Colour Television
Service Manual
Model CE28FWN4F-C
Service Ref. No. CE28FWN4F-C-00
111366005
PRODUCT CODE:
ORIGINAL VERSION: Chassis No. EB7-A
Please use Schematic Diagram SKP20430 with
this Service Manual.
Give complete "SERVICE REF. NO." for parts
order or servicing, it is shown on the rating sheet
on the cabinet back of the TV set.
Note
This TV receiver will not work properly in foreign
countries where the television transmission
system and power source differ from the design
specifications. Refer to the specifications for the
design specifications
Contents
Safety precautions/Specifications ..................................................................................................................2
Block diagrams ..............................................................................................................................................3
Cabinet Disassembly ......................................................................................................................................4
Adjustment and Repair Procedures............................................................................................................5~9
CPU Functions ..............................................................................................................................................................................10~11
Component Locations ..................................................................................................................................12
IC Block Diagrams ..................................................................................................................................13~15
Pin description of semiconductors ................................................................................................................16
Part Description and reading of schematic diagram ....................................................................................17
Cabinet Parts List/TV Stand parts list ..........................................................................................................18
Electric Parts List ....................................................................................................................................19~26
Part No. SKSM0647
CE28FWN4F-C-01
C6AFL
MARCH 2003
28FWN4F
CE
-C
