- Page 1 User manual MISTERO The product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC) EN55014, EN60555-2 and EN60555-3. These cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC...
-
Page 2: Table Of Contents
Index Safretti Mistero 500, Mistero 1000 ........................2 Introduction ..............................2 Important SafetyAdvice………………………………………………………………………………………………2 General nformation…………………………………………………………………………………………………..3 Installation Instructions ............................3 Building the product surround/enclosure………………………………………………………………………4 Ventilation……………………………………………………………………………………………………….5 Electrical connection……………………………………………………………………………………………5 Installing the product into surround/enclosure…………………………………………………………………6 Commissioning/initial product start-up………………………………………………………………………….8 Multiple product installation (daisy chaining)…………………………………………………………………...8 Operating the product ..........................11 Manual controls ............................ -
Page 3: Safretti Mistero 500, Mistero 1000
Safretti Mistero 500, Mistero 1000 Introduction Please read this information guide carefully to be able to safely install, use and maintain your product. Important Safety Advice When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock and injury to persons, including the following: If the appliance is damaged, check with the supplier before installation and operation. -
Page 4: General Nformation
The appliance carries a DO NOT COVER warning symbol. This appliance is not equipped with a device to control the room temperature. Do not use this appliance in small rooms when they are occupied by persons not capable of leaving the room on their own, unless constant supervision is provided. -
Page 5: Building The Product Surround/Enclosure
BUILDING THE PRODUCT SURROUND/ENCLOSURE This product can be built into a wall, surround or structure. Please take note of the product dimensions (Fig. 1) and build your wall, surround or structure accordingly. Suitable clearance should be provided to allow the product to be installed easily. -
Page 6: Ventilation
VENTILATION: VERY IMPORTANT!!! This product needs free air ventilation from underneath to operate correctly. These are slots on the underside of the product to allow this free air through the product. The free ventilation helps keep the electronic components cool and allows the mist to rise and leave the product. Please see Fig. 4 for an example of the required ventilation. - Page 7 The electrician can remove the supplied plug by the following: 1. Lift off the top plate and put switch ‘A’ into the off position (Fig. 21). 2. Ensure that the appliance is unplugged. 3. Lift off the access cover by removing the retaining screw (Fig. 6A). 4.
-
Page 8: Installing The Product Into Surround/Enclosure
INSTALLING THE PRODUCT INTO SURROUND/ENCLOSURE Once your enclosure has been built to the required dimensions and electrical connections has been installed, follow the steps below to install your product. 1. Sit the product on the constructed base, ensuring the cable is accessible and not caught under the product. -
Page 9: Commissioning/Initial Product Start-Up
COMMISSIONING/INITIAL PRODUCT START-UP Connecting the Receiver/Tethered Remote Insert the 3.5 mm jack of the Bluetooth receiver into the socket at the back of the appliance (Fig. 12). It is important to ensure that the jack is pushed fully into the socket. Failure to fully insert the jack will prevent the product from functioning correctly. - Page 10 Multiple Product Control Each product can be paired with its own remote or multiple products can be paired in a single remote. Please note a maximum of six individual products (either M500 or M1000) can be connected to a single Bluetooth remote control.
- Page 11 2. Fit the second product beside the first product, ensuring the protruding screws of the second product engage with slots of the first product (Fig. 20). 3. Ensure the second product is at the correct height to match the first product and ensure it is adequately level.
-
Page 12: Operating The Product
Operating the Product This section describes how to activate your fire using either the manual controls or remote control. MANUAL CONTROLS The manual controls are located beneath the fuel bed (Fig. 21). M500 Mains Switch: Controls the electricity supply to the appliance. (Fig. 21A.) Note: This switch must be in the ‘ON’( I ) position for the appliance to operate. -
Page 13: Receiver Controls
M1000 Mains Switch: Controls the electricity supply to the appliance. (Fig. 21A). Note: This switch must be in the ‘ON’ ( I ) position for the appliance to operate. Button Panel ‘C’ controls the functioning of the left side of the product while Button Panel ‘D’ controls the functioning of the right side of the product. -
Page 14: Remote Control
M1000 • is the on/standby button. Press it to turn on and off the flame effect. • is used to mute the fire crackling sound. Press this to turn on and off the crackling sound. The volume can be adjusted on the manual controls of the appliance. Please note that the mute setting will not be saved after a product restart. -
Page 15: Getting The Desired Flame Effect
Pairing the Remote Control to Multiple Products If you are installing multiple M500/M1000 products you can pair them to a single remote control. To do this, please install the products as described in the ‘Installation Instructions’. Ensure that all products are connected to mains power and have water supplied. -
Page 16: Maintenance
Maintenance GENERAL TIPS Only use tap water in this appliance. Always ensure that the appliance is sitting on a level surface. If you intend not using the appliance for longer than 2 weeks, remove and empty the sump and water tank. Once installed, never move this appliance or lay on its back, without draining the water from sump. - Page 17 Sump 1. Press Switch ‘A’ to the ‘OFF’ (0) position (Fig. 21). 2. Gently lift off the top plate and place it aside. 3. Remove the water tank from its position on top of the sump. 4. Disconnect the electrical connector to the transducers, located on the right side of the sump (Fig. 23). 5.
-
Page 18: Transducer
The transducer is a consumable item and may need to be replaced through time, depending on its usage. Replacement transducers can be purchased from Safretti (info@safretti.com). The transducer is fixed in the sump with a plastic clip. If you need to replace your transducer: 1. -
Page 19: User Manual To Connect Bluetooth Receiver For Smartphone
• Swipe down to search for the device. • If the device has been found, you will see the name “Safretti Magic-Fire” appearing on the screen (see fig. 3 below). • Please click on “Safretti Magic-Fire” and a checkmark appears in the box. Then please click on the arrow... -
Page 20: Additional Information
Attention: it is not possible to connect several smartphones or tablets with the appliance at the same time. You first have to log-out (see fig. 3: click on the name “Safretti Magic-Fire”, so the checkmark disappears) to be able to connect another smartphone or tablet. -
Page 21: Troubleshooting
Troubleshooting The product has been designed to highlight particular errors by flashing the on board LED lights. The lights will flash a number of times corresponding to the error that is occurring. Please see the table below for the meaning of each of the number of flashes.
