- Page 1 DVD/DivX PLAYER Model: DXP-1000 INSTRUCTION MANUAL COMPACT DIGITAL AUDIO DivX / MPEG4 / DVD / MP3 / WMA / CD / Photo CD Please read this manual before installation and use.
-
Page 3: Table Of Contents
ONNECTING TO A 2. C ONNECTING TO A TEREO 3. C 5.1 C ONNECTING TO A 4. C ONNECTING TO AN USING YOUR DXP-1000... 16 1. H ... 16 OW TO LAY A 2. V ... 17 IDEO ETUP 3. G ... - Page 4 PECIAL UNCTIONS CHECKING THE FIRMWARE VERSION... 31 BASIC OPERATION ... 32 FUNCTION BUTTONS ... 34 TROUBLESHOOTING ... 39 SPECIFICATIONS... 41 CUSTOMER SUPPORT AND WARRANTY ... 42 1. C ... 42 USTOMER UPPORT 2. W ... 42 ARRANTY NOTES... 44...
-
Page 5: Warnings
WARNINGS TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS LAYER TO RAIN OR MOISTURE! CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This lightning flash arrow symbol in a triangle is intended to alert users to the presence of non-insulated high voltage within the player’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to a person. -
Page 6: General Information
DivXNetworks, the creators of DivX® video technology, and are capable of playing all versions of DivX® video content. DivX Certified ensures that the DivX® content you attain and create can be played on your AVAYON DivX® Certified product. 2. Disc and Format Compatibility... -
Page 7: Selecting Advd Disc
4. Selecting a DVD Disc DVD discs and DVD players are manufactured under the worldwide DVD Regional Code System that stipulates players will operate only with discs corresponding to the same Zone/Regional Code. Zone/Regional Code Zone/Region Canada, USA Europe (including Poland, Romania, The Czech Republic), Japan, Middle East (including Saudi Arabia, Egypt, Iran, South Africa) East Asia (including Hong Kong, Taiwan, South... -
Page 8: Care Of Discs
NOTE: Some features of this player are related to the DVD disc’s software. Some features of this player cannot be preformed if the disc does not support those features, or required special settings. Check the features of the disc before playing it, or follow the instructions of the on-screen menu for the disc. -
Page 9: Preparing For Installation
PREPARING FOR INSTALLATION Your Avayon DXP-1000 comes carefully packaged from the factory with all the accessories you need to start enjoying high quality video entertainment right away. 1. Unpack the Player The standard package contains the following items: DXP-1000 DVD player... -
Page 10: Panel Description
PANEL DESCRIPTION Familiarize yourself with the front panel and rear panel connections and controls before attempting to connect the DXP-1000 to your audio/video system. 1. Front Panel Items 4 through 7 are karaoke functions. Simply insert the DVD or VCD karaoke disc and start playing. -
Page 11: Remote Control
3. Remote Control AVAYON... -
Page 12: System Connections
These connections allow you to enjoy higher quality video. If you want to select the Progressive Scan function, simply press VIDEO on the remote control for this mode of video output. S-video and YUV (YPbPr/YCbCr) cables are not included with the player. Rear Panel of DXP-1000... -
Page 13: Connecting To A Stereo Amplifier
AV cable. You may alternately connect the S-Video output of the player to the S-Video input of the TV using an S-Video cable (not supplied). Connect the player’s Front Left (FL) and Front Right (FR) audio outputs to stereo amplifier’s Left and Right audio inputs. Rear Panel of DXP-1000... -
Page 14: Connecting To A 5.1 Channel Amplifier
NOTE: An amplifier with 6-channel input and output is required. An AC3 decoder is not required. NOTE: Connecting AC3/DTS digital outputs (Optical or Coaxial) to an AC3 or DTS decoding amplifier is also possible. See further instructions on the next page. Rear Panel of DXP-1000... -
Page 15: Connecting To An Ac3 Or Dts Decoding Amplifier
4. Connecting to an AC3 or DTS Decoding Amplifier Your Avayon DXP-1000 features a dedicated Digital Output. This important connection carries data to your receiver that processes multi-channel home theatre or music playback. DTS (Digital Theater Systems) In order to experience DTS Digital Surround, you will need a DTS-capable receiver (or add-on decoder plus amplifier) and 5.1 Channel speakers (Left, Center, Right, Stereo Surround, plus... -
Page 16: Using Your Dxp-1000
Setup the basic system connections Once you have completed your basic system connections, ensure that you can observe the AVAYON screen on your TV screen. If you do not, visually check your cable connections and ensure that the correct settings have been selected on your TV for an external device like your player. -
Page 17: Video Setup
Picture is not full screen, or the border portion of the picture is blocked NOTE: The DVD Player is set to NTSC system output by default. If you are not playing in the U.S.A. or know you are on a PAL system, please change the output system of the player using the steps below. -
Page 18: General Setup
3. General Setup Press the SETUP button on the remote control during STOP or PLAY mode to enter the on-screen SETUP MENU. Use the cursor to select GENERAL SETUP. Press ENTER to display the GENERAL SETUP page. SETUP MENU MAIN PAGE GENERAL SETUP SPEAKER SETUP AUDIO SETUP... -
Page 19: Osd Lang (On Screen Display Language)
OSD LANG (ON SCREEN DISPLAY LANGUAGE) This feature allows you to choose from one of six languages that will be used to display menus and functions on the screen. CAPTIONS This feature allows you to turn on the CLOSED CAPTION feature. Closed Caption displays the spoken audio portion of a video as text on the screen if the disc supports it. -
Page 20: Speaker Setup
4. Speaker Setup Press the SETUP button on the remote control during STOP or PLAY mode to enter the on-screen SETUP MENU. Use the cursor to select SPEAKER SETUP. Press ENTER to display the SPEAKER SETUP page. SETUP MENU MAIN PAGE GENERAL SETUP SPEAKER SETUP AUDIO SETUP... -
Page 21: Center Delay
CENTER DELAY This feature is used in the surround sound mode. The sound coming out from center speaker will be delayed rather than in real time. This delay depends on the distance from the center speaker to where you are listening to the sound. Adjust the audio delay from center channel from 0 to 5 milliseconds. -
Page 22: Audio Setup
5. Audio Setup SETUP MENU MAIN PAGE GENERAL SETUP SPEAKER SETUP AUDIO SETUP DIVX ® REGISTRATION PREFERENCES EXIT SETUP OFF: Audio signal is out from (FL/FR) AUDIO OUT (RCA) jacks. SPDIF/RAW: The player is connected to a Dolby Digital amplifier through DIGITAL OUT Coaxial or Optical jack. -
Page 23: Pro Logic
PRO LOGIC Dolby ProLogic Surround Sound is an analog technology that encodes four channels of sound onto two stereo tracks. Select Dolby ProLogic Surround either ON, OFF, or AUTO. If you choose AUTO, your player will detect ProLogic capability and decode it automatically. -
Page 24: Divx Registration
6. DivX Registration Avayon provides you the DivX® Video On Demand (VOD) registration code that enables you to rent and purchase videos using the DivX® VOD service. For more information about Video On Demand, visit www.divx.com/vod. To locate your VOD registration code, do the following: Press the SETUP button on the remote control during STOP or PLAY mode to enter the on- screen SETUP MENU. -
Page 25: Preferences
RGB (red-green-blue). The setting you choose depends on the capabilities of your TV. The DXP-1000 comes with cabling for a standard analog VIDEO connection. LANGUAGE SELECTION The LANGUAGE SELECTION menus on the PREFERENCE PAGE allow you to take advantage of certain language options that may be available as a feature on your DVD. -
Page 26: Parental Control
The password used to access changes to the Parental Control can be changed by clicking on PASSWORD and selecting CHANGE. The DXP-1000 comes with a default password of 3308. You may enter any combination of four numbers to create a new password. -
Page 27: Defaults
DEFAULTS All of the features on the player can be restored to their original factory settings. To reset the settings to factory setting, Select DEFAULTS on the PREFERENCE PAGE, and choose RESET. SMART NAVI The SMART NAVI feature displays the contents of your DivX movie CD, Xvid movie CD, MP3 CD, or Photo CD. -
Page 28: Divx, Xvid, Mp3, And Jpeg Formats
8. DivX, Xvid, MP3, and JPEG Formats Whenever a disc containing a DivX, Xvid, MP3, or JPEG format is inserted into the player, a SMART NAVI screen will appear that displays the folders in the left column and the contents of the selected folder in the right column. -
Page 29: Mp3 Format
MP3 FORMAT SM ART NAVI ROOT M P3 1 M P3 2 M P3 3 M P3 4 M P3 5 M P3 6 M P3 7 M P3 8 MP3 files listing Press to select the ROOT folder in the left column. This will display the files and/or folders in that folder. -
Page 30: Jpeg Format
JPEG FORMAT SM ART NAVI ROOT JPEG 1 JPEG 2 JPEG 3 JPEG 4 JPEG 5 JPEG 6 JPEG 7 JPEG 8 JPEG files listing Press to select the ROOT folder in the left column. This will display the files and/or folders in that folder. -
Page 31: Special Functions
9. Special Functions The following special functions can be accessed using the Remote Control. CHECKING THE FIRMWARE VERSION You can check the current version of your DXP-1000 firmware as follows: Open the disc tray. Press the GOTO button on the Remote Control. -
Page 32: Basic Operation
BASIC OPERATION Function Key POWER POWER STANDBY ON / OFF Always Switch Off the Main Power in the back of the player if you don’t plan to use the player for a long period of time. OPEN / CLOSE DISC TRAY If you open the disc tray when a DVD is playing (do not press the STOP button will memorize the stopped position. - Page 33 Function Key SKIP FORWARD SKIP BACKWARD Pressing these buttons while playing a video skips ahead or back to the next or previous chapter. While playing an MP3 disc, these buttons skip to the next or previous track. STOP / PRE-STOP Press once to stop the player, memorizing the stopping position.
-
Page 34: Function Buttons
FUNCTION BUTTONS Function Key DISPLAY MENU BAR ON SCREEN DISPLAY Activate the Menu Bar On-Screen Display, displaying the current status. Repeat pressing the button to activate the first page, the second page of the Menu, and to clear the Menu display. PLAYBACK CONTROL (only for VCD playback) Press PBC to toggle PBC ON or OFF. - Page 35 Function Key GOTO GOTO SEARCH Press the button to enter the SEARCH mode, to select playing at a desired section. The Menu Bar displays as follow: TITLE 01 / 20 DVD mode Press the CURSOR button to select search mode, Title, Chapter and Time modes: Title Other disc types mode Press the CURSOR button to select search mode, Track and Time modes:...
- Page 36 Function Key A – B REPEAT SECTION A Repeat playing back a selected section A Start Press the button at the beginning of the desired section A. B End Press the button at the end of the desired section B. Cancel the setting Press the button again to switch Off the setting, and return to normal play.
- Page 37 Function Key MUTE TURN OFF THE VOLUME ZOOM ZOOM PICTURE Enlarge the picture to 4 times normal. In the ZOOM mode, press SLOW SLOW MOTION Repeat pressing the button to change the SLOW motion speed, or back to normal PLAY mode. The unit is Muted when The player is muted when the SLOW button is pushed.
- Page 38 Function Key SETUP VIDEO Progressive scan selection Description TO CHANGE THE AUDIO TRACK GO TO SETUP MENU PROGRESSIVE SCAN TV AND INTERLACED TV SELECTION This function only works with progressive scan TV, please see Page 9 how to connect to progressive scan TV. Note: If there is no picture display on the screen after pressed the ‘VIDEO’, it means that you are in the wrong display mode, your TV set may not support Progressive Scan.
-
Page 39: Troubleshooting
Picture noise / distorted 2. Reset the color system (NTSC or PAL) of the DVD player, or the TV set. 3. Connect the player directly to the TV instead of via a component like a VCR. 1. Select the proper screen format through the on-screen menu. Enter SETUP... - Page 40 TROUBLESHOOTING Symptom No surround 1. Check if the audio output has been changed to Analog. sound MP3 disc plays 1. When program files or other data files are mixed with MP3 files on the same no sound or disc, the player may play the non-MP3 files with noise or no sound. noise 2.
-
Page 41: Specifications
SPECIFICATIONS DVD-R / DVD-RW DVD+R / DVD+RW DivX version 3.11, 4.xx, or 5.xx Type of Disc CD-DA CD-R / CD-RW PHOTO CD (JPEG) Video Format MPEG 1, MPEG 2, MPEG 4 MPEG 1, LAYER 1, LAYER 2 Audio Format Color System : NTSC / PAL Audio System : AC3 decoded 5.1 channels output / digital Signal Output Video Output : 1Vpp (at 75 ohm) -
Page 42: Customer Support And Warranty
(1) year (“Warranty Period”) from the date of their original retail purchase (“Effective Date”). If the player fails to conform to this warranty, AVAYON will repair the Player using new or refurbished parts or replace the entire Player with a new or refurbished Player. - Page 43 AVAYON customer service for warranty support. You are responsible for all transportation charges to and from the service center and for all loss or damage during transport. AVAYON is not responsible for the de- installation or re-installation of the player.
-
Page 44: Notes
NOTES...
