Tilting Flat Panel Wall Mount
• Supports most 46"- 110" Flat Panel TVs
• Maximum Weight Capacity: 132 lbs.
• Supports VESA Sizes up to 700x600
For technical assistance or troubleshooting
This product Wall Mount frame is intended for use only with an apparatus which has a maximum weight of 132 lbs. See apparatus
instructions. Using with an apparatus heavier than the maximum weight indicated may result in instability and cause possible
injury.
READ THIS FIRST
Read this entire manual! Do not attempt to install this product if you do not understand the instructions. Contact a qualified
mount installer if you have any doubts about a safe and secure mount installation, or if you are not sure what specific wall
materials you are attaching this mount to. Check all the parts carefully to make sure there are no missing or damaged parts.
Improper installation may result in damage to your TV, property, and personal injury.
Model: A590TM
please call 1-800-936-1168
+0 to -15
Advertisement
Related Manuals for Atec A590TM
Summary of Contents for Atec A590TM
- Page 1 Tilting Flat Panel Wall Mount Model: A590TM +0 to -15 • Supports most 46”- 110” Flat Panel TVs • Maximum Weight Capacity: 132 lbs. • Supports VESA Sizes up to 700x600 For technical assistance or troubleshooting please call 1-800-936-1168 This product Wall Mount frame is intended for use only with an apparatus which has a maximum weight of 132 lbs. See apparatus instructions.
- Page 2 Schoenfeld International Inc. and ATEC are not responsible for personal injury or product damage due to mishandling, incorrect mounting, incorrect assembly, or incorrect use of this product.
- Page 3 Bracket Wall Plate Tilt Adjustment Rod Allen Wrench with Phillips End Long Bolt Washers Tilt Adjustment Rod Bolt M5x6mm Concrete Anchors Long Bolts M6x40mm Bolts Wall Plate Brackets M6x50mm Bolts Tilt Adjustment Rod M8x25mm Bolts Allen Wrench M8x45mm Bolts M8x55mm Bolts Long Bolts Concrete Anchors 10mm Spacers...
- Page 4 Attach the Tilt Adjustment Rod Lay the Brackets (2) on a flat surface with the flat side laying down. Insert the Tilt Adjustment Rod (3) into the outer hole in the side of either Bracket (2) as shown in Fig. 1a below. The Handle of the Tilt Adjustment Rod (3) can be located on either side of the TV.
- Page 5 NOTE: IF YOUR TV SCREEN SIZE IS 60” TO 110” PLEASE FOLLOW THE DIRECTIONS FOUND ON PAGE 6 WHICH USES THE PROVIDED SPACERS. Do not force the bolts into the mounting holes on your TV. Do not use an electric drill to tighten these bolts on your TV.
- Page 6 Attach the TV Bracket to the rear of the TV (continued) If your television has a curved back, and the mounting holes are recessed (Fig 1c) spacers are required. Install the proper size Spacers (N-P) between the TV rear and the bracket structure as shown in Fig 1e.
- Page 7 THESE INSTRUCTIONS ARE FOR ATTACHING THE TV BRACKETS TO 60-110” SCREEN SIZE LED FLAT PANEL TELEVISIONS M8x55mm M6x50mm 22mm 10mm M6/M8 SPACER SPACER WASHER For 60-70” LED TVs: Attach the brackets to the rear of the television using the M6x50mm Bolts (J), 22mm Spacers (P), and the M6/M8 Washers (R).
- Page 9 1. Use a pencil, awl, or a nail to mark the location of the wall stud centers (Fig. 3a) after locating the stud with an electronic stud locator. The distance between the marks should not be less than 16 inches (Studs must not be less than 16” inches.) 2.
-
Page 10: Concrete Wall
1. Place the Wall Plate (1) flat against the wall in the desired location. Use the wall plate as a template to mark the location of the four mounting holes on the wall. Make sure that the mounting holes are level and parallel. Make sure the horizontal holes are no closer than 16” (Fig. 3e). 2. - Page 11 Step 4: Hang the television display A large television requires two people to lift. Schoenfeld International Inc. and ATEC are not responsible for equipment damage or personal injury due to mishandling. 1. Lift the Television display with the brackets attached and carefully hang the top hook of the Brackets (2) over the top bar of the Wall Plate (1) as shown in (Fig.
- Page 12 Step 5: Securing the TV to the Wall Mount Plate 1. Secure the Television to the Wall Plate (1) with the security bolts on the bottom of each Bracket (2) Using a long Phillips screwdriver, tighten the screw at the bottom of each of the two Brackets (2) (Fig 5a).
- Page 13 1. To adjust the angle of tilt, turn the handle on the Tilt Adjustment Rod (3). If the handle of the Tilt Adjustment Rod (3) is on the Left side of the TV: • Turn the handle clockwise to unlock the tilt adjusment. If the handle of the Tilt Adjustment Rod (3) is on the Right side of the TV: •...
- Page 14 This page is intentionally left blank...
- Page 15 We warrant this product to you, the original purchaser at the time of purchase printed on a dated store receipt from an authorized ATEC retailer and for a period of six-years thereafter that our wall mount product and all it’s parts and components are free of defects in material and workmanship under normal use.
- Page 16 Schoenfeld International Inc. and ATEC 5001 American Boulevard West Suite 275 Bloomington, MN 55437 © Schoenfeld International Inc. 2016 PN: A590TM Rev 1.1 February 2016...
