Note: Be sure to check all packaging materials for any small parts that may have come
loose during transportation.
Assembly
Attach the six cross members to one of the side frames, using six of the screws supplied.
1.
Lay this side frame on the floor with the cross members pointing upwards.
2.
Carefully position the second side frame on top of the cross members. Attach using the remaining
3.
screws.
With the assembled frames still on their side, screw the covers and castors into frames.
4.
Note: The braked castors should be at the front of the trolley. If the castors are not
evenly touching on the floor, adjust the castors until it evenly assembled and
firmly fix with the hex nut.
VOGUE, Fourth Way, Avonmouth Bristol, BS11 8TB, United Kingdom
Assembly Instructions
Gastronorm Trolley
Parts
Part
Side frame
Cross members
Castors
Castors with brakes
Castor covers
Screws
Nuts
pe
Allen Key
Safety Tips
•
DO NOT stand or climb on the trolley.
•
DO NOT drop heavy items on the trolley.
•
DO NOT place heavier items on the top of the trolley than
on the bottom.
•
Whilst all care has been taken to remove sharp edges, care
must be taken when cleaning or handling the trolley to
prevent risk of injury from exposed metal edges.
Cleaning
•
Clean the trolley using warm soapy water.
•
Dry thoroughly after cleaning.
U376
Quantity
x4
x2
x6
x2
x2
x4
12
x1
x1
