Page 1
WPP-3500CX CONTACT WARRIOR TECH DEPARTMENT GASOLINE GENERATOR For any technical or faults please OWNERS MANUAL contact warrior direct on the following number or write: Warrior Power Products Ltd, 16 Winchester Road, Haydock Ind Est, St Helens, Merseyside, WA11 9XQ, UK Tel: 0044 (0)1942 528272 Email: sales@warriorpowerproducts.co.uk...
Page 2
WARNING Read the operator’s instruction manual. Attention! Exhaust gases are toxic. Do not operate the generator in a room without ventilation system! Children should be protected by keeping them at a safe distance from the generator set! Refi lling of the generating sets is not allowed during the operation! f the generator will be mounted in a closed room, relevant safety regulations against fi...
Page 3
2. CHECKS BEFORE OPERATING (1) CHECK THE ENGINE OIL LEVEL Notice: Stop the generator in a smooth place, then check the generator. Engine oil is a major factor aff ecting engine perfor- mance and life. Use the 4-stroke oil, SAE10W-40 is recommended for general, all-temperature use.
Page 4
3. STARTING THE ENGINE GASOLINE GENERATOR SET Disconnect any load from the AC socket and the DC output terminal, and turn off the AC circuit breaker. TYPE WPP-3500CX AC VOLTAGE 110/230V - 50 HZ AC OUTPUT (CONT) 2500 WATTS POWER FACTOR: 1.0...
Page 5
NO ELECTRICITY AT THE RECEPTACLES: 4. OPERATING METHODS OF GENERATOR In order to keep your generator in good condition, Please follow the rules: Avoid improper operation, make sure to make your generator ground connection. Electrical equipment, motor-driven devices will produce lots of electric current when they start. The following form will give you a reference when you connect them to generator.
Page 6
When you connect more than two loads on the generator, please connect from high electric cur- 8. TROUBLE SHOOTING rent to low electric current successively. When using extension lines or mobile distribution networks the total length of lines for a cross section of 1.5mm should not exceed 60m;...
Page 7
7. TRANSPORTING/STORAGE 5. STOPPING THE ENGINE Turn the AC circuit breaker to the OFF position. WARNING! When transporting the generator, turn the engine switch OFF and keep the generator level to prevent fuel spillage. Fuel vapour or spilled fuel may ignite. Before storing the unit for an extended period: Turn the engine switch to the OFF position Be sure the storage area is free of excessive humidity and dust.
Page 8
CHANGING OIL SPARK PLUG SERVICE Drain the oil while the engine is still warm to assure rapid and complete draining. Recommended spark plug: BP6ES, SPR6ES (NGK) F6TC, F6RTC Remove the drain plug and fi ller cap, and drain the oil. Retighten the plug securely. (LD).
