Roberto Sport srl
Via A. Casale 63/A (Zona Industriale), 10010 Lessolo, TO
ITALY
P.I. 05961970018
Tel. +39 0125 58848 - Fax +39 0125 58851
info@robertosport.it /www.robertosport.it
INTERNATIONAL CHAMPION COVER
Thank you for choosing one of Roberto Sport's products. Our tables are famous for their quality and
accuracy of their components. Roberto Sport has been producing table soccer, pool and hockey tables for
more than 65 years. Huge experience and tradition, constant research and innovation have brought
Roberto Sport's name as a synonymous of the "Made In Italy" football tables all over the world.
Unpacking and assembly operation should be carried out entirely by adults. Keep children away throughout
all steps. All small parts such as bolts, screws etc., not yet assembled, and nylon bags might be swallowed or
The model you just bought is for INDOOR USE. For this reason we suggest you to install it in sheltered
In order to keep your tables performance at a high level, we suggest you clean it periodically by using a
humid dust cloth. For difficult stain you may use abrasive-free detergents. For an utmost sliding rods: we
suggest you get the external part of the rod lubricated (the one in touch with the bushing) along with the
rod's internal part by using a silicon spray. Roberto Sport uses and supplies a special silicon spray studied,
produced and tested for these purposes. Do not use grease; it holds the dust and might block the rod
sliding. The telescopic rods assembled on this table are of a highly safe. To prevent rods bending, we
For any problem you might have, or any info you might need, do not hesitate to visit our web site:
Roberto Sport has a two- year warranty for its products starting from the acquisition date. Warranty covers
manufacture defects only; it doesn't cover damages caused by misuse or assigned to be due to wear & tear.
A manufacture defect must be reported at the earliest by a written communication within two months. A
written notification must be sent to the vendor. Roberto Sport is committed to restore the table with no
charge on the buyer by repairing or replacing the damaged part/parts or by offering a discount.
/

GENERAL WARNINGS

CARE & MAINTENANCE
environment, with low humidity degree and direct sun bean free.
recommend you do not load weight on the rods when extended.
www.robertosport.it or contact us at:
inhaled.
sales@robertosport.it

WARRANTY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INGLESE and is the answer not in the manual?

Questions and answers

Summary of Contents for Roberto Sport INGLESE

  • Page 1 (the one in touch with the bushing) along with the rod’s internal part by using a silicon spray. Roberto Sport uses and supplies a special silicon spray studied, produced and tested for these purposes. Do not use grease; it holds the dust and might block the rod sliding.
  • Page 2 PARTS LIST Lubricant spray Balls Scoring unit Material for legs assembly Iron crossbar Iron legs Locknut diam. 10mm Metal flat 10x30 Screw 8x120 (for crossbar) Plastic flat Foot diam. 80 Metal flat 12x32 L allen spanner 6 Material for rods Screw 5x20 Set complete of rods Material for aluminium trim...
  • Page 3 ASSEMBLY INSTRUCTIONS The football table is packed in a carton box with the rods and legs to be assembled. The assembly operation is very simple and needs about 45 minutes. To start please follow the below instructions. Please read and keep these instructions for future reference. You have received your table with the top cover, at least you must remove it.
  • Page 4 Fixing the coin mechanism Rods assembly...
  • Page 5 Fixing the aluminium trim Metal part for ball exit and top cover assembly...
