Summary of Contents for Moffat MDW 542
- Page 1 All manuals and user guides at all-guides.com User Manual Dishwasher MDW 542...
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com Content Safety information - - - - - - - - - - - - - - - - - -3 Control panel and functions - - - - - - - - - - -4 Audible signals - - - - - - - - - - - - - - - - - - - -6 Programme table - - - - - - - - - - - - - - - - - - -7 Before the first use - - - - - - - - - - - - - - - - -7... -
Page 3: Safety Information
All manuals and user guides at all-guides.com Safety information In the interest of your safety and to ensure the correct use, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents. -
Page 4: Control Panel And Functions
All manuals and user guides at all-guides.com Never use the dishwasher if the electrical supply cable and water hoses are damaged; or if the control panel, work top or plinth area are damaged such that the inside of the appliance is freely accessible. Contact your local Service Force centre, in order to avoid hazard. - Page 5 All manuals and user guides at all-guides.com Starting the washing programme: 1. Press the On-Off button. 2. Press the Programme/Cancel once, the light of the last performed washing programme illuminates and the End light flashes. 3. Press the Programme/Cancel as many times as necessary to illuminate the light corresponding to the desired programme.
-
Page 6: Audible Signals
All manuals and user guides at all-guides.com Audible signals Audible signals have been introduced to help Factory setting: audible signals activated. indicate which operations the dishwasher is performing. - end of the washing programme, - malfunction of the appliance. Deactivation/activation of the audible signals 1.The dishwasher must 2.Press and hold 3.Press... -
Page 7: Programme Table
All manuals and user guides at all-guides.com Programme table Programme Cycle description 65° Normal soil. Prewash - Main wash Normal Crockery, cutlery, pots and pans 2 intermediate rinses - Final rinse 65° Light soil. Main wash - Final rinse Quick Crockery and cutlery 50°... -
Page 8: Setting The Water Softener
All manuals and user guides at all-guides.com Setting the water softener The dishwasher is equipped with a water IMPORTANT! softener designed to remove minerals and salts The water softener must be set in both ways: from the water supply, which would have a manually and electronically. - Page 9 All manuals and user guides at all-guides.com Setting the water softener electronically (see table) The water softener is factory set at position 5. The dishwasher must Press and hold Wait until programme The End light might be switched off. Programme/Cancel light 2 turns off, flash 5 times, for Switch on the...
-
Page 10: Filling With Dishwasher Salt
All manuals and user guides at all-guides.com Filling with dishwasher salt CAUTION! Use only special salt suitable for dishwashers Unscrew the cap. Only before filling with Using the funnel salt for the first time, provided, pour in the fill the salt container salt until the container is with water full. -
Page 11: Filling With Rinse Aid
All manuals and user guides at all-guides.com Filling with rinse aid Open the lid. Fill up with rinse aid. Clean up any rinse aid The maximum level for which overflows. Close filling is indicated by the lid and press until it "max". -
Page 12: Loading Cutlery And Dishes
All manuals and user guides at all-guides.com Loading cutlery and dishes The following items are not suitable for use When loading the dishwasher, make sure in the dishwasher: that you: - Remove all left over food and debris. - Cutlery with wooden, horn, china or mother-of-pearl handles - Soften remnants of burnt food in pans - Plastic items that are not heat resistant... - Page 13 All manuals and user guides at all-guides.com Load upper basket. If plates are to be loaded in the upper basket: Light items (plastic load them starting from the rear positions; tilting bowls etc.) must be them slightly forwards and avoiding the front loaded in the upper positions near the door.
-
Page 14: Filling With Detergent
All manuals and user guides at all-guides.com Filling with detergent IMPORTANT! Only use detergents suitable for dishwashers. Observe the manufacturer’s dosing and storage recommendations. Open the lid. Observe the dosing Fill in the detergent in levels. compartment A. For programmes with When using detergent Close the lid. -
Page 15: Cleaning And Care
All manuals and user guides at all-guides.com Cleaning and Care Cleaning the filters IMPORTANT! NEVER use the dishwasher without filters. Incorrect repositioning and fitting of the filters will produce poor washing results. Remove filter A from the The dishwasher must Clean filters A, B and C Turn the handle about base of the washing... -
Page 16: Environmental Concerns
All manuals and user guides at all-guides.com External cleaning Frost precautions Clean the external surfaces of the machine and Avoid placing the machine in a location where control panel with a damp soft cloth. If the temperature is below 0°C. If this is necessary use only neutral detergents. -
Page 17: Something Not Working
All manuals and user guides at all-guides.com Something not working IMPORTANT! The dishwasher will not start or stops during operation. Certain problems are due to the lack of simple maintenance or oversights, which can be solved with the help of the indications described in the chart, without calling out an engineer. Open the door and carry out the following suggested corrective actions. - Page 18 All manuals and user guides at all-guides.com The wash results are not satisfactory The wrong washing programme has been selected. The dishes are not clean The dishes were arranged in such a way as to stop water reaching all parts of the surface.
-
Page 19: Technical Data
All manuals and user guides at all-guides.com Technical data Dimensions Width 59.6 cm Height 81.8 - 87.8 cm Depth. 55 cm Electrical connection Information on the electrical connection is given on the rating plate on Voltage - Overall power - Fuse the inner edge of the dishwasher’s door. -
Page 20: Hints For Test Institutes
All manuals and user guides at all-guides.com Hints for Test Institutes Testing in accordance with EN 60704 must be Test in accordance with EN 50242 must be carried out with appliance fully loaded and carried out when the salt container and rinse using the test programme (see "Consumption aid dispenser have been filled with salt and values"). -
Page 21: Installation
All manuals and user guides at all-guides.com Installation WARNING! WARNING! Any electrical and/or plumbing work required to Only use, for connection to the water mains, install this appliance should be carried out by a new hose-set; old hose-set must not be qualified electrician and/or plumber or reused. - Page 22 All manuals and user guides at all-guides.com CAUTION! Always be sure, that there is no water leakage from hoses and their connections after the installation. Ensure that the hoses are not kinked, crushed or entangled. Electrical connection WARNING! Safety standards require the appliance to be earthed.
- Page 23 All manuals and user guides at all-guides.com Fitting under a counter IMPORTANT! Carefully follow the instructions on the enclosed template for building in the dishwasher and fitting the furniture panel. WARNING! The dishwasher must be secured against tilting. Therefore make sure that the counter it is fixed under, is suitably secured to a fixed structure (adjacent kitchen units cabinets, wall).
-
Page 24: Service And Spare Parts
We, Moffat, undertake that if within 12 months with the manufacturer’s instructions. of the date of purchase this Moffat appliance or The appliance has not been serviced, any part thereof is proved to be defective by... - Page 25 Kingdom. Appliances found to be in use within a commercial environment, plus those which are subject to rental agreements. Products of Moffat manufacture which are not marketed by Moffat. European Guarantee If you should move to another country within Europe then your guarantee moves with you to...
- Page 26 All manuals and user guides at all-guides.com Notes ................
- Page 27 All manuals and user guides at all-guides.com Notes ................
- Page 28 All manuals and user guides at all-guides.com www.electrolux.com 152952 66/0 Subject to change without notice...
