OWNER'S MANUAL
AND
INSTALLATION GUIDE
MS1500
MARINE HIGH POWER AM/FM STEREO RADIO WITH
C O M PACT DISC PLA YER, CDC SHUTTLE CONTROLS,
AND WIRED REMOTE CAP A B I L I T Y
Visit us at www.asaelectronics.com to see our full line of mobile audio and video products.
MADE IN CHINA

Advertisement

loading
Need help?

Need help?

Do you have a question about the AquaTronics MS1500 and is the answer not in the manual?

Questions and answers

Related Manuals for ASA Electronics AquaTronics MS1500

Summary of Contents for ASA Electronics AquaTronics MS1500

  • Page 1 OWNER’S MANUAL INSTALLATION GUIDE MS1500 MARINE HIGH POWER AM/FM STEREO RADIO WITH C O M PACT DISC PLA YER, CDC SHUTTLE CONTROLS, AND WIRED REMOTE CAP A B I L I T Y Visit us at www.asaelectronics.com to see our full line of mobile audio and video products.
  • Page 2 4.Some vehicles may require an installation kit and/or wiring harness adapter.(sold separately) 5.Ensure that the MS1500 is installed horizontally. 6.Attach speaker and power wires to the mating harness pigtails supplied with the MS1500. 7.Carefully double check the wiring, then plug the pigtails into the radio harness, and the harness into the rear of the radio.

  • Page 4: Basic Operation

    Press MODE again to return to other mode. Note:The MS1500 is equipped with auxiliary audio input cables enabling you to connect a pre-amp level external audio source directly to the head unit. This allows you to listen to an auxiliary audio source on the vehicle speakers.

  • Page 5: Radio Operation

    RADIO OPERATION Seek Tuning ❶ Press the up or down tuning button momentarily to seek the next strong station in the current band. Manual Tuning ❶ 1.Press the up or down tuning buttons for more than two seconds to select manual tuning mode. "MANUAL"...

  • Page 6: Cd Player Operation

    CD PLAYER OPERATION Insert CD With the label surface facing up, gently insert the disc into the slot until the soft-loading mechanism engages and disc play begins. "S-CDP" will appear in the display momentarily, and the CD icon will become animated. "CDP" will appear in the display momentarily with the track number and elapsed time.
  • Page 7 Preset #4(Shuffle) button again, or by activating the Scan or Repeat functions. INSTALLATION OF THE OPTIONAL ACC56M CD CHANGER NOTE: Contact your marine dealer or ASA Electronics (www.asaelectronics.com) to obtain the ACC56M CD C h a n g e r .
  • Page 8 Make sure it is clean, undamaged, and loaded correctly; reload and check or try another disc Remote Operation The REMMS1500 operation is the same as functions on the front panel of the MS1500 head unit. See Pages 3-8 for detailed operation descriptions. Volume Down ❸...
  • Page 9 S P E C I F I C A T I O N S CD / CD CHANGER Signal-to-noise ……………………………………………………………………………………>86dB Frequency response………………………………………………………………20Hz-20kHz, ±3dB Channel separation @ 1kHz ……………………………………………………………………>65dB D/A converter ……………………………………………………………………………………1 Bit/CH FM Tuner Tuning range ………………………………………………………………………87.5MHz-107.9MHz FM mono sensitivity ………………………………………………………………………………12dBf 50dB quieting sensitivity (stereo) ………………………………………………………………16dBf Stereo separation @ 1kHz ………………………………………………………………………40dB Frequency response ……………………………………………………………...
  • Page 10 M E N U...
