USER MANUAL
AFTER SALES SUPPORT:
WWW.SPTOOLS.COM
IMPORTANT
ALL PERSONS WHO ARE TO USE THIS EQUIPMENT MUST THOROUGHLY READ
AND UNDERSTAND THIS INSTRUCTION MANUAL PRIOR TO OPERATION.
SP62022
MINI INFRARED
THERMOMETER
RETAIN THESE INSTRUCTIONS
AND ATTACH RECEIPT TO
MANUAL FOR FUTURE
NOTE: Proof of purchase must be retained by
the customer as it will be required in the
event of a claim under warranty.
AUSTRALIA: Visit the website's contact page to get in
touch with your local service department.
INTERNATIONAL: Use the county selector to get in touch
with your service department in your country or region.
REFERENCE
Advertisement
Table of Contents
Related Manuals for SP tools SP62022
Summary of Contents for SP tools SP62022
- Page 1 USER MANUAL SP62022 MINI INFRARED THERMOMETER RETAIN THESE INSTRUCTIONS AND ATTACH RECEIPT TO MANUAL FOR FUTURE REFERENCE NOTE: Proof of purchase must be retained by the customer as it will be required in the event of a claim under warranty.
- Page 2 CONTENTS Introduction Safety Information Panel Descriptions Specifications Operating Instructions Ambient Temperature Battery Replacement Limited Warranty INTRODUCTUCTION Introduction This meter is a convenient non-contact infrared thermometer with the functions of laser targeting, back light display, data hold and auto power off. Safety Information •...
- Page 3 Panel Descriptions 1. Infrared Sensor 2. LCD Display 3. Black Light Button 4. Ambient temp measurement button 5. Wrist Strap 6. Laser targeting aperture 7. Scan Button 8. °C/°F selection switch 9. Battery Cover LCD DISPLAY 1. Measurement indication 2. Low power indication 3.
- Page 4 Operating Instructions To measure an object’s temperature • Note size of the object to scan temperature. • Move the unit to the appropriate distance to scan its temp. i.e. For a 50mm object, you will need to be 300mm away. •...
- Page 5 To measure the ambient temperature (Please balance the heat of the instrument before use.) • Press the “SCAN” button to start the unit. • Press the “Tamb” button to select the ambient temperature measurement mode, and the sign of “Tamb” will appear on LCD, then press the “SCAN” button, the measured ambient temperature will be displayed on LCD.
- Page 6 To the extent permitted by law and subject to this Limited Warranty, and as part of the terms of the sale of the equipment or part thereof: SP Tools shall not be liable for any form of loss, damage, cost, injury or harm of any kind (whether direct, indirect, special or consequential) howsoever arising from the use or supply of the equipment to the purchaser.
