- Page 1 “Results You Can Count On” Model GHN-AT-PROG-UPLC-3-SLOPE PLC 3-Channel Attenuator with Slope Filter CLI and GUI Reference Guide Rev. - Date of Publication: 04/30/2019...
- Page 2 This document provides the installation and usage instructions for the CLI (Command Line Interface) and GUI (Graphical User Interface) applications for the Model GHN-AT-PROG-UPLC-3-SLOPE PLC 3-Channel Attenuator with Slope Filter. These applications are used to set and read the attenuation levels and slope filter of the attenuation device.
- Page 3 The above warranty is in lieu of all other warranties, expressed or implied, statutory or otherwise, including any implied warranty of merchantability or fitness for a particular purpose. TELEBYTE shall not be liable for any damages sustained by reseller or any other party arising from or relating to any equipment failure, including but not limited to consequential damages, nor shall TELEBYTE have any liability for delays in replacement or repair of equipment.
- Page 4 Equipment Returns Out of warranty equipment may be returned, prepaid, to the Hauppauge, N.Y. customer service facility. Return shipping charges will be billed to the customer. The repaired unit will have a 90-day warranty. In those cases where "no trouble" is found, a reduced charge will be billed to cover handling, testing, and packaging. Whether in or out of warranty, a Return Material Authorization number (RMA) is required and may be obtained by going to www.telebytebroadband.com and opening a technical support case.
-
Page 5: Table Of Contents
Table of Contents Personnel Safety Warning......................1 System Requirements ........................1 Specifications ..........................1 Before You Begin ........................... 2 Application Installation Steps ....................... 3 Command Line Interface (CLI) ...................... 3 Graphical User Interface (CLI) ...................... 6 Control ............................. 7 CLI Overview ..........................7 6.1.1 CLI Commands .......................... -
Page 6: Personnel Safety Warning
1.0 Personnel Safety Warning For personnel safety, the metal enclosure of the GHN-AT-PROG-UPLC-3-SLOPE must be earth grounded. Connect one end of an AWG16 cooper wire to the lug provided with the enclosure and the opposite end of the wire to the facility earth ground. -
Page 7: Before You Begin
4.0 Before You Begin Control of the Model GHN-AT-PROG-UPLC-3-SLOPE PLC 3-Channel Attenuator with Slope Filter (referred to as the device) is accomplished through a Command Line Interface (CLI) or the PLC Test Center Graphical User Interface (GUI). Options available include the ability to set the attenuation and slope filter values for one to three channels, on each of one to nine devices. -
Page 8: Application Installation Steps
5.1 Command Line Interface (CLI) • To install the CLI setup program, click on “Telebyte GHN-AT-PROG-CLI Setup 1.3.0” and follow the instructions. The Select Additional Tasks screen is shown. • Click Next. The Ready to Install screen is shown. - Page 9 • Click Install. When the installation is done, the Completion screen is shown. • Click Finish GHN-AT-PROG-UPLC-3-SLOPE Reference Manual Page 4 of 12...
- Page 10 ➢ Windows will require .Net Framework 3.5 to be installed only if the requried files are not found. • Click on Download and install this feature. GHN-AT-PROG-UPLC-3-SLOPE Reference Manual Page 5 of 12...
-
Page 11: Graphical User Interface (Cli)
5.2 Graphical User Interface (CLI) • To install the GUI program, click on “Telebyte GHN-AT-PROG-GUI Setup 1.3.0” and follow the same procedure as explained in of CLI Installation section. GHN-AT-PROG-UPLC-3-SLOPE Reference Manual Page 6 of 12... -
Page 12: Control
The CLI allows the user to send commands to set the attenuation and slope filter values on each device. All devices must be connected to the system. ➢ When the user connects any Telebyte device to the system, the Refresh command is used to update the device list. - Page 13 Show attndevicelist displays all devices connected to the system along with User ID Number and Device Index. • Set Command Example Set attn sets the attenuation level of a specified channel (or range of channels) on a specified device (or range of devices). GHN-AT-PROG-UPLC-3-SLOPE Reference Manual Page 8 of 12...
-
Page 14: Cli Command List
ChannelNum - single, range (separated by colon), or in group (separated by comma) AttnValue - single or in group (separated by a comma) SlopeFilterState - numeric value (range: 1 to 100) newUserIDNum - maximum of 8 characters GHN-AT-PROG-UPLC-3-SLOPE Reference Manual Page 9 of 12... -
Page 15: Plc Test Control Center Overview
The PLC Test Control Center GUI provides one device panel for each device connected to the system. Up to nine devices may be controlled through this GUI. ➢ When the user connects any Telebyte device to the system, click Refresh in the lower-right corner of the interface to update the device panels. - Page 16 • To change the User ID for a device, click the Edit icon in the upper-right corner of the device panel. The Enter new user ID dialogue box is shown. • Enter the new User ID number and click OK. GHN-AT-PROG-UPLC-3-SLOPE Reference Manual Page 11 of 12...
-
Page 17: Status Messages
6.2.2 Status Messages • BUSY: Settings are being saved. • SUCCESS: Settings successfully saved • READY: Ready to configure • FAIL: Failed to save settings GHN-AT-PROG-UPLC-3-SLOPE Reference Manual Page 12 of 12...
