PRISM installation instructions
Optional
Optionnelle
Optionel
Cutout Dimensions
Format de Découpage
Asschnit Maße
Three standard sizes
Trois dimensions standard
Drei standard Länge
272
191
10
For non-standard sizes please call:
Pour les dimensions differentes, merci de nous appeler:
Fur kündenspezifi sche Bestükung, bitte wenden Sie sich
an:
Contents
Sommaire
Inhalt
430
+44 (0) 1924 367255
N:\Instructions\Prism & Platinum\INSTR 1028 Prism Installation\prism-instructions 1028d Prism Installation
Underdesk clearance:
Espace disponible sous plan de travail:
Notwendige tiefe unter der tischplatte:
175
A = 35 mm
A = 60 mm
Orientation / Orientation / Orientierung
Workstation / Plan de travail / Tischplatte:
Consider cable exit direction when unit closed
Consideréz la direction de sortie de câble quand i'unité
est fermée
Bedenken sie kabelausgang richtung, als einheit
geschloßen ist
Or / Ou / Oder
132
Conference / Conférence / Konferenz
Unit can be accessed from both sides when open
Accès possible à des deux côtés quand l'unité est ouverte
Einheit kann von beiden seiten erreicht werden,wenn
geöffnet
1 Calder Point, Monckton Road Industrial Estate
Wakefi eld, West Yorkshire, WF2 7AL
Tel: +44 (0) 1924 367255 Fax: +44 (0) 1924 290652
Email: sales@oeelectrics.co.uk
