Conair FLX-128 Basic Operation

Setup Sourcing (Reverse Regrind)
The Reverse Regrind system is used as a way to unload a series of bins attached to a common loader. In this system, rather than sensing a
demand for material (empty bin), the multi-source loader senses a full bin and removes material to evacuate that bin. Multiple grinder bins can be
unloaded sequentially. To begin:
1 Press the Device button and choose a device group.
2 Choose a device to establish as a multi-source loader. Configure
that device as a multi-source loader.
3 Press the Device button, choose a device group for the grinder.
4 Configure each grinder (valve) as a grinder and
assign it to the multi-source loader. Now each
grinder that is assigned to the multi-source loader will appear on its net-
work. (Proper login is required.)
NOTE: The location that multi-source loader is conveying to must be open and
available in order to start unloading the grinder bins.
Device Configuration
Each device is configured individually. Proper login is required. From the
Individual Device screen press the Setup button. Depending upon I/O configu-
rations, some loader configurations may not be available.
To Configure Each Device
1 Press the Devices button, followed by the device
group you would like to access.
2 Press the device you would like to configure.
3 Press the Setup button on the screen. This will
allow you to access the Device Configuration
screen. (Proper login is required.) See the
Operation section of the FLX-128 User Guide for
more information on Security.
4 Choose which features and options you would like to enable.
Depending on your configurations, this could include the Fill Alarm,
Material Check, Purge, Discharge, Priority Load, Ratio configuration, and
other settings.
WARNING:
This card provides only basic troubleshooting
and maintenance information. Users must be familiar with all
safety information and procedures described in the FLX-128
User Guide.
Basic Operation
Quick Card
QCC020-0213
FLX-128
Central Loading
Control
Enable Devices
NOTE: In order to enable devices and utilize all the functionality of the
FLX-128 control, all installation and setup instructions explained in
the User Guide must be completed.
