DVD/DIVX PLAYER
Model: DXP-1000
INSTRUCTION MANUAL
COMPACT
DIGITAL AUDIO
DVD / DivX / CD-DA / MP3 / CD / CD-R / CD-RW compatible
Read this manual before installation and use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DXP-1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Avayon DXP-1000

Summary of Contents for Avayon DXP-1000

  • Page 1 DVD/DIVX PLAYER Model: DXP-1000 INSTRUCTION MANUAL COMPACT DIGITAL AUDIO DVD / DivX / CD-DA / MP3 / CD / CD-R / CD-RW compatible Read this manual before installation and use...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Warning & Importance General Information 1. Disc information 2. Select a DVD disc 3. Care of disc Preparation 1. Unpack the unit 2. Loading batteries into the Remote Control System Connections 1. Connecting to TV set 2. Connecting to TV & Stereo Amplifier 3.

  • Page 3: Warning & Importance

    WARNING TO REDUCE THE RISK OF FIRES AND ELECTRIC SHOCKS, DO NOT EXPOSE THIS NIT TO RAIN OR MOISTURE CAUTION RISK OF ELECTRIC S OCK DO NOT OPEN This lighting flash arrow symbol in a triangle is intended to alert users to the presence of non-insulated high voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to person...

  • Page 4: General Information

    GENERAL INFORMATION This unit can play the following types of disc: single side / double sides single layer / double layers DVD-R / DVD-RW DVD+R / DVD+RW DivX Ver. 3.11 / 4.xx / 5.xx CD-DA CD-R CD-RW Photo CD (JPEG) 1.

  • Page 5: Select A Dvd Disc

    2. SELECT A DVD DISC DVD discs and DVD players are manufactured under the worldwide agreed DVD Regional Code System that the player will operate only with corresponding disc of the same Regional Code. DVD Regional Code: Regional Code Region Canada, USA Europe (incl.

  • Page 6: Care Of Disc

    Some features of this unit are related to the DVD disc’s software. Some features of this unit cannot be preformed if the disc does not support the features, or required special settings. Check the features of the disc before playing it, or follow the instruction on screen menu of the disc. 3.

  • Page 7: Preparation

    PREPARATION 1. UNPACK THE UNIT The standard packing contains the following items: The DVD player unit. Infra red remote controller AV Cables Two AAA batteries User’s instruction manual Warranty Registration Card 2. LOADING BATTERIES INTO THE REMOTE CONTROL Remove the battery compartment cover.

  • Page 8: System Connections

    SYSTEM CONNECTIONS DO NOT connect the AC power socket to the wall outlet before the system connection is completed Before turning on the power standby button on the front panel or remote control, you should switch on the main power in the rear panel. Note: The light in the front panel will be red in color when it is in power off mode;...

  • Page 9: Connecting To Tv & Stereo Amplifier

    2. CONNECTING TO TV & STEREO AMPLIFIER Connect the unit’s S-Video or Video output to the TV’s S-Video or Video input. Connect the unit’s Audio (FR / FL) output to stereo amplifier’s input terminals Left (White) and Right (Red).

  • Page 10: Connecting To 5.1 Channels Amplifier

    3. CONNECTING TO 5.1 CHANNELS AMPLIFIER Connect the unit’s ‘S-Video’ or ‘Video’ output to the TV’s S-Video or Video input. Connect the unit’s 5.1 channels surround audio output (FL, FR, SL, SR, CEN, SW) to the 5.1 channels amplifier’s audio input terminals, Front Left, Front Right, Surround Left, Surround Right, Center and Sub-Woofer.

  • Page 11: Connecting To A Ac3 Or Dts Decoding Amplifier

    4. CONNECTING TO AC3 OR DTS DECODING AMPLIFIER Connect the unit’s S-Video or Video output to the TV’s S-Video or Video input. Connect the digital output (optical or coaxial) to the TV’s S-Video or Video input. Press the ‘SETUP’ button on the remote control to enter the unit’s SETUP MENU: Press / v on the Remote Control to select AUDIO SETUP, and Press...

  • Page 12: Panel Description

    PANEL DESCRIPTION 1. FRONT PANEL The items 1-4 are Karaoke function, simply put the DVD or VCD karaoke and getting start playing, then connect the microphone into the MIC1,2 and adjust between Microphone volume and Echo volume for the best effect on sound. Please note that the Volume and MIC buttons need to be pushed so that they pop out and allow for easy tuning.

  • Page 13: Remote Control

    3.REMOTE CONTROL...

  • Page 14: Getting Start

    GETTING STARTED Read through this instruction manual. Unpack the unit. Load batteries into the remote control. Connect the unit, make sure the connections are correct. Connect the power socket to wall outlet, power on the system via switch on rear of unit. Check the setting of the unit, TV and amplifier are correct and match each other.

  • Page 15: Picture Setup

    Picture is not full screen, or border part of picture bas been blocked. The DVD Player is set to NTSC system output as default, if you are not playing in the U.S.A. or in PAL system, please change the output system of the unit by the steps below.

  • Page 16: General Setup

    3. GENERAL SETUP Pressing the SETUP button on remote control during STOP or PLAY mode to SETUP MENU. Using Cursor to select GENERAL SETUP. Press ENTER to enter GENERAL SETUP page. SETUP MENU MAIN PAGE GENERAL SETUP SPEAKER SETUP AUDIO SETUP PREFERENCE EXIT SETUP TV DISPLAY...
  • Page 17 OSD LANG (ON SCREEN DISPLAY LANGUAGE) -- GENERAL PAGE -- TV DISPLAY PIC M ODE ANGLE M ARK OSD LANG ENGLISH CAPTIONS SCR SAVER M AIN PAGE CAPTIONS -- GENERAL PAGE -- TV DISPLAY PIC M ODE ANGLE M ARK OSD LANG CAPTIONS SCR SAVER...

  • Page 18: Speaker Setup

    4. SPEAKER SETUP SETUP MENU MAIN PAGE GENERAL SETUP SPEAKER SETUP AUDIO SETUP PREFERENCE EXIT SETUP DOWNMIX LT/RT : Left and Right output mode ( Either Left or Right channel Audio output while playing ) STEREO : Stereo output mode OFF : Turn off the Downmix mode.
  • Page 19 CNTER DELAY -- SPEAKER SETUP PAG E -- DO WNM IX CENTER REAR SUBWO O FER CNTR DELAY REAR DELAY TEST TO NE M AIN PAG E REAR DELAY -- SPEAKER SETUP PAG E -- DO WNM IX CENTER REAR SUBWO O FER CNTR DELAY REAR DELAY...

  • Page 20: Audio Setup

    5. AUDIO SETUP SETUP MENU MAIN PAGE GENERAL SETUP SPEAKER SETUP AUDIO SETUP PREFERENCE EXIT SETUP OFF: Audio signal is out from (FL/FR) AUDIO OUT (RCA) jacks. SPDIF/RAW: The player is connected to a Dolby Digital amplifier through DIGITAL OUT Coaxial or Optical jack.
  • Page 21 COMPRESSION -- AUDIO SETUP -- SPDIF OUTPUT - FULL OP M ODE DUAL M ONO COM PRESSION PRO LOGIC LPCM OUTPUT M AIN PAGE PRO LOGIC -- AUDIO SETUP -- SPDIF OUTPUT M ODE L M ONO COM PRESSION PRO LOGIC LPCM OUTPUT AUTO M AIN PAGE...

  • Page 22: Preference Setup

    6. PREFERENCE SETUP MENU MAIN PAGE GENERAL SETUP SPEAKER SETUP AUDIO SETUP PREFERENCE EXIT SETUP TV TYPE -- PREFERENCE PAGE -- TV TYPE M ULTI VIDEO OUTPUT NTSC AUDIO SUBTITLE DISC M ENU LOCALE PARENTAL LANGUAGE SELECTION -- PREFERENCE PAGE -- TV TYPE VIDEO OUTPUT AUDIO...
  • Page 23 PARENTAL CONTROL - PREFERENCE PAGE -- TV TYPE VIDEO OUTPUT AUDIO 3 PG SUBTITLE 4 PG 13 DISC M ENU LOCALE 6 PG-R PARENTAL 7 NC-17 PASSW ORD 8 ADULT PASSWORD SETTING -- PREFERENCE PAGE -- TV TYPE VIDEO OUTPUT AUDIO SUBTITLE DISC M ENU...

  • Page 24: Jpeg, Mp3, Divx Format

    JPEG, MP3 & DivX Format When disc with JPEG, MP3 and DivX Format is placed in the machine, one of the following screens will appear. The column ‘Root’ in the left of the SMART NAVI is showing the directory of the disc ; The column in the right will show the files under the directory that you choose.
  • Page 25 MP3 Format SM ART NAVI ROOT M P3 1 M P3 2 M P3 3 M P3 4 M P3 5 M P3 6 M P3 7 M P3 8 MP3 Files listing Press to select the “ROOT” on the left columns & the “FILE” on the right side, press “ENTER”/”PLAY”...
  • Page 26 DivX/MPEG4 FORMAT SM ART NAVI ROOT M P4 1 M P4 3 M P4 3 M P4 4 M P4 5 M P4 6 M P4 7 M P4 8 DivX/MPEG4 Files listing Press to select the “ROOT” on the left columns & the “FILE” on the right side, press “ENTER”/”PLAY”...

  • Page 27: Basic Operation

    BASIC OPERATION (see page 11) Function Key Description POWER POWER STANDBY ON / OFF Always Switch Off the Main Power in the back of the unit if you don’t plan to use the player for a long period of time) OPEN / CLOSE DISC TRAY OPEN If you open the disc tray when a DVD is playing (do not press the STOP button...
  • Page 28 (see page 10/11) Function Key Description SKIP FORWARD SKIP BACKWARD Skip to the next or previous chapter / track. STOP / PRE-STOP Press once to stop the unit, memorizing the stopping position. Press Press to continue playing from the position that it stopped again to completely STOP the unit.

  • Page 29: Function Buttons

    FUNCTION BUTTONS (see page 11) Function Key Description DISPLAY MENU BAR ON SCREEN DISPLAY Activate the Menu Bar On Screen Display, displaying the current status. Repeat pressing the button to activate the first page, the second page of Menu and clear the Menu display.
  • Page 30 Function Key Description GOTO GOTO SEARCH Press the button to enter the SEARCH mode, to select playing at a desired section. The Menu Bar display as follow: TITLE 01 / 20 DVD mode Pressing the CURSOR button to select search mode, Title, Chapter and Time modes: Other disc types mode Pressing the CURSOR button to select search mode, Track and Time modes: REPEAT...
  • Page 31 Function Key Description A – B REPEAT SECTION A Repeat playing back a selected section A Start Press the button at the beginning of the desired section, A B End Press the button at the end of the desired section, B Cancel the setting Press the button again to switch Off the setting, back to normal play To clear the menu bar display, press DISPLAY button...
  • Page 32 Function Key Description MUTE TURN OFF THE VOLUME ZOOM ZOOM PICTURE Enlarge the picture to 4 times In the ZOOM mode, press SLOW SLOW MOTION Repeat pressing the button to change the SLOW motion speeds or back to normal PLAY mode The unit is Muted when slow is pushed...
  • Page 33 Function Key Description TO CHANGE THE AUDIO TRACK SETUP GO TO SETUP MENU VIDEO SYSTEM SELECTION (NTSC/PAL) ( For Progressive Scan Model ) VIDEO PROGRESSIVE SCAN TV AND INTERLACED TV SELECTION Press “+” and “-“ to increase or decrease the audio volume.

  • Page 34: Troubleshooting

    TROUBLESHOOTING When having a problem with this unit, check this list for a possible solution before asking for service: Symptom Check and Action No Power 1. Check the power cord has been properly connected to the wall outlet 2. Check the main power has been switched on in back of unit. Does not play No disc, load a disc Disc has been loaded upside down.
  • Page 35 TROUBLESHOOTING (continue) Symptom Check and Action No surround 1. Check if the audio output has been changed to Analog. sound MP3 disc no 1. When program files or other data files mixed with MP3 files in the same disc, sound or noise the unit may play the non-MP3 files with noise or no sound 2.

  • Page 36: Specification

    SPECIFICATION Type of Disc DVD-R / DVD-RW DVD+R / DVD+RW DIVX Version 3.11 / 4.xx / 5.xx CD-DA CD-R / CD-RW PHOTO CD (JPEG) Video Format MPEG 1, MPEG 2, MPEG 4 Audio Format MPEG 1, LAYER 1, LAYER 2 Signal Output Color System : NTSC / PAL Audio System : AC3 decoded 5.1 channels output / digital...

  • Page 37: Customer Support And Warranty

    CUSTOMER SUPPORT AND WARRANTY 1. CUSTOMER SUPPORT For installation, usage and repair assistance for both the Warranty and Post Warranty periods, go to www.avayon.com/support access customer support.
  • Page 38 During a period of ninety (90) days from the Effective Date, AVAYON will provide service labor to repair a manufacturing defect at its designated service center at no charge to you.
  • Page 39 AVAYON authorized service center, tampering, normal wear and tear, if the serial number has been removed/defaced or deterioration of the external cabinet.
