0GU3031
HANDSHOWER TRIM
TS170F
RENESSE
•
Thank you for your recent purchase
of the TOTO product . Please read
the enclosed information to ensure
the safe use of your product
.
®
™
Installation and Owner's Manual
English
Contents
Important Safeguards---------------1
Specifications -------------------------2
Before Installation -------------------2
Set-up Drawing------------------------3
Components ---------------------------3
Installation Procedure ----------4-5
Set-up Options -----------------------6
Replacement Parts-------------------6
Warranty---------------------------------7
Español
Français
2007.5
Advertisement
Table of Contents
Related Manuals for Toto RENESSE TS170F
Summary of Contents for Toto RENESSE TS170F
- Page 1 Before Installation -------------------2 Set-up Drawing------------------------3 Components ---------------------------3 Installation Procedure ----------4-5 Set-up Options -----------------------6 Replacement Parts-------------------6 Warranty---------------------------------7 • Thank you for your recent purchase of the TOTO product . Please read the enclosed information to ensure the safe use of your product...
- Page 2 Important Safeguards (For your safety please follow the instructions below) Read these important Safeguards thoroughly before using your Hand shower ●The following symbols indicate safe and proper use of the product. Failure to observe them may result in injury or property damage.
- Page 3 Specification Minimum pressure 20 psi (0.14MPa) (flowing pressure) Water Supply Pressure 125 psi (0.86MPa) (static) Check local building code Maximum pressure Supplied Water Temperature Less than 185°F (85°C) Water that meets National/Primary drinking water regulation Water Quality -104°F (2 - 40°C) Ambient Temperature 1/2”...
- Page 4 Set-Up Drawing 1-9/16” FINISHED WALL (40 mm) 1-9/16” (40 mm) (screw location) Ø4.5x45 2-3/4” (screws) (70 mm) 55” (1400 mm) Overall Length 6-5/16” 1/2” NPT Handshower (160 mm) (Handshower Adapter) Trim SOLD SEPARATELY COLD 2-15/16” (75mm) MIN Complete Shower Set 3-9/16”...
- Page 5 Hand Shower Trim does not have direct water connections or volume control; those items need to be purchased separately (See the Shower Setup Options) From Thermostatic Caution TOTO mark on top Mixing Valve Single Vol Refer to Handshower Adapter Installation manual Control for detailed installtion procedure of the adapter.
- Page 6 Installation of Hand Shower handshower adapter coverplate ①Place the coverplate on the handshower adapter opening and fasten the face Face plate nut plate nut. ②Position the notch below and press the Notch escutcheon into the face plate Right below *If the escutcheon is difficult to attach, apply weak soapy water to the O-ring.
- Page 7 Shower Setup Options 1) Complete Set 2) w/o 3) w/o wall spout 4) Showerhead Product Handshower only Product # Description Showerhead Showerhead Showerhead Showerhead TS170A#CP Showerhead Bath Spout TS170E#CP Handshower Single Hand Shower Trim TS170F#CP Single Vol Vol Control Single Volume Control Trim Dual Vol Trim...
- Page 8 ® ® defect together with proof of purchase (original sales receipt) shall constitute delivery. In such case, TOTO ® may choose to repair the Product at the purchaser’s location or pay to transport the Product to a service facility.
