Z-Wave™ Long Range
Garage Door Controller
M/K: GDZW7-ECO
Revision 2
Product Overview
The Garage Door Controller is a security device for users to wirelessly control and monitor their garage door.
It monitors and reports the state of the garage door through use of a paired wireless (or wired) tilt sensor. It
can also determine when the garage door is active by utilizing an accelerometer to detect specific vibration
patterns. The Garage Door Controller may ignore commands to control the garage door if it deems that is
unsafe to execute the command.
Product Specification
•
Supports Z-Wave™ Long Range (must be added via SmartStart)
•
Indoor use only
•
Operating Frequency: 345MHz, Z-Wave (908.42MHz, 916MHz), Z-Wave Long Range (912MHz,
920MHz)
•
Operating Temperature: 0°F to 120°F
•
Power: 12VDC, 1.0A
•
Accelerometer 2-16G I2C/SPI
•
External contact for installer to opt in using magnetic contact instead of using tilt sensor for
determination of the garage door's state
•
Temperature sensor
•
S2 Encryption
User Manual
1 |
P a g e
Advertisement
Table of Contents
Related Manuals for Ecolink GDZW7-ECO
Summary of Contents for Ecolink GDZW7-ECO
- Page 1 Z-Wave™ Long Range Garage Door Controller User Manual M/K: GDZW7-ECO Revision 2 Product Overview The Garage Door Controller is a security device for users to wirelessly control and monitor their garage door. It monitors and reports the state of the garage door through use of a paired wireless (or wired) tilt sensor. It can also determine when the garage door is active by utilizing an accelerometer to detect specific vibration patterns.
- Page 2 Definitions • Panel or Controller are used interchangeably here and is what you are pairing the device with. • Device Specific Key (DSK) – PIN Code and QR-Code Used for inclusion and to setup encrypted S2 communication. • S2 – Secure Communication Technology. •...
-
Page 3: Factory Reset
The Garage Door Controller pairs with the tilt sensor to monitor the state of the garage door. The original (included with the Garage Door Controller) tilt sensor does not need to be added. To add a different Ecolink ClearSky tilt sensor: 1. Locate and press the tilt button. There will be a short beep. -
Page 4: What Is Z-Wave
Adding an External Contact Alternatively, the Garage Door Controller can pair with an external contact to monitor the state of the garage door. To add a hardwired external contact: 1. Connect the external contact’s wires to the Garage Door Controller’s blue terminal block 2. - Page 5 Mapping of the Basic Command Class The Garage Door Controller has the Basic Command Class mapped to the Barrier Operator Command Class such that a Basic Set of a value is the equivalent of a Barrier Operator Set of a target value. A Barrier Operator Report with a state of 0x00 will map to a Basic Report with a current value of 0x00.
- Page 6 Any state/command pair not specified in the following figure will not cause any action: The Garage Door Controller will not respond to Set Commands if any of the following issues are detected: No tilt sensor is paired Tilt sensor is tampered Tilt sensor counter is out of sync Tilt sensor is lost (Garage Door Controller hasn’t heard from the tilt sensor in 2 hours) Tilt sensor is in the wrong state...
- Page 7 Read only Min Value Max Value Default Value 2. Relay Switch Period Description Number of milliseconds to turn on relay switch for. Size Format Unsigned Integer Read only Min Value Max Value 5000 Default Value 1000 3. Door Open Timeout Description Seconds allowed for garage door to open until timeout.
- Page 8 6. Application-Level Retries Description Number of attempts on top of the stack-level retries to try to reach the controller/hub with Z-Wave messages. Size Format Unsigned Integer Read only Min Value Max Value Default Value Indicator Indicator Name Binary Level Time On-Off On-Off Period...
- Page 9 Indicator (LED and Beeper) States Event LED Behavior Beeper Behavior Beeper Tone SmartStart 3 green blinks (500ms on/off), off None None for 3 seconds Classic Inclusion 3 green blinks (500ms on/off), off None None for 3 seconds Inclusion in progress repeated green blinks (100ms None None...
-
Page 10: Troubleshooting
Troubleshooting Problem Possible Cause Solution Unable to add device Device was not properly Try removing the device by putting the Z-Wave to Z-Wave network excluded from a previous Z- controller into exclusion mode and then Wave network pressing the Garage Door Controller’s Hub button. -
Page 11: Fcc Compliance Statement
Warranty Ecolink Intelligent Technology Inc. warrants that for a period of 1 year from the date of purchase that this product is free from defects in material and workmanship. This warranty does not apply to damage caused by shipping or handling, or damage caused by accident, abuse, misuse, misapplication, ordinary wear, improper maintenance, failure to follow instructions or as a result of any unauthorized modifications.
