AVLT-Power AVLT-DM24-1 Instruction Manual

Freestanding articulating dual monitor stand for 13”-32” screen size

Advertisement

Quick Links

Freestanding Articulating Dual Monitor Stand
for 13"-32" Screen Size
AVLT-DM24-1
10Kg
22lbs
each
AP4-0051B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVLT-DM24-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for AVLT-Power AVLT-DM24-1

  • Page 1 Freestanding Articulating Dual Monitor Stand for 13”-32” Screen Size AVLT-DM24-1 10Kg 22lbs each AP4-0051B...
  • Page 2 Thank you for choosing our products! UNPACKING INSTRUCTIONS Carefully open the carton, remove contents and lay out on cardboard or other protective surface to avoid damage. Check package contents against the Supplied Parts List in the next page to assure that all components were received undamaged.
  • Page 3 Supplied Parts List (1)Pole-a (1)Weighted Base-b (1)Swivel Arm-c (2)VESA Plate-d (3)M5x14 Bolt-e (2)Nut-f (1)M10 Bolt-g (1)Support Plate-h (1)Grommet Base (1)M10 Washer-i (1)Spring Washer-j (1)Wire Clip-l1 Plate-k (8)M4x12 (4)Wire Clip-l2 (1)Allen Key-m (1)Wrench-n Thumb Bolt-o (8)M4x30 Bolt-p (8)M4 Spacer-q (1)Soft Pad-r...
  • Page 4 Step 1 Install the Pole to the Desktop Option A: Weighted Base Install 1. Install the Pole(a) to the Weighted Base(b) using 3pcs M5x14 Bolts(e), and tighten using the Allen Key(m), see Figure 1. 2. Optionally, you can drill a 10mm diameter hole in your desk and secure using the Support Plate (h), M10 Wash- er(i), Spring Washer(j) and M10 Bolt(g).
  • Page 5 Step 1 Install the Pole to the Desktop Option C: Grommet Base Install Self Drilled Grommet Hole Installation 1.Position the Pole(a) on the mounting surface and mark the center hole. Drill a 3/8" (10mm) diameter hole at the marked posi- tion through the mounting surface.
  • Page 6 Step 3 Attach the VESA Plate to the Monitor For Monitor with Flat Back For Monitor with Curved or Recessed Back Step 4 Slide the Monitor onto the Head of Swivel Arm Slide the monitor onto the head of Install the security Nut(f). Make sure the Swivel Arm(c) as shown in the above security nut is installed before you rotate diagram.
  • Page 7 Step 5 Make the Necessary Adjustments Ignore this step if Fix the tilt angle monitors are level Tighten the bolt with the supplied Allen If one monitor is lower, remove the Nut(f) Key(m) to fix the tilt angle. and turn the bolt counter-clockwise with supplied Allen key(m) to raise the monitor.
