Terminal Instruction Manual
COUNT
DESCRIPTION OF REVISIONS
△
0
0
TITLE
GT21B Terminal Instruction Manual
TECHICAL SPECIFICATION
FORM HC0011-9-1
GT21B
DESIGNED
APPROVED
DESIGNED
CHECKED
HIROSE ELECTRIC CO.,LTD.
KI.HIROKAWA
CHECKED
MH.YAMAGUCHI
HK.WATANABE
WRITTEN
HK.WATANABE
ETAD-T0685-01
DATE
20210701
20210701
20210701
20210701
△
1 / 8
0
Advertisement
Table of Contents
Related Manuals for Hirose GT21B
Summary of Contents for Hirose GT21B
- Page 1 GT21B Terminal Instruction Manual COUNT DESCRIPTION OF REVISIONS DESIGNED CHECKED DATE △ TITLE HIROSE ELECTRIC CO.,LTD. GT21B Terminal Instruction Manual APPROVED KI.HIROKAWA 20210701 CHECKED MH.YAMAGUCHI 20210701 DESIGNED HK.WATANABE 20210701 WRITTEN HK.WATANABE 20210701 △ 1 / 8 TECHICAL SPECIFICATION ETAD-T0685-01 FORM HC0011-9-1...
- Page 2 １．Configuration GT21B-2426/1.6-2.9SCF Female terminal Shield barrel Wire barrel Insulation Barrel Carrier GT21B-2426/1.6-2.9PCF Male terminal Shield barrel Wire barrel Insulation Barrel Carrier △ 2 / 8 HIROSE ELECTRIC CO.,LTD. ETAD-T0685-01 FORM HC0011-9-2...
- Page 3 ２．Crimping procedure （１） Stripping the cable The stripping specification and the cable cut dimensions after crimping are shown below. Cable cut dimensions (GT21B-2426/1.6-2.9SCF + S type housing) GT21T-1S-HU (GT21-1S-HU(*)) Cable cut dimensions (GT21B-2426/1.6-2.9PCF + P type housing) GT21N-1PP-HU(*) Note) The dimensions of the stripping specification are recommended values. In order to satisfy the quality of crimping, please verify the crimp quality standard.
- Page 4 When crimping, set the stripped coaxial cable by making the contact with the wire barrel and the dielectric of the cable, as shown in the Picture1. 【Reference for the position of the cable】 Wire barrel Terminal plate Picture1 Cable position at the crimping △ 4 / 8 HIROSE ELECTRIC CO.,LTD. ETAD-T0685-01 FORM HC0011-9-2...
- Page 5 Appearance after crimping The appearance after crimping is shown in Picture2. The dielectric of the cable may be deformed but it doesn’t affect the product’s function. GT21B-2426/1.6-2.9PCF Appearance after crimping GT21B-2426/1.6-2.9SCF Appearance after crimping Picture2 Appropriate appearance after crimping The shield braid may be trapped between the edges of the shield barrel but it does not affect the quality of the product unless it exceeds the area of the shield barrel.
- Page 6 ※1 There is no problem in quality if the wire can be verified at the edge of the wire barrel. ※2 In case of inspecting by appearance, verify that the cable dielectric exceeds b1. ② Bendinig up, bending down -10°MAX -5°MAX 10°MAX 5°MAX ③ Rolling ±5°MAX ±5°MAX △ 6 / 8 HIROSE ELECTRIC CO.,LTD. ETAD-T0685-01 FORM HC0011-9-2...
- Page 7 ④ Twisting Ｋ ±5°MAX Ｌ ±5°MAX ⑤ Cutoff tab Ｍ 0.3MAX ⑥ Crimp burr height Ｎ1 0.05MAX Ｎ2 0.15MAX Ｎ3 0.05MAX ⑦ Bell mouth 0.1-0.4 △ 7 / 8 HIROSE ELECTRIC CO.,LTD. ETAD-T0685-01 FORM HC0011-9-2...
- Page 8 Do not store the products in a place with much humidity or dust, exposure to direct sunlight, etc. Storage place Temperature & humidity conditions Storage period Indoor storage -30～60℃、60%RH or less Six months (in our packing condition) △ 8 / 8 HIROSE ELECTRIC CO.,LTD. ETAD-T0685-01 FORM HC0011-9-2...
