raya FRB-NPF-18 User Manual

Bendie-brite folding usb bi-color ring light (18 in.)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FRB-NPF-18
BENDIE-BRITE
FOLDING USB BI-COLOR
RING LIGHT (18 IN.)
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRB-NPF-18 and is the answer not in the manual?

Questions and answers

Related Manuals for raya FRB-NPF-18

Summary of Contents for raya FRB-NPF-18

  • Page 1 FRB-NPF-18 BENDIE-BRITE FOLDING USB BI-COLOR RING LIGHT (18 IN.) USER MANUAL...
  • Page 2 THANK YOU FOR CHOOSING RAYA. You can take the Raya 18-inch Bendie Brite FRB-NPF-18 with you anywhere you want to record, chat, or livestream, indoors or out. The 18-inch LED ring is ideal for lighting vlogs, interviews, influencer videos, and broadcasting from home.
  • Page 3 ⚠⚡ PRECAUTIONS • Please read and follow these instructions, and keep this manual in a safe place. • Keep this unit away from water and any flammable gases or liquids. • Do not stare directly at the lights when they are powered on.
  • Page 4 OVERVIEW Back 5V 2A...
  • Page 5 Light 1. Top shoe mounts 9. Color temperature 2. Heat vents auto button 3. Bottom shoe mounts 10. AC power socket 4. Brightness knob 11. Locking knob 5. Color temperature 12. 5/8 in. receiver knob 13. Angle lock 6. Battery compartment 14.
  • Page 6 OVERVIEW Phone Arm 1. Phone clamp 3. Flex arm 2. Locking ring 4. Locking wheel...
  • Page 7 Remote Power button Brightness up Color temperature down Daylight button Save button Color temperature Brightness down Auto buttons (100%) Auto buttons (50%)
  • Page 8 MOUNTING THE BENDIE BRITE Loosen the locking knob, and mount the receiver onto your light stand’s 5/8-inch pin. Tighten the locking knob until secure. POWERING THE BENDIE BRIGHT AC Power When operating the light on AC power, first remove the batteries.
  • Page 9 Battery Power The Bendie Brite runs on two NP-F type batteries. When operating the light on battery power, unplug the power adapter. Place an NP-F battery into the battery compartment, and slide it in until it locks in place. OFF will appear on the control screen to indicate the light is receiving power.
  • Page 10 ADJUSTING THE COLOR TEMPURATURE AND BRIGHTNESS Brightness Turn the dimmer knob to adjust the output level from 0% to 100% in 1% increments. Color Temperature Turn the color temperature knob to adjust the color temperature from 2700 to 5600 K in 50 K increments. Auto Buttons The brightness and color temperature auto buttons let you quickly select one of three preset color temperatures...

  • Page 11: Sleep Function

    Brightness presets: 100%, 50%, and 20%. Color Temperature presets: 5600, 4150, and 2700 K. Note: The set brightness and color temperature levels remain constant when cycling through the presets. SLEEP FUNCTION The sleep function lets you conserve battery power during temporary breaks.

  • Page 12: Using The Memory Function

    USING THE MEMORY FUNCTION When you power on the light, it will resume operation with the color temperature and brightness that are set in the memory. To set the memory function, follow these steps. Adjust the color temperature and brightness to the desired levels.

  • Page 13: Adding Accessories

    ADDING ACCESSORIES Use the shoe mounts to add small optional photo and video accessories such as an accessory arm or microphone, makeup mirror (not included), or an optional mini ballhead to mount a web cam. USING THE REMOTE CONTROL The included remote uses an infrared beam to operate the ring light.
  • Page 14 Auto Buttons Use the Auto Buttons to automatically set the light to a warm, neutral, or cool color temperature at either 100% or 50% brightness. Warm: 3200 K / Neutral: 4400 K / Cool: 5600 K Brightness Up/Down The brightness control lets you adjust the light’s brightness from 0% to 100% in 1% increments.
  • Page 15 RECYCLING LITHIUM-ION BATTERIES Lithium-ion batteries are recyclable. You can help preserve the environment by returning your used rechargeable batteries to a collection and recycling location near you. For more information about recycling rechargeable b a t t e r i e s , c a l l t h e C a l l 2 Re cyc l e h e l p l i n e a t 1-877-723-1297, or visit www.call2recycle.org.

  • Page 16: Specifications

    SPECIFICATIONS Light Fixture Color Temperature 2700 to 5600 K Color Accuracy CRI: 98.1 (3200 K) / Standard 97.2 (4400 K) / 97.6 (5600 K) TLCI: 98 (3200 K) / 98 (4400 K) / 98 (5600 K) Cooling System Passive Dimming Yes, 0% to 100% Display Housing Material...
  • Page 17 Connectors Battery Plate NP-F (×2) Power Input Connector Barrel Power Output USB Standard-A Connector Mounting Fixture Mount 5/8 in. Tilt ±90° Power AC Input Power 110 to 240 V AC, 50/60 Hz DC Input Power 7.4 V Power Source AC adapter, NP-F battery Max Power 60 W Consumption...
  • Page 18 SPECIFICATIONS CONT. Remote Operation Remote Control Type Proprietary Frequency Smartphone Bracket Maximum Width 3.25 in. (8.2 cm) Length 7.5 in. (19 cm)

  • Page 19: One-Year Limited Warranty

    ONE-YEAR LIMITED WARRANTY This Raya product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
