Befestigung
Fixation
Fissaggio
Fijación
Connection
1
CAUTION:
Shower arm will not support additional loads -
DO NOT HANG OR PULL ON SHOWER HEAD OR
SHOWER ARM!
SW 12
ø 8 mm
3
6
2
4
7
4
5
