- Page 1 DLP SMARTPHONE PICO PROJECTOR Users’ Manual ML51 DLP PICO PROJECTOR...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction -------------------------------------------------------------------5 Box Contents ------------------------------------------------------------------ 5 Setting Up the Pico Projector --------------------------------------------- 6 Installing the remote controller application to your ---------------- 7 Android/IOS Device Connecting to Wireless Media Devices--------------------------------- 8 Connecting to AV Sources ------------------------------------------------- 11 Play From Micro SD card and USB Storage --------------------------- 12 Connecting to external speaker ------------------------------------------- 12 Care and Maintenance ----------------------------------------------------- 12 Cleaning the Pico Projector Housing ----------------------------------- 13... - Page 3 Notes: The appliance inlet of the power supply is the disconnector from mains and must be anytime easily accessible. ≤70dB (A) DIN 45635-19-01-KL2. The maximum noise level of the product is L Der Gerätestecker des Netzteilesbildet die TrennvorrichtungzumVersorgungsstromkreis und mußjederzeitleichtzugänglichsein. ≤70dB (A) DIN 45635-19-01-KL2.
-
Page 4: Introduction
Overloading Do not overload wall outlets and extension cords as this can result in the risk of fire or electric shock. Liquid Spills Do not set drinks or other liquids on top of the Pico Projector. Do not place the Pico Projector near water, for example, near a bathtub, washbowl, kitchen, sink, or laundry tub, in a wet basement, or near a swimming pool. -
Page 5: Box Contents
The following lists some of the specific features:- Direct playback and control from Smartphone and Tablets Small & Simple to Operate Built in WiFi 640x360 nHD resolution 50 Lumens brightness 1000 : 1 High contrast ratio Battery operated USB port and SDcard slot for multimedia playback Various Audio Visual interface connections Built-in Speaker Box Contents... -
Page 6: Setting Up The Pico Projector
SDcard Slot ON/OFF Slide Switch AV Input USB Port Audio Out DC Input Focusing Ring Setting Up the PICO Projector Plug the Power Adaptor to the DC in connector at the rear of the DLP Pico Projector. Note : For first time use with internal battery, charge unit for about 4~5hours Slide the ON/OFF power switch towards the rear of the unitto turn on Projector and will take a short while to initialize. -
Page 7: Installing The Remote Controller Application To Your
Focus Knob SD card Home Screen ON/OFF slot switch Installing the Remote Controller application to your Android/IOS Device Install the App EZ Control from the Google Playstore for Android devices https://play.google.com/store/apps/details?id=com.winnerwave.ezcontrol&hl=en and from Apple’s Itunes https://itunes.apple.com/us/app/ez-control/id592347370?mt=8 for Apple devices. In mobile phone’s/tablets wifi setting, select and connect to WIFI DLP PROJECTOR-xxxxxx, where xxxxxx is unique for each pico projector unit. -
Page 8: Connecting To Wireless Media Devices
QR code for EZCONTROL Start the EZCONTROL application then tap on the name of device [Device(WIFI DLP PROJECTOR)]. If connection is successful, the smart phone’s screen resembles a remote control. Connecting to Wireless Media Devices Install the App EZVIEW application to Smartphone/tablet. The apps for Android and Apple devices can be downloaded from Google Playstore https://play.google.com/store/apps/details?id=com.winnerwave.ezview&hl=en and from Apple’s Itunes... - Page 9 QR code for EZVIEW app WiFi Screen 1) Point to Point Mode At the Home Screen select WiFi At the media device’s wifi setting select and connect to WIFI DLP PROJECTOR-xxxxxx, where xxxxxx is unique for each ML51 unit. PSK (Password) : 87654321 To prevent EZ CONTROL from disconnecting with the pico projector use the HOME button on the media device not the back button to start the EZVIEW application StartEZVIEW wireless application and follow the on screen prompts.
- Page 10 MENU slide left/right options After selecting WIFI DLP EZView home screen after PROJECTOR projector making the connection 2) Internet Access mode (requires Internet access point) At the pico projector home screen select SETTING Highlight WiFi Concurrent Mode then press OK Press the right button to highlight box for AVAILABLE EXTERNAL NETWORKS...
-
Page 11: Connecting To Av Sources
Use the UP button to highlight ON then press OK on the remote controller to select Use the UP/DOWN button to select your network name, then press OK to select. When password input window appears, press OK again on the remote controller to display the soft keyboard. -
Page 12: Play From Micro Sd Card And Usb Storage
Play from Micro SD Card and USB storage Insert SD card (or USB drive) After detecting the presence of the SD card (or USB drive), the screen displays the media type screen. Highlight the preferred media type with the LEFT/RIGHT buttons and then select with the OK button Use the UP/DOWN buttons to highlight the file to play then press Ok to select Connecting to External Audio Speaker... -
Page 13: Cleaning The Pico Projector Housing
Cleaning the Pico Projector Housing DO NOT try to service the Pico Projector. Refer all Pico Projector servicing to your dealer. Failure to do so can result in serious personnel injury or damage to the Pico Projector. DO NOT clean the housing with organic solvents, such as those containing acetone. Wipe the exterior of the housing with a soft, damp cloth. - Page 14 should also check the adjustments and the INPUT connections. Verify that all power is switched on. Before calling for service, check the troubleshooting suggestions in this Section. Problem Solutions There is no sound from speaker Set volume to a higher setting. Remove stereo plug from the Audio Out port Remove blockage from all air vents.
-
Page 15: Appendix 1 (Product Specifications)
Appendix 1 Product Specifications Product Specification Display Technology TI DLP Technology Light Source RGB LED Resolution nHD (640x360) Brightness (Typical) 50 Lumens Contrast Ratio 1000 : 1 Built in SD Card playing Pdf, Powerpoint, Excel, Word and USB port Directly for presentation without connecting PC Rechargable Battery Battery capable of running for approx 80mins Speaker...
