SP tools SP62020 User Manual

Infrared thermometer laser guided
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
AFTER SALES SUPPORT:
WWW.SPTOOLS.COM
IMPORTANT
ALL PERSONS WHO ARE TO USE THIS EQUIPMENT MUST THOROUGHLY READ
AND UNDERSTAND THIS INSTRUCTION MANUAL PRIOR TO OPERATION.
SP62020
INFRARED
THERMOMETER
LASER GUIDED
RETAIN THESE INSTRUCTIONS
AND ATTACH RECEIPT TO
MANUAL FOR FUTURE
NOTE: Proof of purchase must be retained by
the customer as it will be required in the
event of a claim under warranty.
AUSTRALIA: Visit the website's contact page to get in
touch with your local service department.
INTERNATIONAL: Use the county selector to get in touch
with your service department in your country or region.
REFERENCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP62020 and is the answer not in the manual?

Questions and answers

Related Manuals for SP tools SP62020

Summary of Contents for SP tools SP62020

  • Page 1 USER MANUAL SP62020 INFRARED THERMOMETER LASER GUIDED RETAIN THESE INSTRUCTIONS AND ATTACH RECEIPT TO MANUAL FOR FUTURE REFERENCE NOTE: Proof of purchase must be retained by the customer as it will be required in the event of a claim under warranty.

  • Page 2: Table Of Contents

    Notes Warranty Details INTRODUCTUCTION Thank you for purchasing the SP62020 IR (infrared) non-contact Thermometer. Capable of temperature measurements at the touch of a button. The built-in laser pointer increases target accuracy while the backlight LCD and handy push-buttons combine for convenient, ergonomic operation.

  • Page 3: Wide Ranging Application

    WIDE RANGING APPLICATION: Food preparation, Safety and Fire inspectors, Plastic molding, Asphalt, Marine and Screen printing, measure ink and Dryer temperature, HVAC/R, Diesel and Fleet maintenance. SAFETY  Use extreme caution when the laser beam is turned on.  Do not let the beam enter your eyes, another person’s eyes or the eyes of an animal.

  • Page 4: Specification

    SPECIFICATIONS Temperature range -50 to 650 °C (-58°F ~ 1202°F) 12:1 Display resolution 0.1 °C (0.1°F) <1000 1°F >1000 Accuracy for targets: Assumes ambient operating temperature of 23 to 25°C(73 to 77°F) -50 ~ 20°C (-58°F ~ 68°F) ±2.5°C (4.5°F) 20°C ~300°C (68°F ~572°F) ±1.0% ±1.0°C (1.8°F) 300°C ~650°C (572°F ~ 1202°F)

  • Page 5: Front Panel Description

    FRONT PANEL DESCRIPTION IR sensor LCD Display Laser pointer beam Up button Down button Mode button Measure trigger Battery Cover Handle Grip INDICATOR 1) Data hold 2) Laser “on” symbols 3) Lock symbol 4) High alarm and low alarm symbol 5) ˚C / ˚F symbol 6) Low power symbol 7) Emissivity symbol and value...
  • Page 6 Mode Button Function Pressing the mode button also allows you to access the EMS adjustment setings: Emissivity (EMS), Lock on/off, HAL on/off, HAL adjustment, LAL on/off, LAL adjustment. Each time you press set you advance through the mode cycle.The diagram shows the sequence of functions in the mode LOCK on/off cycle.

  • Page 7: Measurement Operation

    MEASUREMENT OPERATION 1) Hold the meter by the Handle Grip and point it toward the surface to be measured. 2) Pull and hold the Trigger to turn the meter on and begin testing. The display will light up if the battery is good. Replace battery if the display does not light up. 3) Release the Trigger and the HOLD display icon will appear on the LCD indicating that the reading is being held.

  • Page 8: Notes

    NOTES:  How it Works Infrared thermometers measure the surface temperature of an object. The unit’s optics sense emitted, reflected, and transmitted energy, which is collected and focused onto a detector. The unit’s electronics translate the information into a temperature reading, which is display on the unit.
  • Page 9 Emissivity Values Substance Thermal Substance Thermal emissivity emissivity Asphalt 0.90 to 0.98 Cloth (black) 0.98 Concrete 0.94 Human skin 0.98 Cement 0.96 Lather 0.75 to 0.80 Sand 0.90 Charcoal 0.96 (powder) Earth 0.92 to 0.96 Lacquer 0.80 to 0.95 Water 0.92 to 0.96 Lacquer 0.97...

  • Page 10: Warranty Details

    To the extent permitted by law and subject to this Limited Warranty, and as part of the terms of the sale of the equipment or part thereof: SP Tools shall not be liable for any form of loss, damage, cost, injury or harm of any kind (whether direct, indirect, special or consequential) howsoever arising from the use or supply of the equipment to the purchaser.
