raya BRITE STIX SB-B User Manual

Bi-color led wand with remote
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SB-B
BRITE STIX
BI-COLOR LED WAND
WITH REMOTE
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BRITE STIX SB-B and is the answer not in the manual?

Questions and answers

Related Manuals for raya BRITE STIX SB-B

Summary of Contents for raya BRITE STIX SB-B

  • Page 1 SB-B BRITE STIX BI-COLOR LED WAND WITH REMOTE USER MANUAL...
  • Page 2 THANK YOU FOR CHOOSING RAYA The Raya Brite Stix Bi-color LED wand provides even illumination along its 15-inch length. It’s extremely simple to operate, and it packs up in its own carry bag so it can go anywhere light is needed for photos or video. It has a color temperature range of 3000 to 5600 K that’s...
  • Page 3 Keep this unit away from water and any flammable gases or liquids. • Do not attempt to disassemble or repair the equipment—doing so will void the warranty, and Raya will not be responsible for any damage. • Handle the unit with care.
  • Page 4 FEATURES • Built-in rechargeable lithium-ion battery • 3000 to 5600 K adjustable color temperature range • 15 in. illumination area • 6-step adjustable brightness • All LED mode for extra brightness • 1/4-20 socket for tripod mounting • Remote included...

  • Page 5: Box Contents

    BOX CONTENTS • Brite Stix Bi-color LED Wand • Remote • Wrist strap • Charging cable • Carry bag • User manual...
  • Page 6 OVERVIEW Front Back Mode Light 1. LED panel 6. Charging indicator 2. Built-in diffuser 7. Power button/ 3. Handle mode selector 4. USB charging port 8. Color temp and 5. 1/4-20 mounting brightness socket...
  • Page 7 Front Back Remote 9. Power button 13. Battery lock 10. All LEDs button 14. Battery tray 11. Brightness buttons 12. Color temperature buttons...
  • Page 8 POWERING ON AND SELECTING THE MODE Press and hold the power button to turn the Brite Stix on or off. Press the power button to switch from Color Temperature mode to Brightness mode. Note: The Brite Stix cannot be powered on or off by the remote.
  • Page 9 Brightness Mode In Brightness mode, the light’s output can be adjusted from 10% to 100% in six 15% increments. Press the buttons to adjust the brightness incrementally. Press and hold either button to rapidly adjust. All LED Mode All LED mode provides a 30-second burst that increases the Brit Stix’s output by illuminating all tungsten and daylight LEDs at full brightness.

  • Page 10: Charging The Battery

    CHARGING THE BATTERY Connect the Brite Stix to a powered USB port with the included cable. The charging indicator will blink while the battery is charging and will stop blinking when the battery is fully charged. To charge the Brite Stix from an AC outlet, plug the USB cable into a USB power adapter (not included).

  • Page 11: Remote Operation

    REMOTE OPERATION Power Button: Once the Brite Stix is powered on via the on-handle power button, press the remote’s power button to activate Sleep mode. Press the power button again to resume operation. Brightness Buttons: Press the Brightness buttons to adjust the brightness in 15% increments. Color Temperature Buttons: Press the Color Temperature buttons to adjust the color...

  • Page 12: Replacing The Battery

    REPLACING THE BATTERY The remote is powered by a CR2025 battery. To replace the battery, follow these steps: 1. Push in the battery lock and slide the CR2025 battery tray out of PUSH the remote. OPEN 2. Remove the old battery, and replace it with a new battery in the correct orientation, indicated by the illustration on the back of the remote.

  • Page 13: Specifications

    SPECIFICATIONS Light Fixture Color Temperature 3000 to 5600 K 84.6 (3000 K), 87.2 (4400 K), 84.9 (5600 K) TLCI 75 (3000 K), 74 (4400 K), 73 (5600 K) Light Intensity 171 lx (3000 K), @ 3 ft. 197 lx (4400 K), 183 lx (5600 K) Cooling System Passive...
  • Page 14 Mounting Fixture Mount 1/4-20 socket Remote Operation Remote Control Type Wireless Range 23 ft. (7 m) Power AC Input 5 V / 1.5 A DC Power Source Li-ion battery Max Power Consumption 7.2 W Cable Cable Type Micro-USB Cable Length 22.25 in.

  • Page 15: One-Year Limited Warranty

    ONE-YEAR LIMITED WARRANTY This Raya product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
