Page 2: Safety Statements
Instruct all personnel on the safe use and maintenance procedures related to this equipment. Discuss any questions on the application, use, or maintenance of this equipment with a Donaldson Torit representative. For optimum collector performance, use only Donaldson Torit replacement parts. -
Page 3: Table Of Contents
Centrifugal Mist Collector Contents Safety Statements ...........2 Optional Equipment ..........11 Prefilter Trap ..........11 Data Sheet ..............3 In-Cover Trap ..........11 Description.............4 In-Cover Impinger ..........12 Purpose and Intended Use ........4 HEPA Filter ............13 Operation...............5 Preliminary Start-Up Check ........14 Inspection on Arrival ..........6 Service Information ..........14 Installation Codes and Procedures......6 Operational Checklist ........14... -
Page 4: Description
Consult and comply with all National and Local Codes related to fire and/or explosion properties of combustible materials when determining the location and operation of all dust, fume, or mist collection equipment. Standard Donaldson Torit equipment is not equipped with fire extinguishing or explosion protection systems. -
Page 5: Operation
Centrifugal Mist Collector Operation During normal operation, mist-laden air enters the housing by centrifugal force. High velocity air drives collector through a flexible hose. The air passes the liquid or oil along the housing walls, through a through a disposable first-stage filter and into circumferential slot, and into a collection chamber a second-stage primary filter. -
Page 6: Inspection On Arrival
Donaldson Company, Inc. Inspection on Arrival Installation 1. Inspect unit on delivery. Site Selection, Grade-Mounted Units 2. Report any damage to the delivery carrier. The unit can be located on a reinforced concrete 3. Request a written inspection report from the foundation. -
Page 7: Rigging Instructions
Centrifugal Mist Collector Rigging Instructions Electrical Wiring Failure to lift the collector Electrical installation must correctly can result in severe be performed by a qualified personal injury or property damage. electrician and comply with all applicable national and local codes. Use appropriate lifting equipment and adopt all safety precautions needed for Lock out electrical power sources before... -
Page 8: Standard Equipment
Donaldson Company, Inc. Standard Equipment The Centrifugal mist collector is normally installed Ductwork horizontally; however, it can be installed vertically with the inlet end down. 1. Attach one end of the flexible hose to the inlet cover and secure with a hose clamp. 1. -
Page 9: Drain Connection
The secondary drain fitting is a 1/4-in NPT 900 EL connection. Use 3/4-in diameter hose for Models fitting and connects the same way the primary drain E-100 and E-200, and 1-in for all other models. connects. 2. Models E-100 and E-200 are equipped with a Do not submerge ends of hose. -
Page 10: Electrical Connection
Donaldson Company, Inc. Electrical Connection Electrical installation must Wire unit according to the wiring diagram located be performed by a qualified on the motor conduit box cover. Collectors be wired electrician and comply with all applicable for 220 or 440-Volt, 60 Hz, 3 Ph supply power. national and local codes. -
Page 11: Optional Equipment
Centrifugal Mist Collector Optional Equipment In-Cover Trap Prefilter Trap Prefilter Trap In-Cover Trap... -
Page 12: In-Cover Impinger
Donaldson Company, Inc. In-Cover Impinger In-Cover Impinger... -
Page 13: Hepa Filter
Centrifugal Mist Collector HEPA Filter HEPA Filter... -
Page 14: Preliminary Start-Up Check
Donaldson Company, Inc. Preliminary Start-Up Check 1. Check all electrical connections for tightness and 3. Starting at the mark made in Step 1, slide the contact. replacement liner under each blade until the ends come together. 2. Check for and remove all loose items in or near the inlet and outlet of the unit. -
Page 15: Troubleshooting
Centrifugal Mist Collector Troubleshooting Problem Probable Cause Remedy Unit will not start Improper motor wire size Rewire using the correct wire gauge as specified by national and local codes. Not wired correctly Check and correct motor wiring for supply voltage. See motor manufacturer's wiring diagram. -
Page 16: Service Notes
Donaldson Company, Inc. Service Notes Date Service Performed Notes... - Page 17 Centrifugal Mist Collector Date Service Performed Notes...
- Page 18 This Page Intentionally Left Blank...
-
Page 20: Warranty
The Donaldson Torit Warranty Donaldson warrants to the original purchaser that the major structural components of the goods will be free from defects in materials and workmanship for ten (10) years from the date of shipment, if properly installed, maintained and operated under normal conditions. Donaldson warrants all other Donaldson...
