SOMOMA SQUARE FIRE PIT ASSEMBLY INSTRUCTIONS
ASSEMBLE ON A FLAT, PROTECTED SURFACE.
PHILLIPS HEAD SCREWDRIVER NEEDED FOR ASSEMBLY, NOT INCLUDED.
PART LIST
A
B
C
D
E
F
G
H
I
FOR MISSING OR INCORRECT PARTS/HARDWARE, CONTACT THE MANUFACTURER'S CUSTOMER SERVICE DIRECTLY AT
REFER TO LAST PAGE FOR ADDITIONAL CUSTOMER SERVICE DETAILS.
SAVE THESE INSTRUCTIONS
STYLE #:
91SRRFR02
FIGURE
QUANTITY
3 PC+1 PC
2 PC+1 PC
CUSTOMERCARE@CHINA-YAYI.COM OR 855-600-9294
1 PC
1 PC
2 PC
2 PC
SIDE PANEL WITH HANDLE
1 PC
1 PC
1 PC
DESCRIPTION
HANDLE
MESH COVER
SIDE PANEL
BASE
POKER
NUT
BOLT
(M6 x 12MM)
WRENCH
Page 1/5
