • Page 6 DC-3500/5000 MOUNTING INSTRUCTIONS Doghouse / Cylinder Figure 3 Tailgate Weld 4 in. channel over at least 3 stiffeners. Then weld vibrator mounting plate to channel. Doghouse / Cylinder Tailgate Figure 4 Weld 4 in. or 6 in. channel between main beams. Then weld sides and underneath of 5/8 in.
  • Page 7 DC-3500/5000 MOUNTING INSTRUCTIONS Figure 5 For smaller dump bodies stitch weld a 6 in. channel between cross members & to body (skip weld to body) & weld mounting plate to middle of channel iron. Doghouse / Cylinder Tailgate Figure 6 Weld 6 in.
  • Page 8 BOTH SIDES USE 3/4-10 x 2-1/2” GRADE 8 BOLTS 3”-6” KNOTCH MOUNTING 3” CHANNEL TO FIT 12” 9” 11-3/8” CENTER OF DC-3500/5000 MOUNTED AT 1/4 BODY LENGTH FROM THE FRONT OF DUMP BODY PHONE: 1-800-633-0032 FAX: 1-401-539-2584 WWW.VIBCO.COM VIBRATORS@VIBCO.COM REV295-13...
  • Page 9 OTHER DC MOUNTING INSTRUCTIONS Dump Body Cross Memberless Mounting. Center of vibrator should always be mounted at 1/4 of the body length from the front of the dump body. Plate Under Channel Figure 8 1. Align 13/16” holes in channel with the 3/4-10 tapped holes in 1500PF38 mounting plate.
  • Page 10 OTHER DC MOUNTING INSTRUCTIONS The Length of the Channel Iron is determined by the thickness of the bin plate. For 3/16 in. to 3/8 in. thick plate, use 3 ft. to 5 ft. long channel. If the bin plate is under 3/16 in. thick, use channel equal to the length of the bin or at least 6 ft.
  • Page 11 OTHER DC MOUNTING INSTRUCTIONS 4” CHANNEL 3/8” GUSSETS 4”x 4” TUBING Figure 15 MOUNTING PLATE VIBRATOR Double Hopper. Weld 4 in. channel to inside slopes of hoppers. Stop welds 1 in. from ends. Weld a 4 in. square piece of tubing between channel. Weld mounting plate to the center of the tubing and add 3/8 in.
  • Page 12 CUSTOM MOUNTING APPLICATIONS VIBCO’s application specialists provide general instructions and guidelines for the installation of our vibrators on customer equipment. These instructions and guidelines are based on the industries best practices and years of experience in applying vibrators.

  • Page 13: Operating Instructions

    All DC vibrator bearings are pre-lubricated to last for the life of the vibrator. ADJUSTING ECCENTRICS Models DC-20, 50, 60, 450, 500, 700 have a fixed force settings and cannot be adjusted. DC- 100 has a single end for adjustment as shown below. DC-200, DC-300, DC-900 and DC-1600 have eccentrics on both ends of the motor.
  • Page 14 Figure 20 Figure 21 CHANGING/ADJUSTING ECCENTRICS DC-3500 & DC-5000 Model DC-3500 also has adjustable eccentrics. For reference turn to page 14 for more detail. To change these eccentrics: 1. Unscrew (2) 3/8-16 x 6-1/2 hex head bolts. 2. Remove dust cover.
  • Page 15 DC-3500 Eccentric Settings Factory Settings Force = 3500 lbs Dump body lengths 17 ft & up Force = 3000 lbs Dump body lengths 15 - 16 ft 60° Force = 2500 lbs Dump body lengths 13 - 14 ft 90°...

  • Page 16: Electrical Installation

    ELECTRICAL INSTALLATION DC-20, DC-50,DC-60 JUNIOR The DC-20 vibrator is a low amperage unit that can be wired directly through a toggle switch. One lead connects to positive, the other to negative. One of the leads can be connected to the body on body grounded applications.

  • Page 17: Electrical Installation Procedure

    ELECTRICAL INSTALLATION PROCEDURE The electrical hook-up consists of two circuits, a master circuit and a pilot circuit (except DC-20, see previous page). The master circuit supplies the motor with current and must be able to carry the vibrators rated amperage. The pilot circuit is the controlling circuit, and carries only a small current between the switch on the dashboard and the solenoid, connecting or disconnecting the master circuit.

  • Page 18: Wiring Diagrams

    16 MTW 16 MTW Ground Ground Battery 12 Volt DC DC-100, DC-200, DC-300, DC-450 Wiring Diagram 2 DC-500, DC-700, DC-900 & DC-1600 WK-1, WK-2 Push Button Switch On/Off Toggle Switch 16 MTW 16 MTW To Ignition Switch Controlled Power Source (Fused)
  • Page 19 Refer to Wiring Diagrams 1 & 2 for correct wire sizes according to vibrator model Ground Battery 12 Volt DC DC Vibrator Signal from cab to operate Starter Motor on spreader gasoline engine that powers hydraulic pump Solenoid Switch that activates...
  • Page 20 The CB12V (figure 22) thermal overload circuit breakers are designed to be used in the main circuit of VIBCO’s DC-3500 dump body vibrator to prevent operators from running the vibrator in excess of its maximum continuous running time of 30 seconds, which can cause premature failure.

  • Page 21: Troubleshooting

    2.) Vibrator is running slow (loss of RPM). Measure motor voltage. If less than 12 volts DC, wire size should be increased. Check the brushes and change if necessary. The life of the brushes is approximately 1,000 hours.

  • Page 22: Technical Data And Dimensions

    9-1/4 9-1/2 1-3/8 7-3/8 188 DC-5000 13-1/2 10-3/4 274 6-13/16 1-1/2 *Bolt Size Note: Data and dimensions subject to change without notice. DC-20, DC-50, DC-100 DC-450, DC-700 DC-60 DC-200, DC-300, DC-900 DC-500 DC-1600 DC-3500 DC-5000 PHONE: 1-800-633-0032 FAX: 1-401-539-2584 WWW.VIBCO.COM VIBRATORS@VIBCO.COM...
  • Page 23 4000 75.0 34.0 SPECIAL *Amps shown for 12 Volt DC (24 volt amps 1/2 of 12 volts, except DC-3500 & 5000) **Decibel on A-scale at 3’ (1 meter) Note: Data and dimensions subject to change without notice. NOTE: For more...
  • Page 24 Model: DC-20 ITEM # PART # DESCRIPTION QTY. 10-24X1-5/8RH SCREW, ROUND HEAD MACHINE 10-24X3-3/4RH SCREW, ROUND HEAD MACHINE 10-24X1/2SS SCREW, SOCKET SET 10LW #10 LOCKWASHER 20SPR06-1 HOUSING (SPR-20) 20SPR07 ECCENTRIC 50SCR03 MOTOR PLATE 60DC07-1-2 MOTOR (DC-20, 50; 12V)
  • Page 25 PART # DESCRIPTION QTY. 10-24X1-5/8RH SCREW, ROUND HEAD MACHINE 10-24X3-3/4RH SCREW, ROUND HEAD MACHINE 1/4-20X3/16SSK SCREW, SOCKET SET (KNURLED) 10LW #10 LOCKWASHER 20SPR06-1 HOUSING (SPR-20) 40SP035 ECCENTRIC (SPR-40, 20M) 50SCR03 MOTOR PLATE 60DC07-1-2 MOTOR (DC-20, 50; 12V) 60CE12 BEARING COVER...
  • Page 26 DC-60 Model:...
  • Page 27 Model: DC-100...
  • Page 28 Model: DC-200 4 2 24 23 5 ITEM # PART # DESCRIPTION QTY. SE-1740 CABLE CONNECTOR 1/4-20X1/2SH SCREW, SOCKET HEAD CAP 1/4-20X1/2SS SCREW, SOCKET SET 1/4LW LOCKWASHER 10-24X1/2SEMS SCREW, ROUND HEAD MACHINE, W/LW&PATCH 10-24X1/2SS SCREW, SOCKET SET 100SCR10 SPACER 16/3 SO CORD (A.I.W.)
  • Page 29 Model: DC-300 4 12 7 5 18 3 19 8 27 ITEM # PART # DESCRIPTION QTY. SE-1740 CABLE CONNECTOR O-RING 1/4-20LN LOCKNUT 1/4-20X1/2SH SCREW, SOCKET HEAD CAP 1/4-20X1/2SS SCREW, SOCKET SET 1/4-20X7HH SCREW, HEX HEAD CAP 10-24X9/16RH SCREW, ROUND HEAD MACHINE...
  • Page 30 Model: DC-450T *ITEM NOT SHOWN...
  • Page 31 Model: DC-500...
  • Page 32 PHONE: 1-800-633-0032 FAX: 1-401-539-2584 WWW.VIBCO.COM VIBRATORS@VIBCO.COM REV295-13...
  • Page 33 Model: DC-700 *ITEM NOT SHOWN...
  • Page 34 Model: DC-900 5 25 14 15 17 18 19 ITEM # PART # DESCRIPTION SCREW, ROUND HEAD MACHINE 10-24x3/4SEMS 300US06-1 ENDBELL COVER 56VM38-1R GASKET, RUBBER 1/4-20X5/8SH SCREW, SOCKET HEAD CAP 1/4LW LOCK WASHER 900US36 ECCENTRIC, NUMBERED 900US35 ECCENTRIC, OUTSIDE 5/16-24HN...
  • Page 35 Model: DC-1600 ITEM # PART # DESCRIPTION 10-24X1SEMSV SCREW, ROUND HEAD MACHINE 48VM23-3 COVER 56VM38-2R GASKET, RUBBER 1/4-20X5/8SH SCREW, SOCKET HEAD CAP 1/4LW LOCK WASHER 1600US11 ECCENTRIC, ADJUSTABLE 1600US35 ECCENTRIC, OUTSIDE 1/4-20X1/2SS SCREW, SOCKET SET 3/8-24HN HEX NUT 3/8LW LOCK WASHER...

  • Page 36: Dc-3500 12 & 24 Volt

    Model: DC-3500 BIG BERTHA 12Volt 11 12 ITEM QTY PART NO DESCRIPTION 1500PF38 MOUNTING PLATE 1500PF82 HOUSING AND BEARING 5100-137 SNAP RING 1500PF32 ECCENTRIC 3/8-16X1/2SS SCREW, SOCKET SET 1500PF83 MTG COVER WITH BEARING 3/8BW BELLEVILLE WASHER 3/8-16X1-1/4HH SCREW, HEX HEAD CAP...
  • Page 37 Model: DC-3500-24V BIG BERTHA 24Volt ITEM PART NO DESCRIPTION 1500PF82 HOUSING AND BEARING 5100-137 SNAP RING 1500PF32 ECCENTRIC 1500PF33 MTG COVER WITH BEARING 3/8-16X1-1/4HH SCREW, HEX HEAD CAP 3/8-16X6-1/2HH SCREW, HEX HEAD CAP...
  • Page 38 SNAP RING 1500PF32 ECCENTRIC 3/8-16X1/2SS SCREW, SOCKET SET 1500PF33 MOUNTING COVER 3/8BW BELLEVILLE WASHER 3/8-16X1-1/4HH SCREW, HEX HEAD CAP 1500PF64-1 MOTOR ASSEMBLY, DC-5000 1500PF68-1 MOTOR ASSEMBLY, DC-5000-24V 1500PF44 MACHINE SCREW 1500PF41 BRUSH 1500PF42 PLASTIC BRUSH HOLDER 1500PF45 SPRING 1500PF43 METAL BRUSH HOLDER...

  • Page 39: Warranty And General Information

    Warranty All warranty claims must be submitted to VIBCO for approval prior to any repairs being done. Failure to do so will void any and all warranty coverage. All repairs will be done at the VIBCO factory. Errors, Shortages & Complaints Complaints concerning goods received or errors should be made at once.
  • Page 40 www.vibco.com...
