INSTRUCTION MANUAL
250W Electric
Line Trimmer
Model No: QG250ELT
Product No: 1938286001
ASSEMBLY REQUIRED
SAVE THESE INSTRUCTIONS
Please read & understand this manual, paying attention to the safety instructions, before use.
Incorrect use of the product could put the operator or machine in danger.
Whilst every effort has been made to ensure the accuracy of information contained in this
manual, our policy of continuous improvement determines the right to make modifications
without prior warning.
Images used are for illustration purposes only.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for QGarden QG250ELT
Summary of Contents for QGarden QG250ELT
- Page 1 INSTRUCTION MANUAL 250W Electric Line Trimmer Model No: QG250ELT Product No: 1938286001 ASSEMBLY REQUIRED SAVE THESE INSTRUCTIONS Please read & understand this manual, paying attention to the safety instructions, before use. Incorrect use of the product could put the operator or machine in danger.
- Page 2 Copyright Notice Copyright © Handy Distribution Permission is granted to reproduce this publication for personal & educational use only. Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Handy Distribution.
-
Page 3: Table Of Contents
Net Weight 1.35 kg Consistent with our policy of continuous improvement, QGARDEN reserves the right to change the design and configuration of any of its products without notice or obligation. Therefore, please treat the text and images in this manual as being for illustrative purposes only. -
Page 4: Important Information
IMPORTANT INFORMATION WARNING Read this instruction manual carefully before operating this machine. Make sure that you are familiar with the controls and properly operate the machine. Following these instructions can reduce the risk of fire, electric shock and personal injury. IF NOT USED PROPERLY THIS MACHINE CAN BE DANGEROUS! This machine can cause serious injury to the operator and others, the warning and safety instructions must be followed to ensure reasonable safety and efficiency in using this product. -
Page 5: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS It is important that you read and understand the owner’s manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product. - Page 6 GENERAL SAFETY RULES Before you put the machine into operation, you must read this instruction manual. When using this machine, observe the following safety instructions to exclude the risk of personal injury or material damage. Please also observe the special safety instructions in the respective chapters.
- Page 7 SAFETY INSTRUCTIONS FOR WORKING WITH YOUR LINE TRIMMER 1. Operate in daylight or good artificial lighting. If possible, do not use on overly wet ground. 2. Ensure good stability on slopes. Always operate across the slope, never up and down. 3.
- Page 8 10. Do not force the machine. Use the correct machine for your application. The correct machine will do the job better and safer at the rate for which it was designed. 11. Do not use the machine if the trigger levers do not work to turn the machine off. Any machine that cannot be controlled with the trigger levers is dangerous and must be repaired.
-
Page 9: Know Your Machine
KNOW YOUR MACHINE 1. On / Off Trigger 2. Main Handle 3. Cable Restraint 4. Safety Guard 5. Nylon Head, Spool & cover 6. Cutting Knife 7. Motor Head 8. Front Handle... -
Page 10: Assembly
ASSEMBLY WARNING Stop the motor and unplug the electrical cable before any repairs or maintenance operations. DO NOT attempt to start this machine without it first being FULLY assembled. Your line trimmer has been supplied unassembled. Please follow the below steps to complete assembly. - Page 11 PROTECTIVE GUARD Put the protective guard onto the machine. Using a fixing screw, secure the guard to the motor head section. Remove the cutting knife protective cover. CAUTION Risk of injury! On the underside of the protective guard there is a sharp blade designed to cut the thread. Remove the transportation protection before operating...
-
Page 12: Operation
OPERATION DANGER Risk of injury! The device may only be put into operation if there are no defects. If a part is defective it must be replaced before the device is used again. WARNING Risk of injury! Before starting work, check the area & remove all objects which may be kicked up by the unit. - Page 13 LENGTHENING THE NYLON LINE When the unit no longer cuts cleanly, the nylon line has become too short. The best cutting results are obtained when the nylon line is lengthened far enough to be cut by the cutting knife/blade to the correct length. LENGTHENING THE NYLON LINE IN OPERATION: Briefly tap the underside of the spool on the ground when the machine is running.
- Page 14 TRIMMING INSTRUCTIONS 1. Walk, never run with the machine, be very careful when trimming uneven/rough ground. 2. Be careful when changing the direction of the trimmer on a slope. Trim across the face of slopes, never down or up. 3. Do not trim excessively steep slopes. 4.
-
Page 15: Maintenance & Storage
MAINTENANCE & STORAGE WARNING Improper maintenance & storage of the machine may void your warranty. Keep the machine clean for better and safer performance. Turn off the motor and remove the electrical plug from the power source before performing any maintenance. MAINTENANCE Use only original equipment replacement parts. -
Page 16: Trouble Shooting
TROUBLE SHOOTING WARNING! Only perform the steps described in these instructions! All further inspection, maintenance and repair work must be performed by an authorised service specialist! Contact your local authorised service dealer if the problem cannot be solved by yourself! WARNING! If the product does not perform properly, makes unusual sounds, the motor does not start or stop as described, the cutting device does not work properly, or any other irregularity or... -
Page 17: Parts Diagram & List
PARTS DIAGRAM & LIST... - Page 18 Item Item Part No. Description Part No. Description Flat Washer QG126-22 Micro-Switch Screw QG126-23 Capacitor Motor Bottom Support QG126-24 Trigger Spring Motor QG126-25 Trigger Inductor QG126-26 Tension Disc Bearing QG126-27 Left Top Handle QG126-A Rotor QG126-28 Power Cable Bearing QG126-29 Cable Sheath Carbon Brush QG126-30...
- Page 19 EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: Electric 250W Line Trimmer Model(s): QG250ELT Product Number: 1938270001 Type/Serial No. As per rating label on machine Motor Power: 250W Voltage: 220-240V, 50Hz...
- Page 20 GJ HANDY & CO LTD USER WARRANTY POLICY Users Statement of Warranty Each new machine is warranted against defective material or assembly of material under normal usage. The warranty applies to the original purchaser and covers faulty parts and the labour involved in replacing and repairing those parts, which are of original manufacture.
- Page 21 Not covered by this warranty a) The warranty policy does not cover any depreciation or damages caused by ordinary wear, rusting or corrosion, lack of correct maintenance or operation, misuse, abuse, lack of transportation or accident. b) The warranty policy does not cover any costs necessary for the standard periodic maintenance services instructed by the operator’s manual, or service parts replacement which would include oil, filters, tyres, belts, brake linings, fuses, blades, seals and other service parts unless it can be proven that the item has evidence of faulty manufacture.
- Page 22 NOTES...
-
Page 24: Tel: 01793 333212
If you require assistance with regards to the contents or operation of the machine, please contact us: Tel: 01793 333212 Email: customerservice@handydistribution.co.uk Opening hours weekdays: February to October 8:30am - 5:30pm November to January 8:30am - 5:00pm (Closed Bank Holidays) Distributed by Handy Distribution, Murdock Road,...
