- Page 1 MYSTIC HD SYSTEM (MTM-2500HD) MAINTENANCE GUIDE DAILY, WEEKLY, MONTHLY 2009 MT Industries, Inc. All rights reserved MT Industries, Inc. 8909 S. Freeway Drive, Suite 100 Macedonia, OH 44056 877.668.8826 11/20/2009...
-
Page 2: Fault Sig N A L
M YST IC H D Qui c k G uide M T M 2 5 00 / 25 00H D 10 minutes a week / 20 minutes a month Basic maintenance will keep your Mystic running smoothly, all it takes is 10 minutes a week, 20 minutes a month. - Page 3 W e e kl y M ain t en a n c e Cle aning th e Guide R ail Cleaning the guide rail will ensure that the nozzle assembly moves smoothly up and down the tower and completes the tanning cycle. To access the back of the tower, remove the ring pin and swing the tower around to the left, then use the pull handle to remove the back panel from the tower.
- Page 4 W e e kl y M ain t en a n c e Cle aning th e In side & Out side E x h a u s t Filte r s Cleaning the fan filters will ensure the mist is evacuated from the booth correctly. EZ Fan Filter Assembly Inside Fan Cover...
- Page 5 Latches Flip latches to open the Fan door. Remove the blue and white filter material. Replace or clean filter before running booth again. 2009 MT Industries, Inc. All rights reserved MT Industries, Inc. 8909 S. Freeway Drive, Suite 100 Macedonia, OH 44056 877.668.8826 11/20/2009...
- Page 6 W e e kl y M ain t en a n c e Cle aning th e Str aine r S c r e e n a nd th e Flow Di s k Cleaning the strainer screen will ensure the cartridge empties completely during the tanning cycle. Wing Twist wing nut to clean the flow disk assy.
- Page 7 Weekly Maintenance Lift the filter upwards from it’s position. Rinse the filter using the wash down hose inside of the unit. Replace the filter with the foam side down. 2009 MT Industries, Inc. All rights reserved MT Industries, Inc. 8909 S. Freeway Drive, Suite 100 Macedonia, OH 44056 877.668.8826 11/20/2009...
- Page 8 M on thly M ain t en a n c e Cle an th e P ump Sump Ar e a a nd Floa t Switc h Cleaning the Pump Sump Area and Float Switch will ensure the pump evacuates water from the booth.
- Page 9 Dr ain th e Air Compres sor a nd Cle a n th e A ir Filter Fill Oil Air Filter Safety Valve Drain Valve Check Oil Turn off the main power to the air compressor. • Pull the safety valve to reduce the air pressure in the tank below 10PSI. •...
