Safco 9728 Quick Start Manual

LETTER
DESCRIPTION
CODE
A Left Side Panel
B Back Panel
C
Right Side Panel
D Bottom Panel with Glides
E Top Panel
F Small Door (reversible)
Hinge Plate with Peg
G
Button Head Bolt
H
TOOLS REQUIRED: FLAT-BLADED & PHILLIPS SCREWDRIVER, WRENCH, RUBBER MALLET
Note; when corresponding about wood parts, be sure to state color (gray or medium oak)
B
A
N
1
Locate the B Back Panel and lay it down on a
smooth, clean surface with the cam locks facing
up. Lay the A Left Panel and the C Right Panel
on the left and right sides
of the Back Panel.
Arrange the E Top
Panel, and D Bottom
Panel (Bottom Panel has
four female Cam Locks
on one side and four
plastic feet on bottom
side) at the top and
bottom ends of the Back
Panel with the cam locks
facing up. Fasten the O
Bumper to the Right Side
Panel using the P Small
Bumper Screw.
9728-37: 1 of 2; Rev. 1: 06/01
Waste Receptacle

PARTS LIST

QTY. PART NO.
1 9728-03
1 9728-01
1 9728-04
1 9728-02
1 9728-05
1 9728-07
2 9728-29
4 9728-23
E
K
M
D
A
LEFT PANEL
(Mounting holes for two
Hinges on one side)
Safco Products Company, New Hope, MN 55428
PARTS LIST
LETTER
DESCRIPTION
CODE
I Nut
J
Plastic Insert
K
Mounting Screw
L Large Door
M Door Hinge Mount Plate
N
Door Hinge
O
Bumper
P Small Bumper Screw
G
I
F
H
L
For questions or concerns, please call
Safco Consumer Hot Line: 1-800-664-0042
available Monday-Friday 8:00 AM to 4:30 PM (Central Time)
(English-speaking operators)
B
E
CAM
LOCK
(Male)
MODEL
NUMBER
QTY. PART NO.
4 9728-24
2 9728-30
8 9728-27
1 9728-09
2 9728-14
2 9728-15
1 9728-16
1 9728-25
C
J
ASSEMBLED UNIT
O
Model 9728
P
C
O
P
UNFINISHED
EDGES
CAM
LOCK
(Female)
9728
