EXPLODED VIEW PARTS LIST

No. Part No.
120 6400WESC01A
121 6400DESA01A
174 6410VUH004A
300 3091V00669C
301 4811V00123K
303 4980V00C04E
304 4980V00C04F
305 3351V00022A
306 4980V00A29J
330 5020V00904B
400 3808V00471A
401 4980V00B64B
402 3550V00452E
404 3550V00418F
410 3550V00451A
430 5018V00087B
431 4980V00C06C
432 4980V00C07C
433 4980V00B95A
501 3210V00165B
502 3210V00280A
503 4811V00125P
520 6871VMMZS9A
530 6871VPMB17B
540 6871VSMG83A
550 6871VSMZZAA
560 6871VSMANTA
570 6871VSMANZA
571 3141VSNS77A
580 6871VSME85A
590 6871VPMB16A
600 3141VSNS79B
601 4980V00C01C
602 4980V00C58C
610 6912B22007B
611 4814V00502D
612 3110V00477A
615 4980V00B42C
616 3300V00420A
617 3550V00547A
618 4980V01200A
622 5900V09008C
623 4980V00D73B
630 6871VSN221H
640 6316000009B
650 6871VSME75A
670 6871VSME03D
680 6871VSN220L
681 3500V00061R
700 6871VSME82A
720 6871VSMW40D
SPEAKER,WOOFER C080P23K1450 ESTEC WOOFER 8OHM 15/25W 84DB 80 NON
SPEAKER,TWEETER D016D01K1450 8HMOHM 15/25W 85DB 50 NON
POWER CORD,UL/CSA3000MM 3P 3000MM HUG BLACK 500MH 7A
CABINET ASSEMBLY,RU-52SZ80L STEREO NON FRONT
BRACKET ASSEMBLY,SPEAKER 52SZ8D-UA NB05ED ZENITH
SUPPORTER,SCREEN AL RN-52SZ80
SUPPORTER,SCREEN AL RN-52SZ80
SCREEN ASSEMBLY,RN-52SZ30H 1178*670*3.9 NEW STRUCTURE
SUPPORTER,SCREEN AL BAR U/L
BUTTON,POWER RU-44SZ80L ABS 1KEY NON
BACK COVER,RN-52SZ80L KOREA
SUPPORTER,PLATE SECC(EGI) RN-52SZ80L
COVER,LAMP RU-52SZ80L HIPS 40AF SPRAY
COVER,FAN RT-52SZ80DB HIPS 40AF SPRAY DLP
COVER,RN-52SZ80L HIPS 40AF DUST
MIRROR,REFLECTION AVATEC GLASS FRONTSIDE 1108(H1)*561(H2)*589(V)*3.0(T)
SUPPORTER,MIRROR SECC(EGI) RIGHT RN-52SZ80L
SUPPORTER,MIRROR SECC(EGI) LEFT RN-52SZ80L
SUPPORTER,MIRROR AL RN-52SZ80L
FRAME,ABS,AF-303 RN-48SZ40H MAIN CHASSIS
FRAME,CHASSIS HIPS 40AF DU-44SZ53D SMPS
BRACKET ASSEMBLY,REAR AV 44SZ8D-UA NB05ED BOARD TERMINAL
PCB ASSEMBLY,MAIN NB-05ED DU-44SZ80D M/I
PCB ASSEMBLY,POWER SMPS NB-05ED 52SZ8D-UA SMPS M/I
PCB ASSEMBLY,SUB TUNER NB05ED DU-44SZ80D M/I
PCB ASSEMBLY,SUB DIGITAL MB05DA 44SZ8D-UA M/I
PCB ASSEMBLY,SUB NB05ED DU-44SZ80D COMP M/I
PCB ASSEMBLY,SUB DMD NB05ED HD4 MAIN FOR 44SZ8D-UA
CHASSIS ASSEMBLY,SUB NB05ED HD4 DMD BOARD FOR 44SZ8D-UA
PCB ASSEMBLY,SUB AUDIO MB042A DN-44SZ80L
PCB ASSEMBLY,POWER SMPS NB-05ED DU-44SZ80D AC-INPUT M/I
CHASSIS ASSEMBLY,SUB NB05ED HD4 SUB ENGINE ASSY FOR OLD CONDENSING LENS
SUPPORTER,SMPS EGI RU-44SZ63D
SUPPORTER,ENGINE SECC(EGI) HD3 BASE 52SZ80 PRESS
LAMP,HIGH PRESSURE MECURY UHP 120W 1.0 PH E22 PHILIPS 70V 1.6A 130MM/160MM
SHIELD ASSY,62SX4D-UB NB03KB SECC(EGI) 4980V00B43C+4814V00530C
CASE,DU-62SY20D NON E-22 LAMP CASE
SUPPORTER,AL COLOR WHEEL HOLDER(WITH HEAT SINK, MC)
PLATE,LOCK AL . RT-52SZ60D HD3 PLATE UNAXIS C/W
COVER,TOP 44SZ80 TOOL HIPS 40AF PROJECTION LENS
SUPPORTER,ENGINE EGI HD3 COSINA PROJECTION LENS
FAN,DC G9232S06B2-AA DONGYANG 92*92*32 6V 1700RPM DC5-8V 0.34CFM 750MM
SUPPORTER,EGI DMD FAN SUPPORTER(PRESS MOLD)
PCB ASSEMBLY,SUB P/AMP MB042A RN/RU-52SZ80L
BALLAST,EUC-120P/11 PHILIPS REV 0.2 120W DLP PJT
PCB ASSEMBLY,SUB CONT MB042A 80L CONTROL
PCB ASSEMBLY,SUB MB042A 80L CASE DET
PCB ASSEMBLY,SUB NB05CB SIDE A/V FOR DN-62SX40D
BOARD,AV RT-44SZ80LP MB042B LGESY
PCB ASSEMBLY,SUB INTER MB042A DN-44SZ80L
PCB ASSEMBLY,SUB SENSOR MB03CC HD3 DLP SENSOR
- 21 -
