Moman ML6-DC User Manual

MOMAN-ML6-DC说明书转曲.indd 1 MOMAN-ML6-DC说明书转曲.indd 1
1. Turn on/off Power
① Depress and hold the button to turn
on or turn off the power.
② Adjustable color temperature and
brightness after the fill light is turned on.
2. Adjustment Button
The button can be adjust color
temperature and brightness.
3. 3.Output Control (5%-100%)
Hold the adjustment button towards the
area, Press the increase button to
increase output and press the decrease
button to decrease it.
4. Color Temperature Control
(3000K-6500K)
Hold the adjustment button towards the
area, Press the increase button to
increase output and press the decrease
button to decrease it.
5. DC Input Port
Type-C charging port. Input voltage
DC5V, Charging time is about 3 hours.
6. DC Output Port
USB charging port, Can be used as a
power bank, built-in 4500mAH lithium
battery.
