- Page 1 OWNER’S MANUAL INSTALLATION GUIDE MS1400GFM MARINE HIGH POWER AM/FM STEREO RADIO WITH COMPACT DISC PLAYER, AND WIRED REMOTE CAPA B I L I T Y Visit us at www.asaelectronics.com to see our full line of mobile audio and video products.
- Page 2 4.Some vehicles may require an installation kit and/or wiring harness adapter.(sold separately) 5.Ensure that the MS1400GFM is installed horizontally. 6.Attach speaker and power wires to the mating harness pigtails supplied with the MS1400GFM. 7.Carefully double check the wiring, then plug the pigtails into the radio harness, and the harness into the rear of the radio.
-
Page 3: Wiring Diagram
WIRING DIAGRAM The MS1400GFM is designed to not require a constant voltage supply to maintain station memories or operational settings. Do not connect to a voltage source which is constantly hot to prevent draining the battery. CONTROL LOCATIONS ❶ Tune/Track Down ❽... -
Page 4: Basic Operation
BASIC OPERATION Power (PWR) ❷ Press PWR or any other button (except EJECT) to turn the unit on. Inserting a CD will turn the unit on automatically. Press PWR to turn the unit off. LCD Panel ❺ The Liquid Crystal Display (LCD) panel displays the frequency and all activated functions. Note: LCD panels may take longer to illuminate when subjected to cold temperatures for an extended period of time. -
Page 5: Radio Operation
RADIO OPERATION Seek Tuning ❶ Press the up or down tuning button momentarily to seek the next strong station in the current band. Manual Tuning ❶ 1. Press the up or down tuning buttons for more than two seconds to select manual tuning mode. "MANUAL"... -
Page 6: Cd Player Operation
CD PLAYER OPERATION Insert CD With the label surface facing up, gently insert the disc into the slot until the soft-loading mechanism engages and disc play begins. "S-CDP" will appear in the display momentarily, and the CD icon will become animated. "CDP" will appear in the display momentarily with the track number and elapsed time. - Page 7 WIRED REMOTE CONTROL (REMMS1500 OPTION) Mounting Remote The REMMS1500 comes with an aluminum mounting bracket that has 4 (four)notches cut into it so the bracket can be broken away for different mounting depths. Remote Operation The REMMS1500 operation is the same as the functions on the front panel of the MS1400 GFM head unit.
Need help?
Do you have a question about the AquaTronics MS1400GFM and is the answer not in the manual?
Questions and answers
i have a 1400ms unit and the rear speakers dont work i checked wires all connected what could problem be
If the rear speakers do not work despite the wires being connected, possible problems include:
- Incorrect splices or connections.
- Speaker wires shorting to chassis ground or to each other.
- Bare wires not insulated properly.
Check all splices and connections, and insulate any bare wires.
This answer is automatically generated
