Related Manuals for Aura AMH-600BT
Summary of Contents for Aura AMH-600BT
- Page 1 OWNER’S MANUAL AMH-600BT CAR BLUETOOTH / USB RECEIVER WARNING! PLEASE READ CAREFULLY BEFORE USING...
- Page 2 Copyrights is a registered trademark. All rights reserved. This document in whole or in part may not be reproduced or copied without the prior written permission of the manufacturer. All brand and product names used in this document are trademarks or registered trademarks of their respective companies.
-
Page 3: Table Of Contents
Content Precautions................... Package bundle and installation............Connection.................... Appearance, control elements.............. Overall size.................... Remote control..................Main functions..................Settings....................Radio..................... USB....................... Bluetooth....................Phone app..................... Technical features.................. -
Page 4: Precautions
Precautions This user manual contains important safety advice and information on the correct use of the device. Please follow all instructions in this manual carefully. 1. While installing the device, avoid places with high temperature, humidity, or dusty places. 2. Make sure that the device and especially its installation accessories are out of the reach of children. -
Page 5: Package Bundle And Installation
Package bundle and installation Open the package and make sure that inside include: 1. USB-receiver - 1piece 2. Remote control - 1 piece 3. Keys for receiver remove - 2 pieces 4. ISO - jack- 1 piece 5. Instruction 6. Guarantee 7. -
Page 6: Connection
Connection 1. Make sure that the on-board voltage of your vehicle is +12 volts 2. Remove the fuse from the device before connecting the wires. 3. Connect the yellow (A4) wire to the +12 Volt DC power circuit. 4. Connect the red wire (A7) to the ACC terminal of the ignition switch. 5. -
Page 7: Appearance, Control Elements
Control elements 1. Turn on / off the device / Select source 2. Next track / Fast forward / Radio tuning 3. Adjust volume / Switch settings / Confirm selection 4. IR receiver 5. LCD display 6. USB connector 7. Receiving / ending a call / Voice assistant / Switching radio bands (FM1, FM2, FM3) 8. -
Page 8: Overall Size
Overall size Remote control Removing the battery protection (CR-2025). Remote control supplied with battery protection. The remote control will not work until the protection is removed. Battery replacement: 1. When the lithium battery has lost its capacity, replace it as shown in the illustration. 2. - Page 9 Remote control Turn on/ off the device 2. Volume control 3. Switching radio bands answer call Previous track / Rewind / Radio setup 5. Source selection Next track / Fast forward / Radio setup 7. Mute mode End call / Clock 9.
-
Page 10: Main Functions
Main functions ON / OFF Power Press any button to turn on the device. Press and hold the button (1) /SRC, to turn on the device. Volume control Rotate the volume knob (3) to set the desired level. Source selection Press the (1) / SRC button to switch between sources playback: Radio ->... - Page 11 DISPLAY settings Color set - customize the color of the RGB backlight. Variable - automatic change of backlight colors. RED (red), PINK (pink), PURPLE (purple), BLUE (blue) Customize - setting a custom highlight color. Version - software version. TUNER settings Local set - local search, on / off Mono set - mono mode, on / off Regional - selection of the broadcasting region (Europe, USA, Asia, Russia).
-
Page 12: Radio
Radio Range selection Press the button (7) BND to select the broadcasting range of radio stations: FM1, FM2, Fm3. Saving and recalling radio stations Press and hold one of the number buttons (1-6) to store the current radio station. Press one of the number buttons (1-6) to recall the current radio station. It is possible to store 6 radio stations in each broadcasting range. -
Page 13: Bluetooth
Pair your phone with the AMH-600BT receiver: 1. Turn on Bluetooth on your mobile device. 2. Find “AMH-600BT” in the list of available BT devices and connect to it. PIN-code for authorization: 1234. 3. In case of successful connection, the “BT” indicator on the display of the receiver will stop blinking and will light up constantly. - Page 14 Bluetooth music (A2DP) The AMH-600BT receiver supports the Bluetooth A2DP audio transmission protocol. After successfully pairing your mobile device with the receiver, you will be able to play music from your phone on the car audio system.
-
Page 15: Phone App
Phone App Most of the device settings are available in the AurA mobile application for Android or IOS. You can control the AMH-600BT receiver from your smartphone: 1. Install the AurA app from Google Play or App Store. 2. Connect your smartphone to the receiver via Bluetooth. - Page 16 lights 10-band equalizer Position adjustment...
-
Page 17: Technical Features
TECHNICAL FEATURES Main Working supply voltage: 12 V (limits 9,6 – 15 V) Fuse: 15 А Maximum output power: 4 х 51 W Speaker Impedance: 4 - 8 Ω Frequency Response Range: 20 Гц – 20 kHz Display viewing angle: vertical ±30°, horizontal ±15°... - Page 18 Due to continuous product development and improvement, all specifications ©2020 AURA Electronics Inc. All rights reserved.
