QIKBOX Assembly instructions
Identify if ribs need removing prior to adding power/data/
1
AV to QIKBOX
Ribs don't need removing
Ribs do need removing
QF5 data/AV
Power Module
+ TUF
Power Module
+ QF5 Data/AV
2 x Power
Module
UK -
sales@oeelectrics.co.uk / +44 (0) 1924 367 255
AUS -
sales@oeelsafe.com.au / 1300 ELSAFE (357 233)
INSTR1209
DE -
info@oeelectrics.de / +49 (0)2261 958 3001
U.S.A -
sales@oeelectrics.com / +1 (844)-927-0600
www.oeelectrics.com
Advertisement
Summary of Contents for OE electrics QikBOX
- Page 1 INSTR1209 www.oeelectrics.com QIKBOX Assembly instructions Identify if ribs need removing prior to adding power/data/ AV to QIKBOX Ribs don’t need removing Ribs do need removing QF5 data/AV Power Module + TUF Power Module + QF5 Data/AV 2 x Power Module...
- Page 2 INSTR1209 www.oeelectrics.com QIKBOX Assembly instructions For QIKBOX with 2 x power modules see next page Mark mounting holes. Use No.10 pan head screws.Length dependent on surface Attach mounting clips to QIKBOX mounted to. 263.5 22.0 44.0 263.5 22.0 Align QIKBOX with surface and screw into 44.0...
- Page 3 Attach mounting clips to QIKBOX mounted to. 263.5 22.0 44.0 Align QIKBOX with surface Add modules to QIKBOX, align to right hand side first and screw into place Right Left QF1 spacer required at Add power cable right hand side...
