WASHLET
SW4547AT60
SW4549AT60
■ Thank you for your recent purchase of this product.
Please read the enclosed information to ensure the safe use of your product.
■ Be sure to read this Instruction Manual before using your product and keep it in a safe place
for future reference.
2020.4.7
D07770
Instruction Manual
Advertisement
Table of Contents
Related Manuals for Toto WASHLET SW4547AT60
Summary of Contents for Toto WASHLET SW4547AT60
- Page 1 1155 Southern Road Morrow, GA 30260 Phone : (770) 282-8686 Warranty Registration and Inquiry For product warranty registration, TOTO U.S.A. Inc. recommends On-Line Warranty Registration. Please visit our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please contact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260 (888) 295 - 8134 or (678) 466 - 1300 when calling from outside of U.S.A.
-
Page 2: Table Of Contents
What functions are available on your product? Keep It Table of Contents Product name, Part No. Safety Precautions ....4 Operational Precautions ..11 Clean Parts Names ......12 Preparation ......14 Basic Operations ....16 Product name (Model) WASHLET Sanitary Toilet Automatic Functions Ref. -
Page 3: Safety Precautions
Safety Precautions IMPORTANT SAFEGUARDS WARNING READ ALL INSTRUCTIONS BEFORE USING Do not use the product if a malfunction occurs. Symbols and Meanings In case of breakdown or other problems, be sure to cut off power by flipping the power switch to •... - Page 4 Safety Precautions (Continued) WARNING CAUTION This is an electrical product. Do not install it anywhere water is likely to get on Do not use the product if the main unit is unstable. the product or anywhere with humidity high enough that water is likely to form Doing so may cause the main unit to come loose and fall, resulting in injury.
- Page 5 Safety Precautions (Continued) CAUTION DANGER To reduce the risk of electrocution: 1. Do not use while bathing. If a water leak should occur, always close the shutoff valve. 2. Do not place or store the product where it can fall or be pulled into a tub or sink. When the ambient temperature is likely to drop to 32 °F (0 °C) or lower, prevent damage to the pipes and hoses due to freezing.
-
Page 6: Operational Precautions
Safety Precautions Operational Precautions (Continued) ■ For prevention of malfunctions ■ For prevention of damage Grounding Instructions ● Do not block the body sensor or the remote control ● Wipe plastic areas transmitter or receiver. such as the main unit and remote control This product should be grounded. -
Page 7: Parts Names
Parts Names Main display Left side of the main unit Right rear of the main unit Power LED Seat LED Power switch Remote control (Page 15) Energy saver LED receiver Soft light CLEAN indicator <All the CLEAN indicator and LEDs light up in the figure> Deodorizer outlet Water filter drain valve Cover... -
Page 8: Preparation
Preparation Using the Product for the First Time 1. Insert the battery If the remote control is secured 2. Turn on the power 3. Open the shutoff valve (for anti theft) Remove the remote control from Fully open the shutoff valve. Switch the breaker on the distribution board to ON. -
Page 9: Basic Operations
Basic Operations ● The "Water pressure adjustment","Wand position adjustment" and "Personal setting" functions are Operate the controls on the remote control; a beep sounds when the main unit receives the signal. swipe operated. ● Functions that operate when a button is pressed Flushing during "Rear cleansing", "Rear soft cleansing"... - Page 10 ▶ Basic Operations You can set as desired About the Menu Screen If you want to return to the previous item, press the button. This section is an overview of the settings that can be configured with the remote control. See the corresponding pages for the detailed descriptions.
-
Page 11: Automatic Functions (Cleaning Features)
Lights to show that the "CLEAN" functions are operating. Automatic Functions Cleaning Features ■Bowl light ■CLEAN indicator Lights to show that auto bowl CLEAN Lights to show that the "clean" As you As you As you and auto wand CLEAN are operating. functions are operating. -
Page 12: Automatic Functions (Convenience Features)
Automatic Functions Convenience Features As you As you As you As you Various automatic functions are available. approach stand up move away • Operation under the initial settings is described below. ■ Changing ■Note settings When using the toilet seat Auto flush is not available in the following •... -
Page 13: Temperature Adjustment
Temperature Adjustment Warm Water, Toilet Seat, Drying Five different temperature levels from high to low and "OFF" can be set. Remove Mount the Press. <Settings Select the Select the item you want to set. the remote remote control complete> temperature level. control from in the hanger. -
Page 14: Energy Saver Features
Energy Saver Features Type Main display "Auto energy saver", "Auto energy saver+" or "Timer energy saver" can be selected. To save energy, the temperature of the toilet seat becomes low (or "OFF"). "Auto energy saver" takes about 10 days to detect time periods in which the toilet seat is never or infrequently used. - Page 15 Energy Saver Features How to Set Set the "Timer energy saver" at the time you want to start it. ENERGY Press. Select SAVER Press 1.AUTO ENERGY [AUTO ENERGY SAVER]. SAVER Auto energy 2.TIMER SAVER Select [ENERGY SAVER]. saver AUTO ENERGY SAVER Select AUTO ENERGY...
-
Page 16: Maintenance
Maintenance Main Unit Main Unit WARNING (Approximately daily) Always flip the power switch to OFF before maintenance or inspection. (Failure to do so may cause electric shock or malfunction, resulting in a breakdown.) Soft cloth soaked in water • Toilet paper •... -
Page 17: Wand
Maintenance Wand Deodorizing Filter Wand Deodorizing Filter (Approximately once a month) (Approximately once a month) <If you notice dirt (Wand cleaning)> Remove the cover on the left side of the main unit, and flip the power switch to "OFF". (Page 30) Remove the deodorizing filter. -
Page 18: Gap Between The Main Unit And Bowl Unit
Maintenance Gap between the Main Unit and Bowl Unit Gap between the Main Unit and Bowl Unit Gap between the Main Unit and Bowl Unit (Approximately once a month) (Approximately once a month) (Continued) You can remove the main unit to clean Mount the main unit. -
Page 19: Gap Between The Main Unit And The Toilet Lid
Maintenance Gap between the Main Unit and the Toilet Lid Water Filter Drain Valve Water Filter Drain Valve Gap between the Main Unit and the Toilet Lid (Approximately once a month) (Approximately once every 6 months) <If you think the water pressure has weakened> The toilet lid can be removed for thorough cleaning. -
Page 20: Changing Settings
Changing Settings Setting List How to Set Available Settings Setting Types Ref. Page • Bold: Initial settings Auto flushing / OFF Set whether or not to clean the bowl unit automatically • • Auto flushing 5seconds / Page 40 • • Change the amount of time before the toilet flushes Auto flush delay 10seconds... - Page 21 Changing Settings Auto flushing AUTO FLUSH Select Press Press. 1.AUTO FLUSH [AUTO FLUSH]. 2.AUTO FLUSH Set whether or not to DELAY MENU clean the bowl unit Select automatically 1.MANUAL CLEANING Auto AUTO [AUTO FUNCTION]. FLUSH Select 2.ENERGY Press SAVER flushing AUTO Press 3.AUTO...
- Page 22 Changing Settings Auto open / close AUTO OPEN /CLOSE Select Press Press. 1.AUTO OPEN /CLOSE [AUTO OPEN/CLOSE]. 2.AUTO CLOSE Set whether or not to DELAY TIME MENU open and close the toilet Select lid automatically 1.MANUAL CLEANING Auto open / AUTO OPEN [AUTO FUNCTION].
- Page 23 Changing Settings Auto open / close (Continued) AUTO OPEN /CLOSE Select Press. 1.AUTO OPEN /CLOSE [AUTO OPEN DELAY]. 2.AUTO CLOSE Press DELAY Change the time period MENU Select 3.AUTO OPEN till automatic opening DELAY 1.MANUAL (After closing by hand.) CLEANING Auto open [AUTO FUNCTION].
- Page 24 Changing Settings Cleaning Features AUTO CLEANING Select Press Press. 1.AUTO WAND CLEAN [AUTO WAND CLEAN]. Set whether or not MENU to clean the wand Select automatically 1.MANUAL CLEANING Auto wand AUTO WAND [AUTO FUNCTION]. CLEAN Select 2.ENERGY Press SAVER CLEAN AUTO WAND 3.AUTO CLEAN OFF...
- Page 25 Changing Settings Cleaning Features (Continued) AUTO CLEANING Select Press. 1.AUTO WAND CLEAN [DEODORIZER]. 2.AUTO BOWL Press Set whether or not to CLEAN MENU Select deodorize automatically 3.DEODORIZER after sitting on the toilet 1.MANUAL CLEANING seat [AUTO FUNCTION]. DEODORIZER 2.ENERGY Press Select Deodorizer SAVER...
- Page 26 Changing Settings Light LIGHT Select Press Press. 1.SOFT LIGHT [SOFT LIGHT]. MENU Set whether or not to Select use the soft light 1.MANUAL CLEANING Soft light SOFT LIGHT [AUTO FUNCTION]. Select 2.ENERGY Press SAVER SOFT LIGHT Press 3.AUTO FUNCTION [ON] or [OFF]. AUTO (To return➝...
- Page 27 Changing Settings Language settings Select 语言 / 語言 / Select the language LANGUAGE Press. displayed on the back of remote control [ 中文简体 ], [ 繁體中文 ] or LANGUAGE 中文简体 ENGLISH Language [ENGLISH]. Press MENU 繁體中文 Select settings ENGLISH 2.ENERGY SAVER (To return➝...
- Page 28 Changing Settings Other settings OTHER SETTING Select Press Press. 1.BEEP [BEEP]. Set whether or not to MENU Select make a beep sound BEEP Beep sound Select 3.AUTO FUNCTION BEEP OFF [OTHER SETTING]. Press 4.语言 / 語言 / Press LANGUAGE [ON] or [OFF]. 5.OTHER SETTING (To return➝...
- Page 29 Changing Settings Other settings (Continued) OTHER SETTING Select Press. 1.BEEP [PERSONAL SETTING]. 2.SETTING Press LOCK MENU Select Set whether or not to 3.PERSONAL SETTING use the personal setting 3.AUTO FUNCTION Personal [OTHER SETTING]. PERSONAL 4.语言 / 語言 / Select SETTING Press Press LANGUAGE...
-
Page 30: What To Do
What to Do? If the water does not flow due to a water service interruption Freeze Damage Prevention When the ambient temperature is likely to drop to 32 °F (0 °C) or lower, take measures to If you cannot operate with the remote control prevent freezing. -
Page 31: Long Periods Of Disuse
What to Do? Long Periods of Disuse If the toilet is in a location you will not visit for a long time, drain the water. Resupplying the Water (The water in the tank may cause malfunctions or become contaminated and cause skin irritation or other problems.) Open the shutoff valve. -
Page 32: Removal Of Operation Guide
Removal of Operation Guide Follow the procedure below. First, try the actions described on pages 63 - 69. If the problem persists, consult the installer, seller, or TOTO customer service (see contact information on the back cover). How to remove the operation guide... -
Page 33: Troubleshooting
➞ Flip the power switch to OFF and wait about 10 seconds before flipping it on again. Flushing If the same symptom reappears. ➞ There may be a malfunction. Consult with TOTO customer service (see contact information on the back cover). Ref. Trouble... - Page 34 Troubleshooting Toilet Seat and Toilet Lid (Auto open/close) Toilet Seat and Toilet Lid Ref. Ref. Trouble Please check Trouble Please check Page Page ● Is "Auto open/close" set to "OFF"? ● Is the toilet seat temperature set to "OFF" or a low level? ➞Set to "ON".
- Page 35 ● Even after sitting down, you do not hear operation sounds. connections seems to be not TOTO customer service (see contact information on the back cover). ➞Sit back on the toilet seat. If you hear an operation sound from the deodorizer, but odors are not...
-
Page 36: Specifications
Vacuum breaker, Check valve device f) Damage or loss resulting from electrical surges or lightning strikes or other acts which are not the fault of TOTO or which Adjustable temperature range: OFF, about 82 - 97 °F (about 28 - 36 °C)
