- Page 1 6 4 0 V 2 5 2 0 A H HIGH-VOLTAGE LITHIUM IRON PHOSPHATE BATTERY USER MANUAL Version 1.0 NEW ENERGY TECHNOLOGY -- LIFE CHANGING...
-
Page 2: Table Of Contents
CONTENTS Installation instructions.....................1 1.1 To carry or move....................1 1.2 Open-box inspections..................1 1.3 Installation......................1 Main control interface introduction................. 7 2.1 Main interface..................... 7 2.2 Single information interface................8 2.3 Single cluster information interface.............. 10 2.4 Alarm Information Interface................10 2.5 Single cluster control interface..............11 III.Instructions for lithium battery charge..............12 3.1 Electrical performance index................. -
Page 3: Installation Instructions
640V2520AH 384V500AH I Installation instruction 1.1 To carry or move Lithium batteries in the carrying or movement process, should avoid inverted handling or side sleeping handling, should be handled with care and to avoid collision 1.2 Open-box inspection Check the battery for damage during transportation. Check the packing list (to actual... - Page 4 640V2520AH 1.3.2 Installation Put the battery rack in the specified position and fix it (pay attention to the direction of the battery rack), and put the battery module on the shelf according to the battery layout diagram, as shown below:...
- Page 5 640V2520AH 384V500AH Battery module layout and signal cable connection diagram -------------------------------------------------------------------------------------------------- Overall...
- Page 6 640V2520AH Battery modules must be placed in the specified order. Battery module is heavy, in order to reduce the risk of injury, please do a good job of protective measures. After the battery module is arranged as required, connect each battery module according to the battery line connection diagram.
- Page 7 640V2520AH 384V500AH The power lines P+ and P- of each cluster are connected to the system cabinet according to the CAD drawings. 2. Please follow the steps below to implement the power-on process: Check the power lines between the battery packs and whether the communication lines are properly connected and fastened.
- Page 8 640V2520AH The system self-check is correct, the high voltage power on, the system is running It is better to use a temperature normally, the running indicator RUN on the measuring gun to test the system cabinet is always on, the battery...
-
Page 9: Main Control Interface Introduction
640V2520AH 384V500AH II、Main control interface introduction 2.1 Main interface： 2.1.1 Key function： The position of each button on the main interface is as shown in the figure below： The specific function description of each serial number button： (1)Restart the display control screen function, which can be used to solve the display control screen display data stuck screen. -
Page 10: Single Information Interface
640V2520AH 2.1.2 Status display： The location of each display data on the main interface is as shown below： Detailed description of each display data on the main interface： (1)Overall general data: SOC, overall current, voltage, actual total capacity, dry contact signal of charge and discharge (green light indicates permission). - Page 11 640V2520AH 384V500AH Specific function description of each serial number button： (1)Restart the display control screen function, which can be used to solve the display control screen display data stuck screen. (2)Selection of cluster serial number to be queried: Select to query the individual information of the cluster, and enter the number selection by clicking the pop-up keyboard.
-
Page 12: Single Cluster Information Interface
640V2520AH Detailed description of each display data： (1)Display the cell voltage information of the cluster. (2)Display the collected temperature information of each temperature sensor of the cluster. 2.3 Single cluster information interface： 2.3.1 Key function： For the location and function of each button on the single cluster information interface, see the description of the buttons on the single information interface 2.3.2 Data display：... -
Page 13: Single Cluster Control Interface
640V2520AH 384V500AH 2.4.2 Data display： The position of each data displayed on the alarm interface is as shown in the figure below： This interface mainly displays the fault information of the cluster： Indicate normal Indicate first-level fault Indicate secondary-level fault Indicate three-level fault The severity of the fault level is: 3>... -
Page 14: Iii.instructions For Lithium Battery Charge
640V2520AH 2.5.1 Key function： The position of each button on the strong control interface is as shown in the figure below： Specific function description of each serial number button： (1)Restart the display control screen function, which can be used to solve the display control screen display data stuck screen. -
Page 15: Electrical Performance Index
640V2520AH 384V500AH and is equipped with a display that can intuitively display the output voltage, current and protection functions , The detailed description is as follows: 3.1 Electrical performance index Product model: APSP-LI-80V50A Input power: three-phase 380Vac 45--65HZ ... - Page 16 640V2520AH Connect the positive and negative poles of the battery here Open the rear panel of the host Three-phase input line After connecting the three-phase input line, fix the switch on the rear panel to complete the wiring A.
- Page 17 640V2520AH 384V500AH As shown in the figure: 3.2.2 Display description A. After booting, the panel will display the following The main interface will display the basic information of the machine and fault information...
- Page 18 640V2520AH B. On the main screen, click the upper left corner to enter the maintenance options as Follows Maintenance options include: parameter settings...
- Page 19 640V2520AH 384V500AH Enter the management password 123456 and enter the settings Then enter the password setting, you can modify the password to ensure safety...
- Page 20 640V2520AH Or enter the module settings You can set the system minimum voltage, maximum current, maximum voltage, and BMS voltage into the protection settings, which can limit the output over-voltage, output under-voltage, and output over-current settings of the machine...
- Page 21 640V2520AH 384V500AH Time setting, you can calibrate the current system time Debug mode The charging voltage and charging current can be set...
- Page 22 640V2520AH Pile information Display the basic information of the machine Alarm query You can directly see the record of the last failure inside, select other to see more historical failure records...
- Page 23 640V2520AH 384V500AH Schedule charging electricty You can set timed charging, more humane, and finally click back to return to the main interface C. Click the battery directly to see the ID information, message data and the set voltage, current and temperature information...
-
Page 24: Product Profile
640V2520AH 3.2.3 Button description The machine is equipped with start and stop buttons, and the corresponding status will be prompted with the change of the light color A. The red light is always on-the upper point is on standby B. Green light is always on-charging C. -
Page 25: V.systemic Statements
640V2520AH 384V500AH Small, maintenance-free Environmental protection non-polluting materials, no heavy metals, green environmental protection Standard cycle life over 5000 cycles Accurately estimate the charge state of the battery pack, that is, the remaining battery quantity, to ensure that the battery pack quantity is maintained within a reasonable range Built-in BMS management system with full protection and monitoring control ... -
Page 26: Technical Features
640V2520AH Number of channels for t Piece emperature detection Temperature detection range ℃ Temperature detection NTC ,100KB3950 ℃ accuracy Insulating Resistance 0~200 KΩ, error <15 KΩ; 10KΩ KΩ >200 KΩ, error ≤±15% Detection Error Equilibrium current Equilibrium opening minimum voltage difference CAN number of channels CAN2.0B... -
Page 27: Product Graphics And Technical Parameters
640V2520AH 384V500AH power-down save function 5.4 Product Graphics and Technical Parameters Battery module ------------------------------------------------------------------------------------ Battery cluster/ Stack (only for sample showing) - Page 28 640V2520AH Product technical parameters： Model 96100 96200 192100 192200 220100 220200 360100 360200 384100 384200 Cell type Lithium iron phosphate Rated energy (KWH) Nominal capacity (AH) Nominal 220.8 358.4 voltage (VDC) Operating voltage range 78~112.5 156~225 179~259 391~420 312~450 (VDC)
- Page 29 640V2520AH 384V500AH Above data is for regular parameters, such as voltage, capacity can be customized according to requirements Overview of Upper Computer Software Main interface-mainly used as a visual display area for basic battery information, selection of upper computer function window, BMS basic information display, and battery failure prompt.
- Page 30 640V2520AH Battery pack health status, button blue/green represents normal, orange represents minor fault, and represents serious fault Monomer Information Interface Click on "monomer information" to enter the monomer information interface, which is mainly used as the visual display area of cell voltage and temperature information.
-
Page 31: Vi.maintenance And Troubleshooting
640V2520AH 384V500AH function selection area. Click the corresponding the Chinese character area to enter the corresponding functional parameters configuration interface. VI. Maintenance and troubleshooting 6.1 Routine maintenance A. Clean battery dust regularly (6 months) and check battery connection wire for loosening. - Page 32 640V2520AH treated as prescribed in packaging, transportation and storage. In order to prevent the daily treatment of lithium batteries caused casualties and property losses, the following requirements are made for lithium battery management: 1.Basic requirements for battery warehouse management The high temperature and wet temperature will accelerate the self-discharge of the battery due to the characteristic problem of lithium battery.
- Page 33 640V2520AH 384V500AH 3.Storage requirements for defective batteries The following measures must be taken in order to deal with the serious defects such as leakage, bumping and breakage, short circuit and so on, such as the bad core and module which are returned from production: A.
-
Page 34: Viii.warranty
640V2520AH Follow the "first in, first out" principle to avoid battery performance degradation due to long-term inventory and accidental occurrence. VIII. Warranty services Under the guidance of our company, customers return our products so that we can provide maintenance services or replace products of equal value. The customer needs to pay the necessary freight and other related expenses. - Page 36 High- Voltage Lithium Iron Phosphate Battery...
