Moman ML9-RGB User Manual

MOMAN
MOMAN-ML9-RGB说明书转曲.indd 1 MOMAN-ML9-RGB说明书转曲.indd 1

1. Power Button

Long press the Power Button to turn on/ off
the product.

2. Charging Port

Input voltage: DC 5V
Charging time: about 3 hours

3. Mode Switch Button (3 light modes)

Press the Mode Switch Button to switch 3
light modes (CCT; HSI; SCENE).
M o r e d e t a i l s a r e o n t h e I n t e r f a c e
Introduction.

4. Multi-function Button (CCT Mode)

The Multi-function Button is used to adjust
the color temperature of the light when in
the CCT mode, pressing up to increase, and
pressing down to decrease (2500K-8500K).

5. Multi-function Button (HSI Mode)

When the light is in the HSI mode, the Multi-function
Button can adjust the color and color temperature.
When is pointing at "H", Multi-function Button
is used to adjust the color value, pressing up to
increase and pressing down to decrease (0-360° ).
Press down the Multi-function Button in the middle,
will point at "S", then you can adjust the color
temperature, pressing up to increase and down to
decrease (0-100).

6. Multi-function Button (SCENE Mode)

There are three subordinate lighting modes under SCENE mode: 1. Warning Lamp mode; 2.
Gradient mode; 3. Lightning mode. Under each subordinate mode, there are A, B, C, three
special effects to freely choose.
When the light is in the SCENE mode, press down the Multi-function Button in the middle
to switch the lighting mode, 1. Warning Lamp mode; 2. Gradient mode; 3. Lightning mode.
Choose the A, B or C option by pressing up and down the Multi-function Button to move
the forward or backward.
More details are on the Interface Introduction.

7. Brightness Control (0%-100%)

Twist the Brightness Control button upward to increase the brightness and downward to
decrease the brightness.
