PHILLIPS HEAD SCREWDRIVER AND WRENCH NEEDED FOR ASSEMBLY; NOT INCLUDED.
PART LIST
A
B
C
D
E
F
G
H
I
J
SAVE THESE INSTRUCTIONS
SONOMA 30" FIRE PIT ASSEMBLY INSTRUCTIONS
STYLE #:
ASSEMBLE ON A FLAT, PROTECTED SURFACE.
FIGURE
61SRR51
QUANTITY
1 PC
1 PC
1 PC
1 PC
1 PC
4 PCS
1 PC
1 PC + 1 PC
12 PCS + 1 PC
12 PCS + 1 PC
DESCRIPTION
HANDLE
MESH COVER
WOOD GRATE
FIRE BOWL
RING
LEGS
POKER
NUT
BOLT
FLAT WASHER
Page 1/3
Advertisement
Table of Contents
Related Manuals for Kohl's 61SRR51
Summary of Contents for Kohl's 61SRR51
- Page 1 SAVE THESE INSTRUCTIONS SONOMA 30" FIRE PIT ASSEMBLY INSTRUCTIONS STYLE #: 61SRR51 ASSEMBLE ON A FLAT, PROTECTED SURFACE. PHILLIPS HEAD SCREWDRIVER AND WRENCH NEEDED FOR ASSEMBLY; NOT INCLUDED. FIGURE DESCRIPTION PART LIST QUANTITY HANDLE 1 PC MESH COVER 1 PC...
- Page 2 ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 61SRR51 STEP 1 A. INSERT HANDLE (A) INTO HOLE IN MESH COVER (B) AND SECURE IT WITH NUT (H) USING WRENCH, NOT INCLUDED. TIGHTEN COMPLETELY. STEP 2 A. PLACE FIRE BOWL (D) UPSIDE DOWN ON FLAT, PROTECTED SURFACE.
- Page 3 ASSEMBLY INSTRUCTIONS (CONTINUED) STYLE #: 61SRR51 **WE RECOMMEND THAT YOU PERIODICALLY TIGHTEN ALL BOLTS WITH PHILLIPS HEAD SCREWDRIVER AND BOLT WITH WRENCH, NOT INCLUDED. WEIGHT LIMIT 50 LBS CARE AND CLEANING 1. TO AVOID METAL CORROSION OR DAMAGE, DO NOT USE WATER TO EXTINGUISH FLAMES.
