Summary of Contents for DLP Texas Instruments vivitek DU6098Z

  • Page 2 Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. © Copyright 2020 Disclaimer The information in this document is subject to change without notice.
  • Page 3 DLP Projector—User’s Manual Important Safety Information Important: It is strongly recommended that you read this section carefully before using the projector. These safety and usage instructions will ensure that you enjoy many years of safe use of the projector. Keep this manual for future reference. Symbols Used Warning symbols are used on the unit and in this manual to alert you of hazardous situations.
  • Page 4 Preface LASER WARNING This symbol indicates that there is a potential hazard of eye exposure to laser radiation unless the instructions are closely followed. CLASS 3R LASER PRODUCT This Laser Product is designated as Class 3R during all procedures of operation. LASER LIGHT - AVOID DIRECT EYE EXPOSURE.
  • Page 5 DLP Projector—User’s Manual Product labels Below drawing show the label’s location Hazard Warning Symbol and Aperture Label Explanatory Label — iv —...
  • Page 6 Preface Location of laser aperture Below drawing is the laser aperture location. Be careful not to let the eye see the light directly. Interlock switches This machine has 2 (Top cover x 1, Lens x 1) Interlock switches to protect the laser light Leakage. 1.
  • Page 7 DLP Projector—User’s Manual Projector Installation Notice  There is no limitation angle for projector installation.  Allow at least 50 cm clearance around the exhaust vent. Minimum 500mm Minimum 500mm Minimum 500mm (19.69 inch) (19.69 inch) (19.69 inch) Minimum 500mm (19.69 inch) Minimum 100mm (3.94 inch)
  • Page 8 Preface Verify Installation Location  To supply power, the 3-blade (with earthing lead) socket should be used to ensure proper grounding and equalized ground potential for all of the equipment in the Projector System.  The power code provided with the Projector should be used. In case of any missing item, other qualified 3-blade (with earthing lead) power cord can be used as substitution;...
  • Page 9 DLP Projector—User’s Manual Power Safety  Only use the supplied power cord.  Do not place anything on the power cord. Place the power cord where it will not be in the way of foot traffic.  Remove the batteries from the remote control when storing or not in use for a prolonged period. Cleaning the Projector ...
  • Page 10 Preface Main Features  Compatible with all major video standards including NTSC, PAL, and SECAM.  A high brightness rating allows for presentations in daylight or in lit rooms.  Flexible setup allows for front, rear projections.  Line-of-vision projections remain square, with advanced keystone correction for angled projections.

  • Page 11: Table Of Contents

    DLP Projector—User’s Manual Table of Contents GETTING STARTED .............................. 1 ............................. 1 ACKING HECKLIST ..........................2 IEWS OF ROJECTOR ARTS Front-right View ............................... 2 Top view ................................3 Side view—IO ..............................4 Side view—On-Screen Display (OSD) buttons ....................6 Bottom view ..............................8 ...........................
  • Page 12 Preface ............................... 70 MAGE ROBLEMS ..........................70 IGHT OURCE ROBLEMS ..........................70 EMOTE ONTROL ROBLEMS ............................... 71 UDIO ROBLEMS ........................71 AVING THE ROJECTOR ERVICED HDMI Q & A ............................... 72 SPECIFICATIONS ..............................73 ..............................73 PECIFICATIONS ...................... 75 ROJECTION ISTANCE VS ROJECTION Projection Distance and Size Table ......................

  • Page 13: Getting Started

    DLP Projector—User’s Manual ETTING TARTED Packing Checklist Carefully unpack the projector and check that the following items are included: Projector Remote Control Anti-thief Screw (M4) (Batteries Included) ( for Lens Installation ) VGA Cable (1.8m) Power Cord (1.8m) Wired Remote Cable Safety Card Warranty Card Quick Start Guide...

  • Page 14: Views Of Projector Parts

    DLP Projector—User’s Manual Views of Projector Parts Front-right View ABEL ESCRIPTION EE PAGE IR Receiver Receives IR signal from remote control. LEDs Displays the projector status. Vent Cool air intake. Tilt Adjuster Rotate adjuster lever to adjust angle position. Lens Release Button For release Lens.

  • Page 15: Top View

    DLP Projector—User’s Manual Top view 1 2 3 4 ABEL ESCRIPTION EE PAGE TEMP LED Display the thermal status. LIGHT LED Display the light source status. STATUS LED Display the warning message. POWER LED Display the power on/off sequence status. IR Receiver Receives IR signal from remote control.

  • Page 16: Side View-Io

    DLP Projector—User’s Manual Side view—IO ABEL ESCRIPTION EE PAGE 3D-SYNC IN Connect 3D-sync in cable from a computer or an enabled device. MONITOR OUT Connect an RGB cable to a display. COMPUTER IN Connect an RGB cable from a computer or a video enabled device. Connect Cat5e/Cat6 cable from HDBaseT TX Box (VIDEO HDBaseT EXTENDER) for HDBaseT signal received.
  • Page 17 DLP Projector—User’s Manual Note:  To use this feature, you must plug in the connector before turn on/off the projector.  Screen controllers are supplied and supported by screen manufacturers.  Do not use this jack for anything other than intended use. Warning: As a safety precaution, disconnect all power to the projector and connecting devices before making connections.

  • Page 18: Side View-On-Screen Display (Osd) Buttons

    DLP Projector—User’s Manual Side view—On-Screen Display (OSD) buttons ABEL ESCRIPTION EE PAGE POWER Turn the projector on or off. INPUT Enter the Source menu. AUTO SYNC Auto adjustment for frequency, phase, and position. ASPECT Displays the ASPECT RATIO selections. To center the lens and calibrate the parameter of lens shift. Note: The lens position needs to be calibrated for the accurate lens CENTER LENS shift operation after installing the lens.
  • Page 19 DLP Projector—User’s Manual ABEL ESCRIPTION EE PAGE Navigates and changes settings in the OSD. Quick Menu – For Horizontal Keystone. MENU Opens and exits OSD menus. Navigates and changes settings in the OSD. Quick Menu – For Vertical Keystone. – 7 –...

  • Page 20: Bottom View

    DLP Projector—User’s Manual Bottom view 300.0m m 180.0m m 85.0m m 300.0m m ABEL ESCRIPTION EE PAGE Contact your dealer for information on mounting the projector on a Ceiling Mount Holes ceiling. Tilt Adjustor Rotate adjuster lever to adjust angle position. Note: When installing, ensure that you use only UL Listed ceiling mounts.
  • Page 21 DLP Projector—User’s Manual Reference drawings for stand Please hire an installation service provider (for a fee) for the design and manufacture of a customized stand to be used for portrait projection. Please ensure that the design complies with the following conditions: •...

  • Page 22: Remote Control Parts

    DLP Projector—User’s Manual Remote Control Parts Important: 1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency fluorescent lights can disrupt remote control operation. 2. Be sure nothing obstructs the path between the remote control and the projector. If the path between the remote control and the projector is obstructed, you can bounce the signal off certain reflective surfaces such as projector screens.
  • Page 23 DLP Projector—User’s Manual ABEL ESCRIPTION EE PAGE IR Transmitter Transmits signals to projector. Turns the projector on. ZOOM + Zoom in the projected image. FOCUS + Adjust the focus of the projected image. FOCUS - Adjust the focus of the projected image. Navigates and changes settings in the OSD.

  • Page 24: Set Control Id Number

    DLP Projector—User’s Manual Set Control ID Number Select Control ID Number option then press Enter button, use the ► button to increase the number or the ◄ button to decrease the number. This option is available when Projector ID Control is turned on. Set the identification number of remote control Press and hold ID SET button on the remote control around 5 seconds, Power LED indicator is flashing red periodically.

  • Page 25: Remote Control Operating Range

    DLP Projector—User’s Manual Remote Control Operating Range The remote control uses infrared transmission to control the projector. It is not necessary to point the remote directly at the projector. Provided you are not holding the remote perpendicular to the sides or the rear of the projector, the remote will function well within a radius of about 10 meters (25 feet) and 15 degrees above or below the projector level.

  • Page 26: Setup And Operation

    DLP Projector—User’s Manual ETUP AND PERATION Inserting the Remote Control Batteries Remove the battery compartment cover by sliding the cover in the direction of the arrow. Insert the battery with the positive side facing up. Replace the cover. Caution: 1. Only use AA batteries (Alkaline batteries are recommended). 2.

  • Page 27: Installing Or Removing The Optional Lens

    DLP Projector—User’s Manual Installing or Removing the Optional Lens Caution:  Do not shake or place excessive pressure on the projector or the lens components as the projector and lens components contain precision parts.  Before removing or installing the lens, be sure to turn off the projector, wait until the cooling fans stop, and turn off the main power switch.

  • Page 28: Removing The Existing Lens From The Projector

    DLP Projector—User’s Manual Removing the Existing Lens From the Projector Push the LENS RELEASE button to the unlock position. Grasp the lens. Rotate the lens counterclockwise. The existing lens will be disengaged. Pull out the existing lens slowly. — 16 —...

  • Page 29: Starting And Shutting Down The Projector

    DLP Projector—User’s Manual Starting and Shutting down the Projector Securely connect the power cord and signal cable. When connected, the power led will flash green to solid green. Turn on the light source by pressing “ ” button on the projector or “ ”...
  • Page 30 DLP Projector—User’s Manual If more than one input device is connected, press the SOURCE button and use ▲▼ to scroll among devices. (Component is supported through the RGB to Component adapter.)  HDMI 1: High-Definition Multimedia Interface compatible  HDMI 2: High-Definition Multimedia Interface ...

  • Page 31: Setting An Access Password (Security Lock)

    DLP Projector—User’s Manual Setting an Access Password (Security Lock) You can use the four (arrow) buttons to set a password and prevent unauthorized use of the projector. When enabled, the password must be entered after you power on the projector. (See Navigating the OSD on page Setting the OSD Language...
  • Page 32 DLP Projector—User’s Manual You can use the cursor buttons ▲▼◄► either on keypad or IR remote control for password entry. You can use any combination including the same arrow five times, but not less than five. Press the cursor buttons in any order to set the password.

  • Page 33: Adjusting The Projector Level

    DLP Projector—User’s Manual Adjusting the Projector Level Take note of the following when setting up the projector:  The projector table or stand should be level and sturdy.  Position the projector so that it is perpendicular to the screen. ...

  • Page 34: Adjusting Projected Image Position Using Lens Shift

    DLP Projector—User’s Manual Adjusting Projected Image Position Using Lens Shift The DU6098Z/DU6198Z/DU6298Z projector has the powered lens shift feature; the image can be shifted vertically or horizontally without moving the projector. The lens shift range is shown in the percentage of the image height and width, the maximum vertical shift range can be up to 55% of the image height and down to 15% of the image height, and maximum horizontal shift range is 5% of the image width to right and left.

  • Page 35: Adjusting The Zoom, Focus And Keystone

    DLP Projector—User’s Manual Adjusting the Zoom, Focus and Keystone The focus and zoom can be adjusted from the projector control panel or remote control. Refer to the following guides to adjust the focus and zoom manually. Press the Focus or Zoom button on the control key panel or remote control to adjust the focus or zoom effect using the increase and decrease buttons as...

  • Page 36: On-Screen Display (Osd) Menu Settings

    DLP Projector—User’s Manual (OSD) M CREEN ISPLAY ETTINGS OSD Menu Controls The projector has an OSD that lets you make image adjustments and change various settings. Navigating the OSD You can use the remote control cursor buttons or the buttons on the projector to navigate and make changes to the OSD.

  • Page 37: Setting The Osd Language

    DLP Projector—User’s Manual Setting the OSD Language Set the OSD language to your preference before continuing. 1. Press the MENU button. Press the cursor ◄► button to navigate to Settings 1. Press the cursor ▲▼ button to move to the Advanced 1 menu. (Enter) / ►...

  • Page 38: Osd Menu Overview

    DLP Projector—User’s Manual OSD Menu Overview Use the following illustration to quickly find a setting or determine the range for a setting. Main Menu Sub Menu Settings Image Display Mode Presentation, Bright, Game, Movie, Vivid, Blending, sRGB, DICOM SIM, User, User2 Brightness 0~100 Contrast...
  • Page 39 DLP Projector—User’s Manual Main Sub Menu Settings Menu Settings 1 Source Source reference Input Source Select (IR/Keypad) Projection Normal, Real, Ceiling, Real+Ceiling Aspect Ratio Fill, 4:3, 16:9, Letter Box, Native, 2.35:1 Alignment Lens Lock Off / On Lens Control Zoom, Focus, Shift control Lens Type non-UST, UST Lens Memory...
  • Page 40 DLP Projector—User’s Manual Main Sub Menu Settings Menu Settings 1 Advanced 2 Test Pattern None, RGB Ramps, Color Bars, Step Bars, CheckBoard, Grid, Horizontal lines, Vertical Lines, Diagonal Lines, Horizontal Ramp, Vertical Ramp, White, Red, Green, Blue, Black H Image Shift -50~50 V Image Shift -50~50...
  • Page 41 DLP Projector—User’s Manual Main Sub Menu Settings Menu Settings 2 Advanced 2 Sleep Timer 0~600 Source Filter HDMI1 Disable, Enable HDMI2 Disable, Enable Disable, Enable Disable, Enable Disable, Enable HDBaseT Disable, Enable Air Filter Timer Air Filter Timer On, Off Air Filter Timer Reset Color Space...

  • Page 42: Image Menu

    DLP Projector—User’s Manual Image Menu Attention ! All of display mode parameters when changed will be saved to user mode. Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Image Menu. Press the cursor ▲▼...

  • Page 43: Computer Menu

    DLP Projector—User’s Manual Computer Menu Press the MENU button to open the OSD menu. Press ◄► to move to the Image menu. Press ▲▼ to move to the Computer menu and then press Enter or ►. Press ▲▼ to move up and down in the Computer menu.

  • Page 44: Advanced Feature

    DLP Projector—User’s Manual Advanced Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲ to move to the Advanced menu and then press Enter or ►. Press ▼▲ to move up and down in the Advanced menu.

  • Page 45: White Balance

    DLP Projector—User’s Manual White Balance Press the ENTER button to enter the White Balance sub menu. ESCRIPTION Press the ◄► buttons to adjust the Red Gain. R Gain Press the ◄► buttons to adjust the Green Gain. G Gain Press the ◄► buttons to adjust the Blue Gain. B Gain Press the ◄►...

  • Page 46: Color Manager

    DLP Projector—User’s Manual Color Manager Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲ to move to the Color Manager menu and then press Enter or ►. Press ▼▲ to move up and down in the Color Manager menu.

  • Page 47: Dynamic Black Settings

    DLP Projector—User’s Manual Dynamic Black Settings Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲ to move to the Dynamic Black Settings menu and then press Enter or ►. Press ▼▲ to move up and down in the Dynamic Black Settings menu.

  • Page 48: Hdr Settings

    DLP Projector—User’s Manual HDR Settings Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲ to move to the HDR Settings menu and then press Enter or ►. Press ▼▲ to move up and down in the HDR Settings menu.

  • Page 49: Settings 1 Menu

    DLP Projector—User’s Manual Settings 1 Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Settings 1 menu. Press the cursor ▲▼ button to move up and down in the Settings 1 menu. Press ◄► to enter and change values for settings.

  • Page 50: Alignment

    DLP Projector—User’s Manual Alignment Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press ▼▲ to move to the Alignment menu and then press Enter or ►. Press ▼▲ to move up and down in the Alignment menu.
  • Page 51 DLP Projector—User’s Manual Lens Control Press ◄► to adjust Lens Focus. Press ▼▲ to adjust Lens Zoom. Press Enter to switch Lens Shift menu. Lens Shift Press ▼▲◄► to adjust Lens Shift. Press Enter to switch Lens Control menu. – 39 –...
  • Page 52 DLP Projector—User’s Manual Lens Memory (Enter) / ► to enter the Lens Memory sub menu. Press ▼▲to select Memory 1~Memory 8 and Press adjust Lens Memory to Save, Load or Clear. This projector supports Lens Position Memory (LPS). Up to 8 programmed lens positions can be stored in the projector’s memory.
  • Page 53 DLP Projector—User’s Manual Keystone (Enter) / ► to enter the Keystone sub menu. Press ▼▲to adjust vertical values from -30 to 30. Press Press ◄► to adjust horizontal values from -25 to 25. 4 Corner (Enter) / ► to enter the 4 Corner sub menu. Press 1.

  • Page 54: Audio

    DLP Projector—User’s Manual Audio Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press ▼▲ to move to the Audio menu and then press Enter or ►. Press ▼▲ to move up and down in the Audio menu. ESCRIPTION Press the cursor ◄►...

  • Page 55: Advanced 1 Feature

    DLP Projector—User’s Manual Advanced 1 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press ▲▼ to move to the Advanced 1 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 1 menu.
  • Page 56 DLP Projector—User’s Manual 3D Setting ESCRIPTION Press the cursor ◄► button to enter and select different 3D mode. Press the cursor ◄► button to enter and enable or disable 3D Sync Invert. 3D Sync Invert Press the cursor ◄► button to enter and select different 3D Format. 3D Format Press the cursor ◄►...

  • Page 57: Advanced 2 Feature

    DLP Projector—User’s Manual Advanced 2 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press ▲▼ to move to the Advanced 2 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 2 menu.

  • Page 58: Settings 2 Menu

    DLP Projector—User’s Manual Settings 2 Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Settings 2 menu. Press the cursor ▲▼ button to move up and down in the Settings 2 menu. ESCRIPTION Press the cursor ◄►...

  • Page 59: Light Setting

    DLP Projector—User’s Manual Light Setting Press the cursor ▲▼ button to move up and down in the Settings 2 menu. Select the Light Setting menu and press Enter or ► to enter. ESCRIPTION Press the cursor ◄► button to select Normal, Eco, Eco Plus, Dimming, Extreme Light Mode Dimming Press the cursor ◄►...

  • Page 60: Status

    DLP Projector—User’s Manual Status Press the cursor ▲▼ button to move up and down in the Settings 2 menu. Select the Status menu and press Enter or ► to enter. ESCRIPTION Model Showing model name. Active Source Display the activated source. Displays resolution/video information for RGB source and color standard for Video Video Information source.

  • Page 61: Advanced 1 Feature

    DLP Projector—User’s Manual Advanced 1 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 2 menu. Press ▲▼ to move to the Advanced 1 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 1 menu.
  • Page 62 DLP Projector—User’s Manual Network ESCRIPTION Network State Displays the network connection status. Press ◄► to turn DHCP On or Off. DHCP Note: If you select DHCP Off, complete the IP Address, Subnet Mask, Gateway, and DNS fields. IP Address Enter a valid IP address if DHCP is turned off. Subnet Mask Enter a valid Subnet Mask if DHCP is turned off.
  • Page 63 DLP Projector—User’s Manual LAN_RJ45 Wired LAN Terminal functionalites Remote control and monitoring of a projector from a PC (or Laptop) via wired LAN is also possible. Compatibility with Crestron / AMX (Device Discovery) / Extron control boxes enables not only collective projector management on a network but also management from a control panel on a PC (or Laptop) browser screen.
  • Page 64 DLP Projector—User’s Manual LAN_RJ45 1. Connect an RJ45 cable to RJ45 ports on the projector and the PC (Laptop). 2. On the PC (Laptop), select Start → Control Panel →Network and Internet. — 52 —...
  • Page 65 DLP Projector—User’s Manual 3. Right-click on Local Area Connection, and select Properties. 4. In the Properties window, select the Networking tab, and select Internet Protocol (TCP/IP). 5. Click Properties. 6. Click Use the following IP address and fill in the IP address and Subnet mask, then click OK. –...
  • Page 66 DLP Projector—User’s Manual 7. Press the Menu button on the projector. Select Settings2→ Advanced1 → Network After getting into Network, input the following:  DHCP: Off  IP Address: 10.10.10.10  Subnet Mask: 255.255.255.0  Gateway: 0.0.0.0  DNS Server: 0.0.0.0 (Enter) / ►...
  • Page 67 DLP Projector—User’s Manual ATEGORY NPUT ENGTH IP Address Crestron Control IP ID Port Projector Name Projector Location Assigned To DHCP (Enabled) (N/A) IP Address Network Configuration Subnet Mask Default Gateway DNS Server Enabled (N/A) User Password New Password Confirm Enabled (N/A) Admin Password New Password...
  • Page 68 DLP Projector—User’s Manual Preparing Email Alerts 1. Make sure that user can access the homepage of LAN RJ45 function by web browser (for ex-ample, Microsoft Internet Explorer v6.01/v8.0). 2. From the Homepage of LAN/RJ45, click Alert Settings. 3. By default, these input boxes in Alert Settings are blank. —...
  • Page 69 DLP Projector—User’s Manual 4. For Sending alert mail, input the following: The SMTP field is the mail server for sending out email (SMTP protocol). This is a required field. The To field is the recipient’s email address (for example, the projector administrator). This is a required field.
  • Page 70 DLP Projector—User’s Manual RS232 by Telnet Function Besides projector connected to RS232 interface with “Hyper-Terminal” communication by dedicated RS232 command control, there is alternative RS232 command control way, so called “RS232 by TELNET” for LAN/RJ45 interface. Quick Start-Guide for “RS232 by TELNET” Check and get the IP-Address on OSD of the projector.
  • Page 71 DLP Projector—User’s Manual Input the command format like the below: telnet ttt.xxx.yyy.zzz 7000 (“Enter” key pressed) (ttt.xxx.yyy.zzz: IP-Address of the projector) If Telnet-Connection ready, and user can have RS232 command input, then “Enter” key pressed, the RS232 command will be workable. How to have TELNET enabled in Windows By default installation for Windows, “TELNET”...
  • Page 72 DLP Projector—User’s Manual Select “Turn Windows features on or off” to open Have “Telnet Client” option checked, then press “OK” button. Specsheet for “RS232 by TELNET” : 1. Telnet: TCP 2. Telnet port: 7000 (for more detail, kindly please get contact with the service agent or team) 3.
  • Page 73 DLP Projector—User’s Manual HDBaseT-IR/RS232 ESCRIPTION Press the cursor ◄► button to enter and enable or disable HDBaseT Control. HDBaseT-IR/RS232 Press the cursor ◄► button to enter and enable or disable Front IR. Front IR Press the cursor ◄► button to enter and enable or disable Rear IR. Rear IR Note: 1.

  • Page 74: Advanced 2 Feature

    DLP Projector—User’s Manual Advanced 2 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 2 menu. Press ▲▼ to move to the Advanced 2 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 2 menu.
  • Page 75 DLP Projector—User’s Manual Source Filter Press the ENTER button to enter the Source Filter sub menu. ESCRIPTION Press the cursor ◄► button to enter and enable or disable the HDMI1 source. HDMI1 Press the cursor ◄► button to enter and enable or disable the HDMI2 source. HDMI2 Press the cursor ◄►...
  • Page 76 DLP Projector—User’s Manual Air Filter Timer Press the ENTER button to enter the Air Filter Timer sub menu. ESCRIPTION Press the cursor ◄► button to enter and enable or disable the Air Filter Timer. Air Filter Timer Air Filter Timer (Enter) / ►...
  • Page 77 DLP Projector—User’s Manual Environment Status Press the ENTER button to enter the Environment Status sub menu. – 65 –...

  • Page 78: Maintenance And Security

    DLP Projector—User’s Manual AINTENANCE AND ECURITY Cleaning the Projector Cleaning the projector to remove dust and grime will help ensure trouble-free operation. Warning: 1. Be sure to turn off and unplug the projector at least 30 minutes before cleaning. Failure to do so could result in a severe burn.

  • Page 79: Using The Physical Lock

    DLP Projector—User’s Manual Using the Physical Lock Using the Kensington Security Slot If you are concerned about security, attach the projector to a permanent object with the Kensington slot and a security cable. Note: Contact your vendor for details on purchasing a suitable Kensington security cable. The security lock corresponds to Kensington’s MicroSaver Security System.

  • Page 80: Troubleshooting

    DLP Projector—User’s Manual ROUBLESHOOTING Common Problems and Solutions These guidelines provide tips to deal with problems you may encounter while using the projector. If the problem remains unsolved, contact your dealer for assistance. Often after time spent troubleshooting, the problem is traced to something as simple as a loose connection. Check the following before proceeding to the problem-specific solutions.

  • Page 81: Led Error Messages

    DLP Projector—User’s Manual LED Error Messages POWER LED STATUS LED LIGHT LED TEMP LED SYSTEM STATUS (GREEN) (RED) (RED) (RED) Light Ready Start Flashing Cooling Flashing Over Temperature T1 1 blinks Over Temperature T2 2 blinks Over Temperature T3 3 blinks Over Temperature T4 4 blinks Over Temperature T5...

  • Page 82: Image Problems

    DLP Projector—User’s Manual Image Problems Problem: No image appears on the screen 1. Verify the settings on your notebook or desktop PC. 2. Turn off all equipment and power up again in the correct order. Problem: The image is blurred 1.

  • Page 83: Audio Problems

    DLP Projector—User’s Manual Audio Problems Problem: There is no sound 1. Adjust the volume on the remote control. 2. Adjust the volume of the audio source. 3. Check the audio cable connection. 4. Test the source audio output with other speakers. 5.

  • Page 84: Hdmi Q & A

    DLP Projector—User’s Manual HDMI Q & A Q. What is the difference between a “Standard” HDMI cable and a “High-Speed” HDMI cable? Recently, HDMI Licensing, LLC announced that cables would be tested as Standard or High- Speed cables. ˙Standard (or “category 1”) HDMI cables have been tested to perform at speeds of 75Mhz or up to 2.25Gbps, which is the equivalent of a 720p/1080i signal.

  • Page 85: Specifications

    DLP Projector—User’s Manual PECIFICATIONS Specifications Model Name DU6098Z DU6198Z DU6298Z Display Type 0.67 WUXGA Resolution WUXGA 1920x1200 Vertical ±30° for ±30 steps Keystone Correction Horizontal ±30° for ±30 steps Projection Methods Front, Rear, Desktop/Ceiling (Rear, Front) Data Compatibility VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA@60hz, Mac SDTV/EDTV/ HDTV 480i, 480p, 576i, 576p, 720p, 1080i, 1080p Video Compatibility...
  • Page 86 DLP Projector—User’s Manual RS-232 in x 1 ( for serial in for control ) RS-232 out x 1 (serial out for Pass thru Daisy Chain) RJ45 x 1 (10/100Mbps) Control Terminals Screen Trigger : DC Jack x 1 (DC12V 200mA output function) Wired Remote In x 1 Wired Remote Out x 1 USB Type B for service x 1...

  • Page 87: Projection Distance Vs. Projection Size

    DLP Projector—User’s Manual Projection Distance vs. Projection Size Projection Distance Projection Distance and Size Table Short throw zoom projection lens: TR: 0.77~1.1; offset=55% 1.18 2.37 3.55 4.98 1.00 1.66 3.32 4.98 Distance (m) Diagonal (") Image Width (mm) 1077 2154 3231 4523 1292...
  • Page 88 DLP Projector—User’s Manual Semi throw projection lens: TR: 1.25 ~ 1.6; offset=55% Distance (m) 1.38 3.45 5.17 7.93 1.35 2.69 5.38 8.08 Diagonal (") Image Width (mm) 2154 3231 4954 1077 2154 4308 6462 Image Height (mm) 1346 2019 3096 1346 2692 4039...

  • Page 89: Timing Mode Table

    DLP Projector—User’s Manual Timing Mode Table Table of Supported Frequency The unit automatically determines PC signals to select the appropriate resolution. Some signals may require manual adjustment. VGA/BNC HDMI IGNAL ESOLUTION OMPOSITE OMPONENT ( KH NALOG IGITAL IGITAL IGITAL － －...
  • Page 90 DLP Projector—User’s Manual VGA/BNC HDMI IGNAL ESOLUTION OMPOSITE OMPONENT ( KH NALOG IGITAL IGITAL IGITAL ○ － － 480i 15.734 (3D:FS) (3D:FS) (3D:FS) SDTV ○ － － － － － 576i 15.625 ○ － － － － － 576p 31.3 EDTV ○...

  • Page 91: Table Of Supported Frequency For 3D Mode

    DLP Projector—User’s Manual Table of Supported Frequency For 3D mode The unit automatically determines PC signals to select the appropriate resolution. Some signals may require manual adjustment. Input Signal for D-SUB/HDMI/DVI-D IGNAL ESOLUTION EFRESH SVGA 800 X 600 60/120 1024 X 768 60/120 HDTV(720P) 1280 X 720...

  • Page 92: Projector Dimensions

    DLP Projector—User’s Manual Projector Dimensions — 80 —...

  • Page 93: Regulatory Compliance

    DLP Projector—User’s Manual EGULATORY OMPLIANCE FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 94: Communication Parameter Setup

    DLP Projector—User’s Manual PPENDIX Communication parameter setup You can use the serial control command to input commands for projector control or retrieve its operational data through Windows client terminal software Item Parameter: Bit per Second 9600 bps Data Bit 8-bit Parity None Stop Bit...
  • Page 95 DLP Projector—User’s Manual Function Operation Set Get Inc Dec EXE Values 0 = Off Auto Source auto.src 1 = On 0 : Auto HDMI Color Space color.space 1 : RGB 2 : YUV 0 : Auto HDMI Range hdmi.range 1 : Full 2 : Limited Video Saturation video.saturation...
  • Page 96 DLP Projector—User’s Manual Function Operation Set Get Inc Dec EXE Values 0 : PQ-L300 1 : PQ-L400 HDR Mode hdr.mode 2 : PQ-L500 3 : PQ-L600 0 = Off Dynamic Black dblack 1 = On 0 : Disable 1: 0.5 sec Projector Light 2: 1 Sec projector.light...
  • Page 97 DLP Projector—User’s Manual Function Operation Set Get Inc Dec EXE Values White Balance /Green Gain green.gain 0 ~ 200 White Balance /Blue Gain blue.gain 0 ~ 200 0 = Fill 1 = 4:3 2 = 16:9 Aspect Ratio aspect 3 = LetterBox 4 = Native 5 = 2.35:1 Digital Zoom...
  • Page 98 DLP Projector—User’s Manual Function Operation Set Get Inc Dec EXE Values 0 : Cancel NetWork Apply net.apply 1 : OK 1: On (0.5W) Standby Power standby.power 2: On By Lan 3: On By HDBaseT No Signal Power Off nosignal.poweroff V 0 ~ 36 Sleep Timer sleep.timer...
  • Page 99 DLP Projector—User’s Manual Function Operation Set Get Inc Dec EXE Values 0 = English 1 = French 2 = German 3 = Spanish 4 = Portuguese 5 = Simplified Chinese 6 = Traditional Chinese 7 = Italian 8 = Norwegian 9 = Swedish 10 = Dutch 11 = Russian...
  • Page 100 DLP Projector—User’s Manual Function Operation Set Get Inc Dec EXE Values 0 : Off Freeze freeze 1 : On 1 :RGB 3: DVI 6: HDMI 1 Input Select input.sel 7: BNC 9: HDMI 2 15: HDBaseT Lens Lock lens.lock 0: off, 1:on Lens zoom in zoom.in Lens zoom in 2...

This manual is also suitable for:

Vivitek du6198zVivitek du6298z
