LIFA Duct Control Cleaning Robot
OPERATING AND MAINTENANCE INSTRUCTIONS
Combined brushing machine and inspection camera robot operated with electricity and compressed
air, for circular and rectangular ducts.
These instructions must always be available to personnel using the equipment. Please read
instructions before operating the machine. Observing the instructions carefully will guarantee many
years of trouble-free use.
IMPORTANT!
Read this manual before you operate the machine
Lifa Air Oy Ltd. • Vellamonkatu 30 B, 00550 Helsinki, Finland • Tel: +358 9 394 858
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lifa Air LIFA Duct Control Cleaning Robot
Summary of Contents for Lifa Air LIFA Duct Control Cleaning Robot
- Page 1 Observing the instructions carefully will guarantee many years of trouble-free use. IMPORTANT! Read this manual before you operate the machine Lifa Air Oy Ltd. • Vellamonkatu 30 B, 00550 Helsinki, Finland • Tel: +358 9 394 858...
-
Page 2: Table Of Contents
Driving the robot with Duct Control Manual or Mini ............10 Spare parts ........................13 Accessories ........................14 Problem situations ......................15 Warranty ..........................16 Recycling ........................... 16 Declaration of Conformity ....................17 Lifa Air Oy Ltd. • Vellamonkatu 30 B, 00550 Helsinki, Finland • Tel: +358 9 394 858... -
Page 3: General Directions
Also, the CE-marking plates in robot may fade over time and use, so necessary information is found from your office records also. Lifa Air Oy Ltd. • Vellamonkatu 30 B, 00550 Helsinki, Finland • Tel: +358 9 394 858... -
Page 4: Lifa Duct Cleaning Robot
Lifa Duct Cleaning Robot Congratulations for your new Lifa Duct Control Cleaning Robot from Oy Lifa Air Ltd. Lifa Duct Control Cleaning Robot is designed and manufactured according to international quality- and environmental management system ISO 9001:2008 and ISO 14001:2004. - Page 5 (40m). The brushed off dirt is collected in to a bag filter of the negative pressure air vacuum unit, i.e. LIFA Hepa Clean 2500, 4000 or LIFA Air Clean 3500.The minimum size of the service hatch / access door is 300 mm in width and 200 mm in height.
-
Page 6: Principle Of Operations
Robot/Cable. Lifa Air Oy Ltd. • Vellamonkatu 30 B, 00550 Helsinki, Finland • Tel: +358 9 394 858... -
Page 7: Safety
Wear protective mask, eye protection glasses, overall, gloves shoes etc. according to the requirements of the working place/environment. • In any questions, contact Lifa Air Ltd, or an authorized dealer. Lifa Air Oy Ltd. • Vellamonkatu 30 B, 00550 Helsinki, Finland • Tel: +358 9 394 858... - Page 8 Lifa Duct Control Cleaning Robot has a strong rotating force. Clothes or hair can easily get caught in the brush and cause damage or accidents. The brush has to be placed always in the ventilation duct before starting the machine.
-
Page 9: Construction And Installation
3) A double hose on metallic reel with operation valve for brush motor (accessory) 4) A separate single hose with valve for air jetting or liquid spraying (accessory) Lifa Air Oy Ltd. • Vellamonkatu 30 B, 00550 Helsinki, Finland • Tel: +358 9 394 858... -
Page 10: Driving The Robot With Duct Control Manual Or Mini
Double hose reel for and controlling the brush motor and rotation direction. 1) Operation valve for brush motor/changing direction for motor rotation 2) Double hose on reel for pneumatic brush motor Lifa Air Oy Ltd. • Vellamonkatu 30 B, 00550 Helsinki, Finland • Tel: +358 9 394 858... - Page 11 3. Electrical connection Lifa Duct Control Cleaning Robot requires a power supply (12V DC) that is the battery of Duct Control Manual or Mini. When switching on the central box of Duct Control Manual or Mini a red light at the central box will light up if the power supply is OK.
- Page 12 The air nozzles have to be cleaned after each use: air nozzles with an air pistol, and chemical nozzles with water / Lifa Air Oy Ltd. • Vellamonkatu 30 B, 00550 Helsinki, Finland • Tel: +358 9 394 858...
-
Page 13: Spare Parts
We are not responsible for any service or repair carried out by a third party. Warranty also expires if any other than Lifa accessories (brushes etc.) are used. Lifa Air Oy Ltd. • Vellamonkatu 30 B, 00550 Helsinki, Finland • Tel: +358 9 394 858... -
Page 14: Accessories
(including fast coupling) 6411517083105 Y-dual knife (nozzle) with adjustable-bending arms) for large rectangular ducts 6420281024245 Lifa Drop Camera (manually pushed, for small ducts) Lifa Air Oy Ltd. • Vellamonkatu 30 B, 00550 Helsinki, Finland • Tel: +358 9 394 858... -
Page 15: Problem Situations
If there are any old detergents etc. left in the hose they may cause the hose to clog. The hose can be tried to open by spraying warm water or mild detergent solution in to the hose. Lifa Air Oy Ltd. • Vellamonkatu 30 B, 00550 Helsinki, Finland • Tel: +358 9 394 858... -
Page 16: Warranty
Electrical parts (frequency converter, main switch) should be returned to an authorized recycling depot. Other parts can be recycled as mixed normal waste. Lifa Air Oy Ltd. • Vellamonkatu 30 B, 00550 Helsinki, Finland • Tel: +358 9 394 858... -
Page 17: Declaration Of Conformity
EN 60204-1:2007 Safety of machinery. Electrical equipment of machines. General Requirements. The product fulfils requirements for CE-marking. Oy Lifa Air Ltd., 31.01.2018 Johan Brandt, CEO Lifa Air Oy Ltd. • Vellamonkatu 30 B, 00550 Helsinki, Finland • Tel: +358 9 394 858...
